Summary of Contents for Varco VP-16
- Page 1 V A R C O P R U D E N B U I L D I N G S VP-16 Seamer Tool Manual The field guide for proper use of the Model VP-16 SSR Seamer Tool.
- Page 3 Caution/Safety The Builder/Erector remains solely responsible for the safety of all techniques and methods utilized by its crew in the erection of the building. The Builder/Erector is also responsible for supplying any safety devices, such as scaffolds, runaways, nets, etc. which may be required to safely erect the metal building system and to perform the SSR-Seaming Operations.
- Page 4 ________________________________________________________________________________ Page 4 Bi-Directional Seamer Tool Manual VP Buildings #4037...
-
Page 5: Table Of Contents
Table of Contents A. Bidirectional SSR Seamer Tool - Model No. VP16 Item Page 1. SSR Seamer Tool Kit Components........6 2. Basic Description............7-8 3. Power Source..............9 4. Preparation For Seaming..........10 5. Seaming Operation/Start/Endlaps/Finish....11-14 6. Field Maintenance/Troubleshooting.......14-15 7. Seaming Information...........16 8. Hand Crimping/Information.........17 B. -
Page 6: Ssr Seamer Tool Kit Components
Model No. VP16 1. SSR Seamer Tool Kit Components 1. Bi-directional SSR Seamer Tool 2. This Field Manual 3. One (1) Finish Seam Gauge 4. Shipping Box. Do Not Discard. Save for Storage & Shipping. ________________________________________________________________________________ Page 6 Bi-Directional Seamer Tool Manual VP Buildings #4037... -
Page 7: Basic Description
Model No. VP16 2. Basic Description 1. The SSR Seamer Tool is a special precision designed and built, portable roll-forming machine. This tool can seam in two directions. 2. The tool is powered by an electric motor, rated at 3/4 H.P./10 Amp/115 volt/60 cycle single phase 3. - Page 8 Model No. VP16 2. Basic Description 8. Forming Rolls. First Set (Rolls #1 & 4) - Fig. 1 Tuck the female lip under the male lip and begin to pull the seam together. FIG. 1 Second Set (Rolls #2 & 5) - Fig. 2 Force the two parts of the seam together and begin the finishing process.
-
Page 9: Power Source
Model No. VP16 3. Power Source 1. The 5 station roof seamer motor requires a 20 amp, 100-125 volt AC power supply. Poor performance and motor damage can result from use of an improper power supply. Recommended extension cord size: Distance (FT) 0-50 50-100... -
Page 10: Preparation For Seaming
Model No. VP16 4. Preparation For Seaming Check Seamer Tool 1. Check Seamer Tool for Grease. When in use, tool should be lubricated every day. If Seamer Tool is in sustained, continuous use, grease every four (4) hours (four shots per grease fitting). -
Page 11: Seaming Operation/Start/Endlaps/Finish
Model No. VP16 5. Seaming Operation/Start To Begin Seaming Operation: 1. Ensure proper engagement of the male and female hems. Hand crimp with VP Hand Crimping Tool or channel lock type pliers (use caution to not scratch finish when using channel lock pliers). Hand crimp at least eighteen inches (18") (457mm) to allow the first two (2) sets of forming rolls to engage. - Page 12 Model No. VP16 5. Seaming Operation/Start 3. Clamp leading 3 handles down to the locked position. Rear 2 handles should remain disengaged. 4. Turn Power Switch on and run seamer about 4 inches (102mm). Check seam to ensure proper seaming operation. 0.45"...
- Page 13 Model No. VP16 5. Seaming Operation/Start HAND CRIMPING AT START OF SEAMING OPERATION: (Use caution CRIMPING THE FEMALE LIP OF SEAM INTO POSITION: to not scratch finish when 6. When the seamer tool approaches the End Lap, "STOP" using channel the Seamer tool before crossing the End Lap and hand lock pliers) crimp the leading edge of female lip.
-
Page 14: Field Maintenance/Troubleshooting
Model No. VP16 5. Seaming Operation/Start Note: Starting Seamer Tool at Midpoint of Seam It is possible to start seaming at midpoint of a seam by hand crimping 12 inches (305mm). Then place the seamer on that area 6. Field Maintenance/Troubleshooting 1. - Page 15 Model No. VP16 6. Field Maintenance/Troubleshooting (continued) If the seamer tool jumps off the seam, the panel module may be too wide. This lowers the height of the seam and prevents the proper engagement of the forming rolls and the SSR panel seams. Panel Module Must Be Maintained. REF: Fig. 1, 2,& 3. FEMALE MALE RIB 2 3/8"...
-
Page 16: Seaming Information
Model No. VP16 7. Seaming Information Correct/Incorrect Engaged Seams Check seams to ensure they are engaged prior to seaming. SEALANT FEMALE MALE SSR-Correct/Incorrect Seams & Finish Seam Gauge 0.45" Max. @ Center of Included with the Seamer Tool is an SSR (11.4 mm) SSR Clip "Finish Seam Gauge". -
Page 17: Hand Crimping/Information
Model No. VP-2000 8. Hand Crimping/Information 3. Hand Crimping/Information A. Always hand crimp the following areas with VP-SSR crimping tool or with ChanneLock® pliers or a similar tool. Use caution to not scratch finish when using ChanneLock® pliers. Reason: To ensure proper engagement of forming rolls and rolling guides. To ensure proper start of seaming operation, endlaps and finish end of seamer panel. -
Page 18: Vp-Ssr Hand Crimping Tool
Model No. VP-43600 1. VP-SSR Hand Crimping Tool ________________________________________________________________________________ Page 18 Bi-Directional Seamer Tool Manual VP Buildings #4037... -
Page 19: Uses Of Hand Crimping Tool
Model No. VP-43600 2. VP-SSR Hand Crimping Tool Uses of Hand Crimping Tool VP Hand Crimping Tool is recommended for starting the seaming process but not required. The hand crimping tool, if used properly, will provide a tighter, more uniform seam upon which to start the seamer. -
Page 20: Step 1: Positioning
Model No. VP-43600 3. VP - SSR Hand Crimping Tool Step 1: Positioning Place hand crimping tool on SSR rib over female leading edge, female edge will fit into notch on left hand side, right hand side will fit flush on back side of vertical leg. ________________________________________________________________________________ Page 20 Bi-Directional Seamer Tool Manual... -
Page 21: Step 2: Crimp Female Leading Edge
Model No. VP-43600 4. VP - SSR Hand Crimping Tool Step 2: Crimp Female Leading Edge Crimp female leading edge until edge is turned up into male location. Crimping of female leading edge may require more than one crimping action. ________________________________________________________________________________ VP Buildings #4037 Bi-Directional Seamer Tool Manual... -
Page 22: Step 3: Crimp Finish End
Model No. VP-43600 5. VP - SSR Hand Crimping Tool Step 1: Crimp Finish End 0.45 Max. (11mm) To complete hand crimping of the SSR seam, turn crimping tool around so the flat side/right hand side is against the open seam, then finish crimping. - Page 24 Varco Pruden Buildings, 3200 Players Club Circle, Memphis, TN 38125 4037 Seamer Tool Model Guide ©BlueScope Buildings North America, Inc. All rights reserved. Form: EG-902947 Issue Date: 2016 Varco Pruden Buildings® is a division of BlueScope Buildings North America, Inc. Revision: New Issued: 8/16...
