Summary of Contents for MILLASUR anova ATM40
- Page 1 ACCESSORY FOR LAWN TRACTOR ATM40 Millasur, SL. Rúa Eduardo Pondal, nº 23 - Pol. Ind. Sigüeiro 15688 - Oroso - A Coruña - 981 696 465 www.millasur.com...
- Page 2 We therefore recommend that you read this instruction manual carefully and follow all our recommendations. For more information or questions, you can contact us through our web supports such as www.anova.es and www.millasur.com INFORMATION ABOUT THIS MANUAL Pay attention to the information provided in this manual and on the machine for your safety and that of others.
-
Page 3: Table Of Contents
Content 1. Safety warnings and general rules 2. Components and parts of the ATM40 accessory 3. Assembly instructions 4. Operation 5. Maintenance and storage 6. Environment 7. Exploded view 8. CE conformity declaration 1. Safety warnings and general rules Please read this manual carefully before using the riding mower attachment. - Page 4 The warnings, cautions, and instructions described in this instruction manual cannot cover all possible conditions or situations that may occur. Common sense and caution are factors that must be present at all times. Assembly required This product requires assembly before use. See the mounting instructions section for more information.
-
Page 5: Components And Parts Of The Atm40 Accessory
2. Components and parts of the ATM40 accessory Part Description Comb base Spring tines Height adjustment lever Shaft support Wheels Lifting plate Hitch brackets Hitch mount Spring alignment Part Quantity Description Stop bolt Hexagon bolt M8x50 Hexagon bolt M8x30 fifteen Hexagon bolt M8x20 Carriage bolt M8x25 Hitch pin φ... -
Page 6: Assembly Instructions
3. Assembly instructions Tools required for assembly: (2) 1/2 "wrenches (1) 9/16 "wrench (1) 3/4 "wrench or adjustable wrench (1) Pliers Before assembling the accessory, set up all parts and hardware as shown on the previous pages. The 40 "straw eliminator is shown in the following drawings. The 40" and 48 "assembly is the same except as indicated in the instructions. - Page 7 7. Attach the hitch mounting arms to the outside of the hitch arm mounting brackets on the rear of the tine guard. Use two M8x25 carriage bolts, Ø8 lock washers and M8 hex nuts. Do not tighten yet. Ø8 lock Carriage washer bolt M8x25...
- Page 8 Shaft support Hexagon bolt M8x20 Hex nut M8 12. Mount the wheels to the axle bracket with two flange bolts and two M10 hex locknuts. To tight. Stop bolt Hex nut M10 Attach ten spring teeth to the square holes at the bottom of the tooth guard. Use an M8x25 carriage bolt, a Ф8 large flat washer, an Ø...
-
Page 9: Operation
Spring alignment wire 15. Mount a hitch arm mounting bracket to the axle bracket using two M8x25 carriage bolts, Ø 8 lock washers, and M8 hex nuts. Do not tighten yet. 16. Insert the lift handle down through the tine guard. Attach to the newly assembled hitch arm mounting bracket with an M8x20 hex bolt and M8 hex locknut. -
Page 10: Maintenance And Storage
• Lower the blade remover to the operating position using the lift handle. • Loosen the two hex nuts and carriage bolts that secure the rear of the hitch mounting arm to the hitch arm mounting brackets. • Adjust the tin guard until it is level and the front and rear spring teeth are in contact with the ground. -
Page 11: Environment
Maintenance 1. Before each use, check that all nuts and bolts are tight. 2. Lubricate the wheels as necessary. 3. If rust appears on guard or spring teeth, lightly sand and coat with enamel paint. 4. Always store in a dry area and coat exposed metal with light oil when not in use. If a part needs to be replaced, use only parts that meet the manufacturer's specifications. -
Page 12: Exploded View
7. Exploded view ATM4... -
Page 13: Ce Conformity Declaration
8. CE conformity declaration DISTRIBUTION COMPANY MILLASUR, SL RUA EDUARDO PONDAL, Nº 23 PISIGÜEIRO 15688 OROSO - A CORUÑA SPAIN CE DECLARATION OF CONFORMITY In compliance with the different CE directives, it is hereby confirmed that, due to its design and construction, and according to the CE mark printed by the manufacturer on it, the machine identified in this document complies with the relevant and fundamental requirements in health and safety.
