Montech SH Operating Instructions Manual

Protective hood
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Safety Devices
OPERATING INSTRUCTIONS
Protective hood: SH
Edition:
BA-100025
03/2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SH and is the answer not in the manual?

Questions and answers

Summary of Contents for Montech SH

  • Page 1 Safety Devices OPERATING INSTRUCTIONS Protective hood: SH Edition: BA-100025 03/2008...

  • Page 2: Table Of Contents

    Contents Important information EC Declaration of Conformity (CE) .........1 Scope of these instructions.............2 Technical data and hints on use ..........3 Commissioning Transport guards ..............4 Handling the pillars of the hoods ...........5 Mounting the hood ...............6 Rigidity of the hood ..............6 Mounting the panes ..............7 Hood with reinforcing struts...........8 Hood with cover ..............8...

  • Page 3: Ec Declaration Of Conformity (Ce)

    “Technical data and hints for use”. Additional information The aim of the present User Manual is to enable users to employ the protective hood SH correctly and safely. Should further information be required in relation to your particular application, please contact the manufacturer.

  • Page 4: Scope Of These Instructions

    Important information Fig. 1-1: Description of type plate Reference number Product name Serial number Montech AG Management U. D. Wagner C. Wullschleger Validity of the User Manual Our products are continually updated to reflect the latest state of the art and practical experience. In line with product developments, our User Manuals are continually updated.

  • Page 5: Technical Data And Hints On Use

    Important information Technical Data and Hints for use Nominal stroke (mm) Own weight per pillar (kg) Attached weight per pillar (kg) Torque M xz max. (Nm) M yz max. (Nm) Permissible number of opening and closing strokes with an attached load of 20-25 kg per pillar 30/h Ambient temperature...

  • Page 6: Commissioning

    Commissioning Transport Guard In the state as delivered, every pillar of the protective hood is locked in its clo- sed position by transport guard elements, which prevent the supporting spars (20, Fig.16) from being moved. Every time a hood is transported these guards must be fitted to secure the moving parts.

  • Page 7: Handling The Pillars Of The Hoods

    Commissioning Handling the pillars of the protective hood Fig. 3 Ring screw M8, DIN 580 10 (Fig. 16) 300 (Fig. 16) To transport the pillar a ring screw as per Fig.3 should be screwed into the tapped hole provided (10, Fig. 16). The weight of the pillar is shown on the nameplate (300, Fig.16).

  • Page 8: Mounting The Hood

    Commissioning Mounting the Hood Since the hood stands on only two pillars, it must be secured by appropriate means to prevent it toppling. Optimal stability is obtained with a structure in which the pillars of the hood are integral parts of the machine support. Fig.4 to 6 show examples of sup- ports made of Quick-Set fixing elements.

  • Page 9: Mounting The Panes

    Commissioning Mounting the Panes Fig. 4 502614 505006 43943 20 (Abb. 16) 20 (Fig. 16) 44633 44633...

  • Page 10: Hood With Reinforcing Struts

    Commissioning Hood fitted with strengthening struts Fig. 5 45327/… 505006 504381 Hood with cover 502614 Fig. 6 43943...

  • Page 11: Actuating The Hood With The Framing Profile

    Commissioning Actuating the pane at the framing profile If framing profiles are provided and mounted as shown in Fig.4, they may be used to actuate the pane as in Fig.7. Fig. 7...

  • Page 12: Equalizing Weights

    Commissioning Equalizing Weights With the equalizing weights (43532, Fig. 16) a balance is obtained between the mass of the hood and that of the counterweights. Once a state of equilibrium has been reached, the hood can be set to any desired position only by the application of an external force.

  • Page 13: Altering The Equalizing Weights

    Commissioning • Move the hood only so far that the upper edge of the weights is roughly in the middle of the opening. • Remove equalizing discs singly by hand or insert them with the slit forwards (as in Fig.16). After an insertion or removal check whether the hood does stand still in any desired position.

