Page 1 Welcome Congratulations on your purchase of this Sony VAIO computer, and welcome to the online VAIO Computer User Guide. ® ® This user guide provides detailed information on all aspects of using your new VAIO computer, from keyboard functions to preinstalled software programs.
Page 2: Powering Your Computer
Powering Your Computer Your VAIO computer comes with a battery and an AC adapter. This chapter explains how to install and use these supplied ® accessories to power your computer. It also describes ways you can efficiently utilize the battery as a power source. ...
Page 3: Using Ac Power
Using AC Power The supplied battery is not charged when you receive your computer. To use your computer immediately, use the supplied AC adapter as the power source. While the computer uses AC power it automatically charges the battery if it is inserted. Using the Battery for more information on installing and using your battery.
Page 4 Connecting the AC adapter To connect the AC adapter Plug the cable attached to the AC adapter into the DC IN port on your computer. Connecting the AC Adapter to the Com puter Plug one end of the power cord into the AC adapter, and plug the other end into an AC outlet. Use only the AC adapter supplied with your computer.
Page 5 Turning on the computer To turn on the computer Slide the OPEN switch to the right, and lift the cover while holding the bottom of the computer firmly. Opening the Com puter Press the power button until the power indicator turns on. Turning on the Com puter If you hold the power button down, the computer turns off.
Page 6: Using The Battery
Using the Battery A battery is an auxiliary power source you can use when your computer is not plugged into an AC outlet. Your computer may come equipped with one or two battery bays, depending on the model you purchased. If your computer comes with two battery bays, you can purchase a second rechargeable battery to extend your computing time.
Page 7 Inserting a battery To insert a battery Push the battery bay cover down to open it. The battery bay cover swings out but does not detach from the computer. Opening the Battery Bay Slide the battery into the battery bay. If the computer is on, it automatically detects the battery. Inserting a Battery Push the battery bay cover up until it clicks into place.
Page 8 Removing a battery If you are not using the computer for an extended period of time, remove the battery from the computer to avoid damaging the battery. You can remove the battery when the computer is on or off. If the computer is on, connect the AC adapter and exit a power saving mode before you remove the battery. To remove a battery Push the battery bay cover down to open it.
Page 9 Using a second battery To insert a second battery If another device is in the multipurpose bay, remove that device. Insert the battery into the multipurpose bay. When the computer uses the second battery, the Battery 2 indicator turns on. Inserting the Second Battery Slide the weight saver in the direction of the arrow until it clicks into place.
Page 10 Displaying battery information You can display the remaining battery charge on the Battery Information toolbar and/or the Battery Information window. To display the Battery Information toolbar Right-click the center of the Windows Select Toolbars from the shortcut menu, and click Battery Information. The Battery Information toolbar appears on the taskbar.
Page 11  Battery tab — Displays the total charge remaining in the battery. You can click Advanced for specific information on the battery.  Alarms tab — Displays the alarm settings, which notify you when the battery is fully charged or too low. You can change your computer's alarm settings on this window.
Page 12 Charging a battery You will need to charge the battery if battery power drops below 10 percent or you have not used the battery for a long time. The lithium-ion battery supplied with your computer may be recharged at any time, whether you wait until the battery is completely or partially discharged.
Page 13 Notes on batteries  Never leave the battery in temperatures above 140°F (60°C), such as under direct sunlight or in a car parked in the sun.  While the battery is in use or being discharged, the battery heats up. This is normal and is not cause for concern. ...
Page 14 Frequently asked questions How do I know when the battery is charged? To determine the remaining battery charge, see When is the computer using AC power? When the computer is directly connected to the AC adapter, it uses AC power, even if a battery is installed. When should I recharge the battery? ...
Page 15: Conserving Battery Power
Conserving Battery Power You may use the power saving modes and PowerPanel significantly extend your computing time, depending on how you use your computer.  Using power saving modes  Using PowerPanel utility  Frequently asked questions utility to conserve battery power. Conserving battery power may Page 15...
Page 16 Using power saving modes In addition to the normal operating mode, which allows you to turn off specific devices, your computer has two distinct power saving modes: Standby and Hibernate. Use the Standby and Hibernate power saving modes to override a profile setting or initiate an immediate action.
