- Page 1 Junior Racer RTF Quick start manual...
- Page 2 Install Battery................4.1 Power On.................... 4.2 Binding ....................4.3 Power Off..................4.4 Charge....................4.5 red when charging ................4.6 NVISION VTX....................5 Description ..................5.1 Wiring....................5.2 Junior Racer Whoop Drone include 1x Junior Racer(with Frsky XM+ Receiver) 1x Radio(support Frsky XM+)
- Page 3 Operate Junior Racer Whoop Drone *Power On/Off: connect the power cable of to Junior Racer 75 the battery, the power LED, receiver LED and FC LED are on, then the FC LED flashes and the receiver LED turns off. After using, unplug the connection, and all LED will turn off.
- Page 4 LED Status Reason solution Power LED off 1.Insufficient battery 2.FC is 1. Charge the battery 2. broken Replace the FC FC LED off and Receiver LED FC is broken Replace the FC solid FC LED flashes Bule at high Out of control or BB ringing There are many reasons, frequency mode enabled...
- Page 5 Operate the radio ·Install Battery: remove the back cover of the transmitter, connect the battery inside to the power interface correctly, and install the back cover. ·Power On: Long press the power button for about 3 seconds, then pull the throttle to the lowest position, release the button after the radio vibrates twice, and the power indicator turns from green to blue, indicating that the radio is turned on.
- Page 6 *Dipole whip high sensitivity antenna. It is mounted to the VTX board durable. *Output power: 0mW, 25mW and 200mW (adjustable) *Power supply voltage: 5V. Does not support direct connection to 1S battery *Weight: 2.0g *Frequency: 5.8GHz 6 frequency band 48 channels, competition frequency band: 5362~5945MHz Component Layout Diagram for NVISION A01 VTX:...
- Page 7 How to Change Frequency & Channel & Power Only support frequency and power change through the SmartAudio interface. Method 1: Use the OSD menu. Enter the OSD menu by radio transmitter sticks ( Pitch Stick UP and Yaw Stick Left). Then FEATURES ->...
- Page 8 Method 2: Use the Betaflight GUI command. We could also use the Betaflight CLI commands to change the frequency and power of the VTX. For example, set the frequency to 5865 and power to 200mW ( 1 for 25mW / 2 for 200mW);...
- Page 9 TRANSMISSION FREQUENCY TABLE This A01 VTX could support 3 frequency table according to your local law. The tables below is for all the frequency is valid. USA frequency table bleow. The frequency in red item is invalid. Europe frequncy table below. The frequency in red item is invalid.
