A U D I O, I N C
WWW.BUTLERAUDIO.COM
OWNER'S INFORMATION FOR
MODELS 5150 & 3150
MODULAR DIRECT-COUPLED
VACUUM TUBE DRIVEN
MULTI CHANNEL POWER AMPLIFIER
UTILIZING
T H E R M I O N I C
b
VACUUM TUBE TECHNOLOGY
B K Butler
Concept & Design:
Patented in the USA
Worldwide patents pending
"Tube Driver", "Tube Driver Blue", "Thermionic" and Blue Tube illumination appearance / method are
trademarks of or patented by
BK Butler
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Butler MULTI CHANNEL POWER AMPLIFIER TDB 5150
Summary of Contents for Butler MULTI CHANNEL POWER AMPLIFIER TDB 5150
- Page 1 A U D I O, I N C WWW.BUTLERAUDIO.COM OWNER'S INFORMATION FOR MODELS 5150 & 3150 MODULAR DIRECT-COUPLED VACUUM TUBE DRIVEN MULTI CHANNEL POWER AMPLIFIER UTILIZING T H E R M I O N I C VACUUM TUBE TECHNOLOGY B K Butler Concept &...
-
Page 2: Table Of Contents
Contents Congratulations………..…………………………………… 1 Product Description Power Output Protection………………………………………………..…… 2 Use and Operation Front Panel Power Switch Rear Panel Remote Jack………………………...…….. 3 Inputs Speaker Output Binding Posts Speaker Phasing Recommended Channel Assignment Remote Operation….…………………….……...……… 4 Specifications……….…………………………………..…… 5 Cable Quality The Marvelous Vacuum Tube………..………………. 6 Tube Reliability……………………………………………….. -
Page 3: Congratulations
Congratulations Please accept our sincere thanks and congratulations for making your musical choice Butler Audio. This new USA-Patented technology from BK Butler promises to become a classic design, just as his former efforts have in the professional music and auto sound industry. -
Page 4: Product Description
Product Description: Butler Audio Models 5150 is a vacuum tube-driven 5-channel power amplifier. Each channel Power Module is completely independent and includes separate RCA input and 5-way speaker output binding posts, vacuum tube, rectifier & filter capacitors, electronic components, protection and output power devices, etc. Butler... -
Page 5: Use And Operation
Important: Do not apply power until you have read and understand this section! Connect or disconnect cables only with amplifier OFF. Note: Your new Butler Audio multi-channel amp is designed to operate with ONE separate speaker system connected per channel. Bridging or combining channels in any manner should never be attempted. -
Page 6: Inputs
Inputs: The high-quality gold plated RCA-type input jacks will easily accept the line-level signal supplied from most pre-amplifiers. The input gain has been internally preset to equal full (150 Watts) output at 8 ohms for an input sensitivity of 1.5Volts. The input impedance is a very compliant 47K Ohms which accepts a wide range of signals without undue loading. -
Page 7: Specifications
Specifications: Models TDB-5150 & TDB-3150 Power rating, RMS: Frequency Response: Distortion (THD): Input Sensitivity S/N ratio: Slew Rate: Vacuum Tube Complement: Idling Consumption: Full Power AC Consumption: Model Power (Nominal) 5150: @ 8 Ohms 1,200 Watts @ 4 Ohms 1,800 Watts 3150: @ 8 Ohms 800 Watts... -
Page 8: Cable Quality
Without De Forest's great insight and marvelous discovery, you would probably not be enjoying your new Butler Audio amplifier! -
Page 9: Tube Reliability
Finally, the most likely reason you invested in your new Butler Audio amplifier was to enjoy the sonic superiority vacuum tubes create. Please enjoy this revolutionary design BK Butler worked so long to produce. -
Page 10: Warranty & Repair Policy
Returns must be sent prepaid via UPS/FedEx or similar carrier to facilitate any necessary tracking. The RMA number issued must be clearly marked on the outside of the shipping box. Butler Audio assumes no responsibility for damage incurred during shipping. A copy of the completed RMA form showing the assigned RMA#, signed by an authorized Butler Audio representative and a copy of the original sales receipt must accompany all returns. - Page 11 A U D I O, I N C WWW.BUTLERAUDIO.COM...