Page 17 Using PowerPanel utility The PowerPanel utility enables you to select and customize a predefined power management profile to conserve battery life. The following table describes all the predefined power management profiles in PowerPanel. Your computer is set to Automatic Profile Selection by default. You can customize the settings for all the following profiles, except the Disable Power Management profile.
Page 18 Do not choose the Automatic Profile Selection when connected to AC power. To select a profile Right-click the Battery icon on the Windows taskbar. See icon descriptions. Select Profiles, and click the profile on the shortcut menu. The profile settings are implemented instantly. See Using PowerPanel utility for descriptions of available profiles.
Page 19 HDD Standby Timer Controls the time it takes the system to switch the hard disk drive to Standby mode when the system is idle. This setting only turns off power to the hard disk drive. i.LINK Port Controls the power supply to the i.LINK port. You can disable power to the i.LINK port to conserve power. Memory Stick Port Power-saving Controls the power supply to the Memory Stick slot.
Page 20 Frequently asked questions Can my computer enter Hibernate mode while using battery power? Your computer can enter Hibernate mode while using battery power, but some software programs and peripheral devices prevent the system from entering Hibernate mode at all. If you are using a program that prevents the system from entering Hibernate mode, save your data frequently.
Page 21: Internet And Network Connections
Internet and Network Connections  Internet Connections  Network Connections  Connecting Another VAIO Computer Page 21...
Page 22: Internet Connections
Connection Wizard guides you through the process of connecting to the Internet and choosing an Internet service provider (ISP) or setting up an existing account. When you connect to the Internet, you can register your VAIO services, and gain access to Sony Computing Support. ...
Page 23 Setting up a dial-up Internet connection Before you can connect to the Internet, you need to connect your computer to a telephone line via a telephone cable (not supplied). Once you have set up your telephone cable, you're ready to connect to the Internet. To connect a telephone cable Locate the Modem jack on your computer.
Page 24 Setting up an Ethernet Internet connection Your computer accommodates both 10BASE-T and 100BASE-TX Ethernet connections, with data transfer speeds of between 10 and 100 Mbps, depending on the line conditions and Ethernet cable. To connect an Ethernet cable Locate the Ethernet port on your computer. For location information, see Locating Ports and Controls in the Setting Up chapter of your printed VAIO Connecting an Ethernet Cable Plug one end of the Ethernet cable into your computer's Ethernet port...
Page 25 Click to select the Automatically detect settings check box. Click to select the Use automatic configuration script, and type an address in the Address box. Click OK. Page 25...
Page 26 Customizing your Internet connection The Internet Properties dialog box enables you to change the way you view the Internet. You can change your home page, fonts, language, and colors. You can also regulate content and set your browsing preferences. To open the Internet Properties dialog box Click Start, point to Settings, Control Panel, and click Internet Options.
Page 27  Make sure the telephone number the program is dialing is correct.  Make sure the software you are using is compatible with the computer's modem. (All preinstalled Sony programs are compatible.)  If you are still experiencing problems, use the supplied Application Recovery CD(s) to reinstall the modem driver software.
Page 28: Network Connections
Network Connections With a Sony computer, you can easily set up or connect to a variety of networks. The Network Connection Wizard makes it easy to gain access to remote and local area networks (LANs) using wireless, Ethernet, or dial-up connections.
Page 29 Using Ethernet and dial-up connections Local area networks (LANs) comprise a group of computers and associated devices within a small geographic area, such as a home or office building. For setting up LANs, Ethernet is a widely installed technology. Your computer accommodates both 10BASE-T and 100BASE-TX Ethernet connections, with data transfer speeds of between 10 and 100 Mbps, depending on the Ethernet cable.
Page 30 A wireless local area network (LAN) is a network in which you can connect to a LAN through a wireless (radio) connection. You can opt to purchase a Sony Wireless LAN Access Point to set up a LAN. The Wireless LAN Access Point is designed for building a wireless LAN environment. Because a wireless LAN configuration requires no wiring, you can operate multiple computers more freely than ever before.
Page 31 Click Next. If the network was not set up with an encryption key, then click Next. Add/Edit Configuration Profile Window Select a power management option, and click Next. 10. Click to select the Renew IP Address when selecting this profile check box, so you don't have to type the IP Address every time you want to connect to the network.