  • Page 14: Mounting The Safety Switch

    Commissioning Mounting the safety switch A safety switch must be mounted on one of the two pillars of each hood (as per Fig.23). The safety limit switch (10, Fig.23) is fixed to a plate (20, Fig.23) with screws (50, Fig.23). The plate with the safety switch can be fixed with the clamping element (40, Fig.23) either to the external dovetail of the pillar (50, Fig.16) as shown in Fig.10, or to the external dovetail of a strut perpendicular to the pillar (50, Fig.16) in a suitable position as shown in Fig.11.
  • Page 15 Commissioning Fig. 11 The safety switch must be positioned so that the actuating arm engages in the slit in the switch housing when the hood is closed, thereby actuating the switch. The safety switch must be electrically connected so that the hazardous device is switched off at once when the hood is opened and cannot be switched on again before the hood is closed.

  • Page 16: Drop Guard

    Commissioning Drop Guard The drop guard prevents the hood from dropping down if the belt (40, Fig.16) or its mounting (110, 140, Fig.16) breaks. If the tensile force of the counterweight transferred by the belt to the bracket (20, Fig.24) becomes ineffective for any of the reasons given, he energy stored in the two springs (50, Fig.24) forces the bracket downwards.This movement actuates the two pawls (30 and 40, Fig.24), which immediately engage in the dovetail of the pillar (50, Fig.16).

  • Page 17: Retrofitting Of Drop Guards

    Commissioning Retrofitting of Drop Guards Retrofitting of drop guards may only be carried out by qualified persons. On both pillars the holder (70, Fig.16) has to be replaced by a drop guard. Procedure: • Lower the hood as far as the stop. •...
  • Page 18 Commissioning • Push the assembly aid (45459, Fig.12) with the pins first into the holes (10 mm dia.) of the drop guard support until resistance is encountered. • Press the assembly aid further against the spring pressure, until the plate of the aid is against the support of the drop guard.
  • Page 19 Commissioning Fig. 13 10 (Fig. 16) 10, Abb. 16 45515...
  • Page 20 Commissioning • By slackening and turning out the screws (150, Fig.16), remove the holder (70, Fig.16) and bushes (80, Fig.16) from the supporting spar (20, Fig.16). • By slackening and turning out the countersunk screws (140, Fig.16), remove the holder (110, Fig.16) from the belt. •...
  • Page 21 Commissioning After mounting the drop guards • Remove the holding devices (45515 Fig.13) from the belt. For this purpose, the synchronous shaft must be pressed about 10 mm away from the bearing block (10, Fig. 16) as when mounting the holding devices, and the shaft (30, Fig.

  • Page 22: Maintenance

    Maintenance Replacing the Belts Material: Chlorbutadiene elastomer CR (Polychloroprene) with steel strands The belts are highly resistant to the weather and ozone, also to acids and alka- lis as well as to most oils, but are not resistant to aromatics. For closer details see ISO 1817.

  • Page 23: Adjusting The Play Of The Guide Rollers

    Maintenance Adjusting the play of the guide rollers To eliminate undesired play from the guides, proceed as follows: • Having loosened and turned out the panhead screw (260, Fig.19), remove the cover (220, Fig.19) by pushing upwards out of the groove in the suppor- ting spar (10, Fig.19).
  • Page 24 Maintenance Fig. 15 1 Box spanner (19 mm) 2 Allen key (6 mm, long type) 3 Open-ended spanner ø 40...

