- Page 1 Operation & Maintenance Manual Please read and save this manual. Follow all safety instructions. Air Sanitation System Models: CLNS10K or CLNS10K-E...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Warnings / Instructions / Labels / Caution Major Parts Breakdown / Specifications Package Content / Pre-Installation Unpacking / Set-up Procedures / Install Locations Meter Features / Warning Lights 9-11 Schedule / Care and Maintenance 12-19 Warranty Information 20-21 Maintenance Scheduler SAFETY WARNINGS... -
Page 3: Safety Warnings / Instructions
READ AND SAVE THESE INSTRUCTIONS DO NOT DISCARD SAFETY INSTRUCTIONS R E A D A N D F O L L O W A L L S A F E T Y INSTRUCTIONS IN THIS MANUAL • The unit is to be used indoors only •... - Page 4 Toujours débrancher le courant avant de changer l’ampoule ou d’effectuer un entretien. Remplacer le courant avant l'entretien la lampe par le numéro de pièce Aguair: G24T5L., Fabriqué par Aguair, Inc. ATTENTION Pour réduire les risques d'électrocution, n'exposez...
-
Page 5: Major Parts Breakdown / Specifications
Major Parts Breakdown Surface Contaminent Filter VOC / Odor Control Filter Filter Switch FIlter Sensor Lid Safety Switch Blower Maintenence Timer Power Supply UV Lamps Ballast Titanium Dioxide Coated Tube Hour Meter Rocker Switch Particulate Filter Intake Filter Green Indicator Replacement Red Indicator Antimicrobial Filter... -
Page 6: Package Content / Pre-Installation
Package Content Surf X Surf X SURFACE CONTAMINATION PREVENTION FILTER Included in the assembly: 1. UV lamps, Qty: (2) 2. Surf X sachet container, attached to wall of exhaust outlet on Pathogen models, shipped loose with ethylene control models. 3. Surf X foil package 4. - Page 7 Unpacking your ClensAir™ Air Sanitation System The ClensAir factory has ™ taken all possible precautions to prevent damage to your system during shipping. In the rare case of damage to the unit or power cord, please contact us immediately before plugging in and using the unit.
- Page 8 Set-up Procedure - continued Remove the Surf X sachet from its foil packet, and place in the dispenser located in front of the VOC / Odor Control filters. NOTE: On ethylene models, the dispenser is shipped loose. Simply clip it on the outside of the exhaust grill, in the center. Place the cover on top of the box, being careful to match the gasket to...
- Page 9 Set-up Procedure - continued 100% HOURS Reset Air Filter INTAKE FILTER OPERATIVE REPLACE LAMPS LAMPS POWER Press the lower part of the power switch on and the unit will begin functioning. You can now start enjoying cleaner air! If the intake filter indicator is initially in the red, push/hold reset button. Installation Locations Install the ClensAir unit as central in the room as possible, not close ™...
- Page 10 Operation Features Hour meter The hour meter will accumulate total time the unit has run. It will not operate if the unit is only plugged in, but not turned on. 100% HOURS Reset Air Filter INTAKE FILTER OPERATIVE REPLACE LAMPS LAMPS POWER Particulate Filter Indicator...
-
Page 11: Meter Features / Warning Lights
Lamp Replacement Warning Lights The single green and red LED’s measure hours of UV lamp operation. The lamps lose their efficiency at 10,000 hours and should be replaced. 100% HOURS Reset Air Filter INTAKE FILTER OPERATIVE REPLACE LAMPS LAMPS POWER To indicate that the timer is working, the green light is on continuously for 50 seconds. - Page 12 Lamp Replacement Warning Lights - continued When the lamps are replaced, the reset button located in the intake chamber should be pressed and held for 10 seconds to reset the timer.
- Page 13 Maintenance Schedule No. Part Number Description Maintence Schedule CLSPRT001 ClensairTM Particulate Filter 3 Months or as needed ClensairTM Antimicrobial Filter 6 Months or as needed CLSATM001 Smartlite Germicidal Bulb 12 Months SLGM25401 Only if signs of blockage CLSCB001 VOC / Odor Control Filter CLSSX001 Surf X Surface Contamination Filter 3 Months...
-
Page 14: Schedule / Care And Maintenance
Care and Maintenance Your ClensAir unit has been carefully designed to require minimal ™ attention while providing years of dependable service. Be sure to disconnect the power to the unit before performing any maintenance to prevent injury! There is 110 volt AC power present in the unit! Do not override the safety interlock switches! Exposure to the Ultraviolet rays are harmful to the eyes and skin! - Page 15 Maintenance Surface Contamination Prevention Filter (Surf X sachet) Change to a fresh packet every 90 days. The Surf X sachet should be replaced every 3 months to maintain efficacy. Simply remove the sachet from the dispenser wprovided with each new ClensAir unit. A dispenser that houses them is in ™...
- Page 16 Maintenance Intake particulate air filter Change as required as indicated by the Filter Minder on the control panel. The green lights will appear and rise as filter restriction increases. When the red lights appear, it is time to change the filter (occurring about every 3 months). To change the two intake filters, particulate and antimicrobial, remove the lid from the box by loosening the ¼ turn fasteners.
- Page 17 Maintenance Intake particulate air filter - continued Lift the two filters from their place. Insert the new particulate filter, being careful to line up the arrow on the filter, towards the inside of the box with the pleats horizontal.
- Page 18 Maintenance Intake particulate air filter - continued The antimicrobial filter is non directional: just line the pleats up horizontally.
- Page 19 Maintenance Ultraviolet lamps and reflective chamber After 8,000 hours, the green and red light alternate. At 10,000 hours, the red light only will blink, signaling the lamps need to be changed. To change the lamps, remove the lid of the enclosure. Wearing gloves, carefully retract the spring loaded lamp holder and remove each lamp.
- Page 20 Maintenance If your hands ever come in contact with the UV lamps, wipe them down with a soft cloth and denatured alcohol. Oil from the skin will adhere to surface and may cause premature lamp failure. Should the reflective plates in the lamp chamber get dirty, carefully remove the UV lamps and stainless steel tube. Use a clean soft cloth and denatured alcohol to gently wipe them down;...
- Page 21 365 days from the date of invoice for parts and 90 from the date of invoice for labor, and that either Aguair LLC or its Authorized Service Agency’s examination, shall disclose to the Distributor’s satisfaction to be thus defective.
- Page 22 THE WARRANTY OF MERCHANTABILITY, EXCEPT AS SPECIFICALLY SET FORTH HEREIN. Except as stated above, Aguair LLC, its suppliers, and agents will not be liable for any loss, injury, or damages to persons or property resulting from failure of defective operation of any...
-
Page 23: Maintenance Scheduler
Maintenance Scheduler Write in schedule to know exactly when it is time to change filters. Start date of unit Surf X Surface Contamination Filter |Change Every 3 Months Change Date Change Date Change Date Change Date Change Date Change Date Change Date Change Date Change Date Change Date Clensair Particulate Filter |Change Every 3 Months Change Date Change Date Change Date... - Page 24 AGUAIR Contact Us 1359 Gresham Road Marietta, GA 30062 sales@aguair.com 6 7 8 . 6 7 1 . 2 7 5 7 | 8 4 4 . 9 9 3 . 3 6 6 0 Aguair.com...