Page 32 Click to select the Enable Data Security check box. Select either Use Alphanumeric Characters or Use Hexadecimal. Type a five-character encryption key in the Key 1 box using either alphanumeric or hexadecimal characters, depending on your selection in the previous step. Make sure Key 1 appears in the Encrypt data with box.
Page 33 Click Next. Set up an encryption key, so only the individuals to whom you give the encryption key can gain access to the network: Click to select the Enable Data Security check box. Select either Use Alphanumeric Characters or Use Hexadecimal. Type a five-character encryption key in the Key box using either alphanumeric or hexadecimal characters, depending on your selection in the previous step.
Page 34 Checking your network connection status To check the status of your network connection  Click Start on the Windows taskbar, and point to Programs, ORiNOCO, and click Client Manager. The Status box ® shows information about your network connection. Page 34...
Page 35 Wireless LAN communication occurs on divided frequency bands known as channels. Third-party Wireless LAN Access Point channels may be preset to different channels from Sony devices. If you are using a Wireless LAN Access Point, refer to connectivity information contained in your access point instructions.
Page 36: Connecting Another Vaio Computer
N K is a trademark of Sony us ed to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Page 37: Frequently Asked Questions
N K is a trademark of Sony us ed only to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Page 38: Cds, Dvds, And Optical Drives
CDs, DVDs, and Optical Drives  Inserting and Ejecting CDs or DVDs  Copying and Playing CDs  Copying and Playing DVDs Page 38...
Page 39: Inserting And Ejecting Cds Or Dvds
Inserting and Ejecting CDs or DVDs Avoid using adhesive labels to identify your CDs or DVDs. Adhesive labels may damage the optical drive if they come off while the disc is in the drive. To insert a CD or DVD Turn on the computer, and exit a power saving mode (Standby or Hibernate) if one is active.
Page 40 Lift the disc from the drive. Push the drive tray gently to close it. Page 40...
Page 41: Copying And Playing Cds
Copying and Playing CDs Your optical drive can read CDs and DVDs. The type of optical drive installed in or connected to your computer may vary, depending on the model you purchased. If you are using a CD-RW/DVD drive, you can write data to CD-Rs and CD-RWs. ...
Page 42 Playing CDs Before you play an audio CD, you may need to enable your computer's audio feature. To enable the audio feature Click Start, and point to Settings, Control Panel, and then click System. The System Properties window appears. Select the Hardware tab, and click Device Manager in the Device Manager box. A window with a listing of the computer's hardware devices appears.
Page 43 Copying files to a CD-RW or CD-R Before you write data to a CD-RW or CD-R, read the following notes to avoid a computer malfunction and ensure the best writing results:  Deactivate the screen saver and exit anti-virus software. ...
Page 44 Frequently asked questions How do I maintain CDs and DVDs?  Avoid touching the surface of the disc with your fingers. Fingerprints and dust on the surface of the disc may cause reading errors.  To clean the disc, hold the edge of the disc, and use a soft cloth to wipe the surface from the center out. If the disc is badly soiled, moisten a soft cloth with water, wring it out well, and use it to wipe the surface of the disc from the center out.
Page 45  Double-click the listed optical drive. The Properties window appears.  Click the Properties tab, and click to select the Enable digital CD audio for this CD-ROM device check box. Why did the computer screen (LCD) go blank?  Your computer screen may go blank if the computer has lost power or is in a power saving mode (Standby or Hibernate).
Page 46: Copying And Playing Dvds
Copying and Playing DVDs The type of optical drive installed in your computer may vary, depending on the model you purchased. Computers equipped with a CD-RW/DVD drive can play DVDs and can read most DVD-R media. Computers equipped with a DVD-RW drive can play and copy files to DVDs.
Page 47 Playing DVDs You can play a DVD on your computer or TV. If you watch DVDs on your computer, use either the AC adapter or the supplied battery for power. To play a DVD on the computer using AC power Close all open programs.
Page 48 Switch the TV input channel to external input. See the guide that came with your peripheral device for more information on its installation and use. Disable the screen saver and the virus checker. Select a display. Press the Fn+F8 key combination to select either the computer screen (LCD) or an external display. Selecting a display mode The Fn+F8 key combination will not work once a DVD is inserted into the optical drive.
Page 49 Disconnecting the TV from the computer Simply unplug the audio-video (AV) cable from the A/V OUT jack on the computer. Page 49...
