- Page 1 TesiraLUX IDH-1 & OH-1 OPERATION MANUAL September 2017...
- Page 2 TesiraLUX IDH-1 and OH-1 Product Description The TesiraLUX IDH-1 is an AVB/TSN enabled video encoder capable of transmitting video signals up to and including 4K60. The IDH-1 functions as a server-class device in a Tesira media system and is configured through the Tesira software. Acting as an AVB talker, the IDH-1 fully integrates digital audio and video on a single network, allowing for simplified lip sync management and transmission latencies (including scaling) of less than 2 frames.
-
Page 3: Installation
TesiraLUX IDH-1 and OH-1 Setup and Installation Setup and Use The Tesira Software provides configuration for the TesiraLUX devices in a Tesira system. The information supplied by this manual relates to front panel operation and physical connections. For more details on software setup, please consult the Tesira Help File. - Page 4 TesiraLUX IDH-1 and OH-1 Front View TesiraLUX IDH-1 and OH-1 Front Panel 1 – Ventilation fan 2 – LED status indicators 3 – Display navigation buttons 4 – OLED display Ventilation Fan Each device has a perforated cover to allow cool air into the chassis. A variable speed, temperature controlled fan allows air into the front of the unit and out of the rear left side and right side.
- Page 5 TesiraLUX IDH-1 and OH-1 Front View Display Navigation Buttons Capacitive-touch buttons allow navigation through the OLED display menu to view and configure device and networking information, as well as see system-wide faults. Navigating the display is done using touch-sensitive UP and DOWN and SELECT buttons.
- Page 6 TesiraLUX IDH-1 and OH-1 Front View System Information The system information screen shows the following information: Device audio state (on/off) • System description • Network Parameters The network parameters screen shows the following information Host name • IP address •...
- Page 7 TesiraLUX IDH-1 and OH-1 Rear View TesiraLUX IDH-1 (Rear Panel View) TesiraLUX OH-1 (Rear Panel View) 1. AC power inlet (100 – 240V) 6. Gigabit Ethernet control port (RJ-45) 2. RS-232 serial port 7. Gigabit AVB Media Port (RJ-45) 3. GPIO connections 8.
- Page 8 TesiraLUX IDH-1 Specifications IDH-1 Control Connection: RJ-45 with Ethernet cable Analog Audio Inputs: (Minimum Cat 5e) Frequency Response Media Connections: (20Hz~20kHz @ +4dBu): +0/-0.25dB 1Gb: RJ-45 with Ethernet (Minimum Cat 5e) THD+N (20Hz~20kHz) 10Gb: 10GbE SFP+ @0dB Gain, +4In: < 0.006%...
- Page 9 < 0.0035% 10Gb: 10GbE SFP+ Video Outputs: Dynamic Range Supported Resolutions: Up to 4096x2160p60 (20Hz~20kHz, 0dB): > 110dB Full mode table at Biamp.com Output Impedance (Balanced): 200Ω Physical Interfaces: HDMI Colors Space: Up to Rec. 2020 Maximum Output: +24dBu Color Formats...
- Page 10 Notes Page...
- Page 11 Notes Page...
- Page 12 Notes Page...
