User Quick Reference Guide
Product Name
Car Radio with Bluetooth Module
Product Models
R013- CMFB WDAB; R013- CMFB;
R013 PH2 – X07 WDAB; R013 PH2 – X07
R013 PH2 – 1DIN WDAB; R013 PH2 – 1DIN
Product description
Car Radio with Bluetooth Module is equipment installed in a car to provide in-car
entertainment and information for the vehicle occupants. It consisted of a simple
FM/AM/DAB radio, media players and Bluetooth module. User can listen to FM/AM,
DAB, USB and AUX audio by using the equipment.
Above 6 models use same Bluetooth module and same main PCB board
R013- CMFB WDAB; R013- CMFB;
Same appearance, construction, PCB and components to above two models.
R013- CMFB WDAB – with DAB
R013- CMFB – without DAB
R013 PH2 – X07 WDAB; R013 PH2 – X07
Same appearance, construction, PCB and components to above two models.
R013- PH2 – X07 WDAB – with DAB
R013- PH2 – X07 – without DAB
R013 PH2 – 1DIN WDAB; R013 PH2 – 1DIN
Same appearance, construction, PCB and components to above two models.
R013- PH2 – 1DIN WDAB – with DAB function
R013- PH2 – 1DIN – without DAB function
Technical Parameters
The supply voltage range for Nominal mode is from 8V to 16V.
The typical current consumption is less than 2A
Rated output current of USB: 2A
Radio Frequency Bands:
BT: 2400~2483.5MHz
FM: 87.5-108.00MHz
AM: 522-1611KHz
Tx Output Power:
BT: <=100mw
Software Version: V4.1.5
Hardware Version: VPJR1F-14A608-AAF
Manufacturing Factory Information
Manufacture：
Yanfeng Visteon Automotive Electronics Co.,Ltd.
Address:
300 Minolta Road Songjiang County Shanghai, China
Advertisement
Related Manuals for VISTEON R013-CMFB WDAB
Summary of Contents for VISTEON R013-CMFB WDAB
- Page 1 Rated output current of USB: 2A Radio Frequency Bands: BT: 2400~2483.5MHz FM: 87.5-108.00MHz AM: 522-1611KHz Tx Output Power: BT: <=100mw Software Version: V4.1.5 Hardware Version: VPJR1F-14A608-AAF Manufacturing Factory Information Manufacture： Yanfeng Visteon Automotive Electronics Co.,Ltd. Address: 300 Minolta Road Songjiang County Shanghai, China...
- Page 2 User Quick Reference Guide The detailed use guide for this device could be found in car user manual too. On_User Status When engine on, push POWER button will switch on radio to On_User Status OFF_User Status When the radio is power on, one push of POWER button will change the radio to OFF_User Status.
- Page 3 User Quick Reference Guide Radio Stations List Update FM list Long press on RADIO button will update FM list. List can also updated by SETUP. Browse FM list and select station When in radio source screen, rotate right knob or press it will enter FM list. Then rotate right knob to browse the list and press it to select the station.
- Page 4 User Quick Reference Guide Quick Search of Browsing List When in music play screen, press on preset #6 will start quick search feature. Rotate on the right knob clockwise will change the initial from A －Z and anti-clockwise will change from 9-0. Press on the right knob will display songs beginning with selected letter.
- Page 5 User Quick Reference Guide BT ON Status but not connect the phone If BT is ON and no BT device is connected to the radio, short press on TEL button will enter BT telephone menu with the following screen. The following operation item will be displayed in the menu: Scan devices Pair device Settings...
- Page 6 User Quick Reference Guide Devices Pairing In BT telephone menu, select “Pair device” to pair device. If the radio is already paired five devices, it reaches the max number of paired devices. In that case, the pairing will not start immediately and the following screen will be displayed: When on the Max Device screen, press the right knob to enter Max Devices Question screen: Choose YES on the question will delete a device, which will be explained in CH5.5.2.4.
- Page 7 User Quick Reference Guide Browse Phonebook In the BT telephone menu, select “Phonebook” option to enter phonebook. If the phonebook is empty, the radio displays screen as following: Or the radio will display phonebook screen. Select the contact’s name to see his phone numbers. The radio will display either of the following two screens: Press on the right knob will call the selected phone number.
- Page 8 User Quick Reference Guide Bluetooth Settings Ring Volume When the radio is on BT telephone menu, select “Settings” to enter Bluetooth settings menu. Then select “Volume” option to enter volume-setting menu to adjust default volume of ringtone and call. Rotate and push the right knob to choose Ringtone option in the volume-setting menu. And then rotate the right knob anti-clockwise to decrease volume of ringtone or clockwise to increase.
- Page 9 User Quick Reference Guide Rotate the right knob to adjust minute when the Minutes text is flashing. Then press right knob to confirm and the radio will return to Clock Setup menu. “ON/OFF” option in Clock Setup menu decides the clock display. When the option is ON status, the clock shows on the screen whether the radio is On_User Status or Off_User Status.
- Page 10 User Quick Reference Guide (This is used for R013-CMFB; R013-CMFB WDAB) Button Usage Overview Button 1~6: Short press: recall a preset station. Long press: save a radio station. TEXT button: Enable Text function Radio Button: Short Press: Select the radio waveband source: FM1, FM2, DAB1, DAB2, AM.
- Page 11 User Quick Reference Guide (This is used for R013PH2 – X07; R013 PH2- X07 WDAB) Button Usage Overview Button 1~6: Short press: recall a preset station. Long press: save a radio station. TEXT button: Enable Text function Radio Button: Short Press: Select the radio waveband source: FM1, FM2, DAB1, DAB2, AM. Long Press: Update radio list.
- Page 12 User Quick Reference Guide (This is used for R013PH2 – 1DIN; R013PH2-1DIN WDAB) Button Usage Overview Button 1~6: Short press: recall a preset station. Long press: save a radio station. TEXT button: Enable Text function Radio Button: Short Press: Select the radio waveband source: FM1, FM2, DAB1, DAB2, AM. Long Press: Update radio list.
- Page 13 User Quick Reference Guide Select Play Mode Short press on preset #1 will turn on RPT mode. Short press on preset #1 will turn on MIX mode. Press again on the preset button will revert to normal play mode Note No sufficient ventilation distance needed The use of apparatus: in tropical and moderate climates Media Players Supported...
Need help?
Do you have a question about the R013-CMFB WDAB and is the answer not in the manual?
Questions and answers
The radio is blocked and I'm not abel to put in the pin. How can I reset the device to put in the pin.
To reset the VISTEON R013-CMFB WDAB radio to enter the PIN, follow these steps:
1. In the BT telephone menu, select “Pair device.”
2. If the radio has already paired with five devices (maximum limit), it will not start pairing immediately. Instead, a "Max Device" screen will appear.
3. On the "Max Device" screen, press the right knob to enter the "Max Devices Question" screen.
4. Choose "YES" to delete a device, which will free up space to pair a new one.
5. After deleting a device, pairing can begin. The radio will display a password confirm screen or prompt to enter a PIN on the Bluetooth device.
6. Enter the PIN within 60 seconds to avoid timeout.
This process resets the pairing list and allows entering a new PIN.
This answer is automatically generated