Page 50 You can copy files to a DVD-R or DVD-RW if your computer is equipped with a DVD-RW drive. Use the DVD-RW drive and the preinstalled Click to DVD or Drag'n Drop CD/DVD program to create your own DVDs. The Sony Click to DVD program is ideal for creating full-featured video DVDs, and the Drag'n Drop CD/DVD program is ideal for creating data DVDs.
Page 51 Frequently asked questions How do I maintain CDs and DVDs?  Avoid touching the surface of the disc with your fingers. Fingerprints and dust on the surface of the disc may cause reading errors.  To clean the disc, hold the edge of the disc, and use a soft cloth to wipe the surface from the center out. If the disc is badly soiled, moisten a soft cloth with water, wring it out well, and use it to wipe the surface of the disc from the center out.
Page 52  Make sure the digital CD audio is enabled for your optical drive. Follow these steps:  Click Start on the Windows Properties window appears.  Select the Hardware tab, and then click Device Manager. The Device Manager window appears. ...
Page 53: Printer Connections
Printer Connections  Printing With Your Computer Page 53...
Page 54: Printing With Your Computer
Printing With Your Computer You can connect a universal serial bus (USB) printer or a parallel port printer to your computer. To print properly, the printer you connect must be compatible with the Microsoft  Connecting a printer  Disconnecting a printer ...
Page 55 Connecting a printer Your computer is compatible with many popular printers. The New Hardware Wizard guides you through the software installation process. Some printers require separate driver software installation. See the instructions that accompanied your printer for more information. If you cannot print once you have connected your computer to your printer, see asked questions in this section for more information.
Page 56 See the manual that came with the parallel port printer for more information on its installation and use. Page 56...
Page 57 Disconnecting a printer You can disconnect a USB or parallel printer when the computer is on or off. Disconnecting a printer when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. To disconnect a printer ...
Page 58 Select the Ports tab, and select a different LPT Port Number.  You may need to enable the computer's printer port. Click Start, and point to Settings and Control Panel, then click Sony Notebook Setup. The Sony Notebook Setup window appears. Click the Device tab.
Page 59: Computer Features
Computer Features  Using the Keyboard  Using the Touch Pad  Using Jog Dial Control  Using Memory Stick Media  Changing the Window Design of Sony Programs Page 59...
Page 60: Using The Keyboard
Using the Keyboard Your keyboard is very similar to a typewriter's, but your computer keyboard has additional keys that perform specific computer-related tasks.  Key locations and descriptions  Combinations and functions with the Windows key  Indicators  Combinations and functions with the Fn key Page 60...
Page 61 Key locations and descriptions Keyboard Description Numeric keypad Contains the keys found on a typical calculator. Use the numeric keypad area to type numbers or to perform mathematical calculations such as addition and subtraction. Numbers appear on the front beveled edge of the numeric keys.
Page 62 Combinations and functions with the Windows key Combination Function + F1 Displays the VAIO Help and Support Center window. + Tab Switches the selected button on the taskbar. Displays the desktop. Displays the My Computer window. Displays the Search Results window, where you can find a file or folder. This is the equivalent of selecting Search from the Start menu.
Page 63 Indicators Indicator Function Power Lights up when the power to the computer is on, blinks in Standby mode, and turns off when the computer is in Hibernate mode or off. Battery Lights up when the computer is using battery power, blinks when the battery is running out of power, double-blinks when the battery is charging.
Page 64 Combinations and functions with the Fn key If you switch user identities during a computing session, the Fn+F7 key functionality (if available on your computer) will be interrupted. To switch to an external display or monitor, see Combinations/ Feature Function Fn + (F3) Mute On/Off...
Page 65 Fn + B Bass Boost Toggles the bass-boost function off and on. This feature is available only while using headphones. You can also carry out these functions using the Jog Dial Control. Some functions are not available until the Windows operating system launches.
Page 66: Using The Touchpad
Using the Touch Pad The keyboard contains a pointing device called a touch pad. You can point to, select, drag, and scroll objects on the screen using the built-in touch pad.  Describing the touch pad  Customizing the touch pad ...
Page 67 Describing the touch pad Locating and Describing the Touch Pad Action Description Point Slide one finger on the touch pad to place the pointer on an item or object. Click Press the left button once. Double-click Press the left button twice. Right-click Press the right button once.