  • Page 25: Spare Parts Lists Showing Materials And Suppliers Supporting Spar Left/Right

    Parts Lists Crossbar left/right (Fig.16) 47951 43532 0,5 kg 45337 43279 43280 43205 43538...
  • Page 26 Parts Lists Supporting spar Fig.17 left 1 right 1 No. Part Ref. No. Ref No. left right Bearing block 44302 44306 Spar profile assembled 44303 44303 Guide roller holder 49101 49101 Belt with holder 44305 44305 Pillar TP-96 48411N 48411N Clamping element SLL-20 41190 41190...
  • Page 27 Supporting spar Fig.18 left 2 right 2 Ref No. Ref. No. Supplier Material Remarks left right 44306 44302 Montech AG see Fig. 21 44303 44303 Montech AG see Fig. 19 49101 49101 Montech AG see Fig. 20 44305 44305 Montech AG see Fig.

  • Page 28: Mounting The Supporting Spar Profile

    Parts Lists Supporting spar profile assembled (Fig.19)
  • Page 29 Parts Lists No. Part Ref. No. Supplier Material Supporting spar 43492 Montech AG Aluminium Stop 43948 Montech AG Steel Buffer 43949 Montech AG Plate 44590 Montech AG Steel Countersunk screw 501825 M6 x 12 Steel Rivet nut 502614 Bossard AG...

  • Page 30: Guide Roller Holder

    Parts Lists Guide roller holder (Fig.20)
  • Page 31 Parts Lists No. Part Ref. No. Supplier Material Plate 49099 Montech AG Steel Bush 43170 Montech AG Steel Eccentric 43171 Montech AG Steel Bush 43172 Montech AG Steel Roller 49100 Montech AG Deep-groove ball bearing 504790 6002.2 RSR Steel Cheesehead screw...

  • Page 32: Bearing Pedestal Left/Right

    Parts Lists Bearing block left/right (Fig.21) (60) (30)
  • Page 33 Parts Lists No. Part Ref. No. Supplier Material Bearing block 43189 Montech AG Synchronous wheel 44356 Montech AG Aluminium Shaft 48070 Montech AG Steel Bush 43220 Montech AG Steel Deep-groove ball bearing 503582 6001.2RS Steel 503604 Bossard AG Steel Circlip...

  • Page 34: Belt With Holder

    Parts Lists Belt with holder (Fig.22) No. Part Ref. No. Supplier Material Holder 44350 Montech AG Aluminium Toothed belt 44351 Montech AG Holder 46690 Montech AG Aluminium Countersunk screw 501801 Bossard AG Steel...

  • Page 35: Safety Switch

    505405 506400 Miscell. Miscell. Ditto currentless released 505406 506401 Miscell. Miscell. 20 Baseplate 47048 48361 Montech AG Aluminium 30 Plate 47050 Montech AG Aluminium 40 Clamping element SLL-55 40201N 40201N Montech AG Alu/Steel 50 Cheesehead screw 503785 505900 Bossard AG...

  • Page 36: Drop Guard

    Parts Lists Drop guard (Fig.24) No. Part Ref. No. Supplier Material Support 43167N Montech AG Aluminium Bracket 46691 Montech AG Aluminium Pawl right 43164 Montech AG Steel Pawl left 43165 Montech AG Steel Compression spring 504765 Gutekunst & Co Steel...

  • Page 37: Accessories For The Hood

    Parts Lists Accessories for Protective Hoods Part Ref. No. Supplier Material Rem. Synchronous shaft 47951 Montech AG Aluminium Fig. 16 Equalizing weight, 2.5 kg 45337 Montech AG Steel Fig. 16 Equalizing weight, 5 kg 43279 Montech AG Steel Fig. 16...

  • Page 38: General Notes

    General Notes Environmental Compatibility and Disposal Materials used • Aluminium • Steel • ABS Acrylnitrile butadiene-styrol • Acryl-nitrile butadiene rubber (NBR to ISO 1629) • CR Polychloroprene • PE Polyethylene • PMMA Polymethyl methacrylate (Atulex) • POM Polyoxymethylene (polyacetal) • PP Polypropylene •...
  • Page 39 MONTECH AG Gewerbestrasse 12, CH-4552 Derendingen Fon +41 32 681 55 00, Fax +41 32 682 19 77 info@montech.com, www.montech.com...
