Stream SV8W Quick Start Manual

SV8W Quick Start Guide
[iv]
[iii]
[ii]
SV8W
_______________________________________________________________________________________________

Preparing the SV8W

Steam Operation:

1. Plug cable into a wall outlet.
NOTE: Do NOT use multi-outlet power-boards and
avoid using low-quality extension cables.
2. Open water tank filler cap (iii), fill tank with clean
tap water up to the top then close filler cap.
NOTE: Do NOT use de-mineralised water and do NOT
fill with any chemicals.
3. Turn SV8W on using the ON/OFF switch (i), making
sure the steam level lights on the display (g) light up
after a few seconds.
4. Connect hose into the SV8W by opening the
protective plastic flap located on the front of the
machine (ii) and pushing the plug end of the hose in
with the round red button on the top side of the hose
until it clicks.
Proceed to "Vacuum Operation" and/or "Water Injection
Operation" section if you are planning on using the vacuum
and/or water injection functions together with the steam
functions.

Vacuum Operation:

1. Turn the vacuum on from the hose controls by
quick-pressing (V).
The SV8W will make a beeping noise and
the vacuum waste tank lights
(b) will flash on the display.
2. Open the transparent
vacuum cover (iv), remove
blue foam filter and slowly fill
clean tap water into the
rectangular hole on top of the
vacuum waste tank until the
vacuum waste tank lights (b)
stops flashing.
3. Replace the blue foam filter
and the transparent vacuum cover (iv).
Tel: 1300 79 50 50 E-mail:
[b][c][d]
[e]
[f]
[i]
SV8W Display
info@steamaustralia.com.au
[V]
[L]
[g]
[S]
SV8W Hose Controls
NOTE: If the vacuum waste tank
lights (b) still flashes after filling
the tank up, remove the plastic
part with the rectangular hole,
then remove the plastic divider
underneath. You will see a
white float, make sure the
white float's surrounding areas
and the float itself is clean and
can move freely. Re-assemble
the waste tank, fill the tank with clean tap water until
the vacuum waste tank lights (b) stops flashing then
put the blue foam filter and transparent vacuum
cover (iv) back on.

Hose Handle Operations

Steam Functions:
1. After 5-6 minutes the 'Steam Ready' lights (d) will
light up on the display and the steam function is ready
for use. Make sure the steam level lights (g) is on,
otherwise quick-press the
the steam level lights turn on to prepare the steam
function for use.
2. If the SV8W makes a beeping noise and the 'Low
Water' lights (c) flashes, proceed to Step 2 of
"Preparing the SV8W | Steam Operations".
3. Press and hold the RED
between 3 steam levels: low, medium, or high. The
steam level lights (g) display will light up in
correspondence to the different steam levels: 1 =
Low, 2 = Medium and 3 = High.
4. Once you have selected which steam levels you
want, press the trigger located underneath the hose
handle (T) to release steam from the nozzle.
WARNING: Do NOT operate hose with steam nozzle
pointing at persons, animals or electrical machinery
Web: www.steamaustralia.com.au
[T]
RED steam button (S) until
steam button (S) to select
1