Page 68 Customizing the touch pad Sony Notebook Setup lets you customize your touch pad, such as enable or disable the touch pad. You can also open the Mouse Properties dialog box, which enables you to set your touch pad and mouse preferences, such as changing pointers, enabling or disabling the tapping feature, clicking both buttons simultaneously, and adjusting the touch pad speed.
Page 69 Press Enter. Press R to select restart. , and then press P to open the Programs menu. key to select Sony Notebook Setup, and press Enter. to select the Device tab. and the E keys. The My Computer window appears.
Page 70  If you still cannot restart your computer, press and hold the power button for more than four seconds to turn off the computer.  If the pointer does not move while playing a disc, press Ctrl+Alt+Delete simultaneously to stop playback and restart the computer.
Page 71: Using Jog Dial Control
Using launcher mode  Using guide mode  Using the Jog Dial control with Sony programs  Using the Jog Dial control with other programs Control, which enables you to open a program, folder, or document from a Page 71...
Page 72 Using VAIO Action Setup VAIO Action Setup manages the settings for your computer's Jog Dial Control interface and enables you to set a timer to launch a program or document. For more information on customizing the Jog Dial control or setting the timer, right-click the Jog Dial Control icon in the taskbar and click Help Topics.
Page 73 Locating the Jog Dial Control Jog Dial Control Page 73...
Page 74 Using launcher mode The Jog Dial Control window is either in the launcher mode or in the guide mode. The Jog Dial Control window is in launcher mode until a software program is launched or the Jog Dial Control window becomes active. When an arrow is displayed next to an item in the Jog Dial Control window, you can display a submenu of that item by selecting it and pressing the Jog Dial control.
Page 75 Depending on the program, you can select items from the Jog Dial Guide window using the Jog Dial control. With some Sony programs, you can change the Jog Dial window to List View, Simple Menu, and Full Menu. For more information, right-click the Jog Dial Control icon , and click Help Topics.
Page 76 Using the Jog Dial control with Sony programs If Sony programs that support the Jog Dial Control are active, you can use the Jog Dial's functions that are allocated to that program. For more information, click Start, Settings, Control Panel, Jog Dial, and click Help on the VAIO Action Setup window.
Page 77 Using the Jog Dial control with other programs If the program you are using does not support the Jog Dial control, you can still select menu items to perform the following functions:  Maximize window  Minimize window  Close window ...
Page 78: Using Memory Stick Media
Using Memory Stick Media This compact, portable, and versatile recording medium has a data capacity exceeding that of a floppy disk. The medium is specially designed for exchanging and sharing digital data with compatible products. Because it is removable, the media can be used for external data storage.
Page 79 Selecting Memory Stick media The following two types of Memory Stick media can be used with your computer:  MagicGate Memory Stick media (hereafter called MG Memory Stick media), which is provided with copyright protection.  Memory Stick media, which does not have the same copyright protection as MagicGate Memory Stick media. Some music files with secure copyright protection may be stored on MG Memory Stick media but not on regular Memory Stick media.You can also use MagicGate media-compatible devices to record and playback music when they are connected to your computer.
Page 80 Inserting Memory Stick media Before using Memory Stick media, back up important data. The media slot accommodates only one Memory Stick media at a time. To insert Memory Stick media Insert the Memory Stick media with the arrow facing up and toward the Memory Stick media slot. Inserting the media in the wrong direction may damage the connector pins.
Page 81 Viewing the contents Depending on the model you purchased, the Sony Memory Stick window appears automatically when you insert a Memory Stick media. From this window, you can choose to view, print, copy or organize your Memory Stick images or data. If the Sony Memory Stick window does not appear when you insert your Memory Stick media, then follow these steps.
Page 82 Write-protecting Memory Stick media Memory Stick media is designed with a write-protect tab to protect data from accidental erasure or overwriting. Move the ® tab to the right or left to set or release write-protection. When the write-protect tab of the Memory Stick media is set to LOCK, data cannot be recorded or erased.
Page 83 Formatting Memory Stick media Memory Stick media is formatted for immediate use when you purchase it. If you need to reformat Memory Stick media, use ® the Memory Stick Formatter that is provided with the media. For more information about using Memory Stick Formatter, refer to Formatter Help.