-
Page 13: Important Safety Instructions
To reduce the risk of fire, use only No. 26 AWG solid copper wire for telecom circuit connections. Intended for Installation and Service by Skilled Personnel Only: CAUTION – To reduce the Risk of Electric Shock, Installation and Service of Biamp Products should be conducted only by Skilled Persons who are Biamp Qualified Audio Installation Professionals. -
Page 14: Instrucciones De Seguridad Importantes
Para la instalación y mantenimiento solo por parte de personal calificado: PRECAUCIÓN – Para reducir el riesgo de descarga eléctrica, la instalación y el mantenimiento de los productos Biamp deben ser realizados por personas calificados que formen parte de los Profesionales capacitados en la instalación de audio de Biamp. -
Page 15: Consignes De Sécurité Importantes
Installation et interventions réservées au personnel compétent: MISE EN GARDE – Pour limiter les risques d’électrocution, l’installation des produits Biamp et les interventions sur ces produits doivent être réalisées uniquement par du personnel compétent faisant partie des professionnels d’installation audio qualifiés de Biamp. -
Page 16: Wichtige Sicherheitshinweise
Brandrisiko zu reduzieren. Ausschließlich für Einbau und Wartung durch geschultes Personal vorgesehen: VORSICHT – Zur Verringerung der Stromschlaggefahr sind Einbau und Wartung von Biamp-Geräten ausschließlich durch geschulte Personen, bei denen es sich um von Biamp geschulte Audio-Fachleute handelt, vorzunehmen. Führen Sie keine anderen als die in der Betriebsanleitung angegebenen Wartungsarbeiten aus, vorausgesetzt, Sie wurden hierfür geschult. - Page 17 警告 – 由市电供电的产品采用了安全接地技术，必须与正确接地的市电插座连接，才能提供接地防护。 断开设备连接 – 市电插头可用于断开 市电电源且必须保持时刻可运行状态。 小心 – 在提供了 POTS 电话接口选项时，必须由训练有素的人员将电话接口与本设备的电信回路进行连接。为减少火灾风险，只能使用 26 号 AWG 实心铜线连接电话端口。 只适用于专业技术人员来执行的安装和服务： 小心 – 为减少电击带来的风险，Biamp 产品的安装和服务应该只能由 Biamp 音频安装专业技术人员来执行。 除非您是专业技术人员，否则不能执行未包含在操作说明中的任何服务。 在打开产品之前，专业人员必须先断开交流市电电源。 小心 – “辅助电源”的安装步骤只适用于专业技术人员，而且必须遵循所有的本地法规。 • 对于美国，国家电气法规 ANSI/NFPA 70。 • 对于加拿大，加拿大电气法规第 1 部 CSA C22.1 第 2-128、12-010(3) 和 12-100 节。...
- Page 18 위험을 줄이기 위해서는 전기 통신 회로 연결은 26번 AWG 솔리드 동선만 이용하십시오. 공인 전문가의 설치 및 서비스: 주의 – 전기 충격의 위험을 줄이기 위해, Biamp 제품의 설치 및 서비스는 Biamp 공인 오디오 설치 전문가에게 의뢰해야 합니다. 전문 인력이 아닌 경우, 작업 지침에 담긴 내용 이외의 사항에 대해 서비스를 제공하면 안됩니다.
- Page 19 .لتمديدات روابط دائرة االتصاالت AWG 26 :هذا الجهاز معد للتركيب والصيانة من قبل الموظفين الماهرين فقط Biamp إال من قبل األشخاص المهرة وهم المهنيون المؤهلون تنبيه - للحد من خطر حدوث صدمة كهربائية، ينبغي أال يتم تركيب وصيانة منتجات .Biamp في...
-
Page 20: Importantes Instruções De Segurança
Destinado para Instalação e Manutenção apenas por Pessoal Qualificado: ATENÇÃO – Para reduzir o risco de choque elétrico, a instalação e a manutenção dos produtos Biamp devem ser realizadas somente por pessoas qualificadas, que são profissionais de instalação de áudio qualificados da Biamp. -
Page 21: Важные Инструкции По Технике Безопасности
одножильный медный провод типа 26 AWG. Предназначено для установки и обслуживания только опытным персоналом ПРЕДОСТЕРЕЖЕНИЕ! Для снижения риска поражения электрическим током установку и обслуживание устройств Biamp должны выполнять только лица, которые являются опытными специалистами по установке аудиосистем Biamp. Не проводите какое-либо обслуживание, помимо указанного в инструкциях по эксплуатации, если вы не обладаете соответствующим опытом и... - Page 22 CAUTION – changes or modifications not approved by Biamp could void the user’s authority to operate the equipment...
-
Page 23: Rohs Compliant
RoHS COMPLIANT This Biamp product, including all attendant cables and accessories supplied by Biamp, meets all requirements of EU Directives 2011/65/EU on the restriction of the use of hazardous materials. An EU RoHS Materials Content Declaration document may be obtained at www.biamp.com (This information is presented to comply with the requirements of Chinese law SJ/T11363-2006) 有害物质表... - Page 24 The Warranty Period for the products described in this manual shall be five (5) years. The Warranty Period begins (a) the date of the original end user’s purchase from an authorized Biamp Systems dealer or (b) six months after the product is first shipped from Biamp Systems’...
