Sony CDX-R3000 Product Manual

2004 SONY MOBILE
PRODUCT GUIDE
CDX-R3000
FM/AM Compact Disc Player
Audio Power Specifications
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
23.2 watts per channel minimum continuous average power into 4 ohms, 4 channels driven from 20 Hz to 20 kHz with no more than 5%
total harmonic distortion
CD Player Section
Signal-to-noise ratio
Frequency Response
Stereo Separation
Total Harmonic Distortion
Tuner Section
FM
Tuning Range
Antenna Terminal
Intermediate Frequency
Usable sensitivity
Selectivity
Signal-tp-noise ratio
Harmonic distortion at 1 kHz
Separation
Frequency response
Power Amplifier Section
Outputs
Speaker impedance
Maximum power output
General
Preamp Output Level
Preamp Impedance
Outputs
Tone controls
Power requirements
Dimensions
Mounting dimensions
Mass
Supplied accessories
Optional accessories
Note
This unit cannot be connected to a digital preamplifier or an equalizer
which is Sony BUS system compatible.
Design and Specifications subject to change without notice.
120 dB
10 - 20,000 Hz
85 dB
0.01%
87.5 - 107.9 MHz
External antenna connector
10.7 MHz/450 kHz
9 dBf
75 dB at 400 kHz
67 dB (stereo), 69 dB (mono)
0.5% (stereo), 0.3% (mono)
35 dB at 1 kHz
30 - 15,000 Hz
Speaker outputs (sure seal connectors)
4 - 8 ohms
52 W x 4 (at 4 ohms)
2 Volts
220 ohms
Audio outputs (rear/sub selectable)
Power antenna relay control terminal
Power amplifier control terminal
Antenna input terminal
Low: ±10 dB at 60 Hz (XPLOD)
Mid: ±10 dB at 1kHz (XPLOD)
High: ±10 dB at 10kHz (XPLOD)
12 V DC car battery (negative ground)
Approx. 178 x 50 x 179 mm
(7 1/8 x 2 x 7 1/16 in.) (w/h/d)
Approx. 182 x 53 x 161 mm
(7 1/4 x 2 1/8 x 6 3/8 in.) (w/h/d)
Approx. 1.2 kg (2 lb. 10 oz.)
Parts for installation and connections
Front panel cover (1)
Card Remote Commander (RM-X114)
• Motion Blade retractable
faceplate
• Rear/Sub selectable preout
w/LPF
• Detachable faceplate
• EQ3
• 52W x 4 high power
• Drive-S
• 8fs, 1-bit D/A converter
AM
Tuning Range
Antenna Terminal
Intermediate Frequency
Sensitivity
Pin Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
• 45 degree install
• CD/CD-R/CD-RW playback
• SSIR-EXA tuner
• 18FM + 12AM memory presets
• White 13-segment LED display
• Red key illumination
• Optional wireless card remote
(RM-X114)
530 - 1,710 kHz
External antenna connector
10.7 MHz/450 kHz
30 µV
Harness Plug Configuration
3 5 6
1 2 4
9 10 11 12 13 14 15 16
Plug shown with wires facing viewer
Wire Color Description
White Left front +
Green Left rear +
Purple Right rear +
Gray Right front +
Blue/white AMP Remote
Blue ANT Remote
Red Accessory
Black Ground
White/black Left front -
Green/black Left rear -
Purple/black Right rear -
Bray/black Right front -
Sky blue ATT
Orange/white Illumination
Yellow Battery
8
7