Page 84 Removing Memory Stick media If the media is removed prematurely, a blue screen with an error message appears prompting you to continue or exit. Reinsert the media into the slot and press Enter to continue. This enables the media to finish reading or writing data. To remove Memory Stick media Wait a minimum of 10 seconds after the Memory Stick media finishes reading or writing data before removing the media.
Page 85 Using recorded music requires permission of the copyright holders.  Sony is not responsible for music files that cannot be recorded from a CD or downloaded from other sources. Can I copy images from a digital video camera using Memory Stick media? Yes, and you can view video clips that you have recorded with Memory Stick media-compatible video camera recorders.
Page 86: Changing The Window Design Of Sony Programs
Click << or >> to view the designs. To select a design that appears in the center window, click Apply. The UI Design Selector window design changes. The window design for your Sony software will match the UI Design Selector window. Click OK.
Page 87: Connecting Mice And Keyboards
Connecting Mice and Keyboards  Using External Mice and Keyboards Page 87...
Page 88: Using External Mice And Keyboards
Using External Mice and Keyboards You can connect a universal serial bus (USB) mouse or keyboard to your computer. To function properly, the device you connect must be compatible with the Microsoft about your computer's built-in keyboard and key functions, see ...
Page 89 Connecting a mouse or keyboard Your computer is compatible with many popular mice and keyboards. The New Hardware Wizard guides you through the software installation process. Some devices require separate driver software installation. See the instructions that accompanied your mouse or keyboard for more information. If the mouse or keyboard does not work once you have connected it to your computer, see Your computer can be on or off when connecting a mouse or keyboard.
Page 90 Connecting a PS/2 mouse or keyboard You can connect either an external PS/2 Connect only one PS/2 device to the port replicator at a time. See the instructions that accompanied your mouse or keyboard for more information. If the mouse or keyboard does not work once you have connected it to your port replicator, Frequently asked questions for more information.
Page 91 Disconnecting a mouse or keyboard You can disconnect a USB mouse or keyboard when the computer is on or off. Disconnecting the USB mouse or keyboard when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. To disconnect the USB mouse or keyboard ...
Page 92 Why doesn't the computer recognize the USB mouse?  If you are using a Sony USB mouse, make sure the mouse is securely plugged into the USB port.  If you are using an external mouse, make sure the mouse is securely plugged into the USB port or the PS/2 port if you are connecting it to the port replicator.
Page 93: Connecting A Port Replicator
Connecting a Port Replicator  Locating Ports and Connectors  Using the Port Replicator Page 93...
Page 94: Locating Ports And Connectors
Locating Ports and Connectors You can purchase a port replicator to use with the computer you purchased. The port replicator contains several ports and connectors, which enable you to connect additional peripherals to your computer. Back USB ports 2 LINE IN jacks 3 S Video Out jack Network port (Ethernet 10BASE-T/100BASE-TX port)
Page 95: Using The Port Replicator
Using the Port Replicator Connecting the port replicator You must use the AC adapter to power the computer when it is connected to the port replicator. However, you can insert the battery to charge it while you are using the AC adapter to power the port replicator. Make sure you insert the battery before you connect the port replicator.
Page 96 Using the Port Replicator Connecting the port replicator You must use the AC adapter to power the computer when it is connected to the port replicator. However, you can insert the battery to charge it while you are using the AC adapter to power the port replicator. Make sure you insert the battery before you connect the port replicator.
Page 97 Removing the port replicator To remove the port replicator Close any active programs to prevent data loss. Double-click the Unplug or Eject Hardware icon appears. Select the floppy disk drive in the Hardware devices window, if it is not already selected. Click Stop.
Page 98: Floppy Disk Drives And Pc Cards
Floppy Disk Drives and PC Cards  Using Floppy Disk Drives  Using PC Cards Page 98...
Page 99: Using Floppy Disk Drives
Using Floppy Disk Drives You can connect a floppy disk drive to your computer or port replicator. The floppy disk drive enables you to read data stored on a floppy disk.  Connecting a floppy disk drive  Inserting and removing floppy disks ...
Page 100 Connecting a floppy disk drive You can connect a floppy disk drive when your computer is on or off. Connecting the drive when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. To connect a floppy disk drive Close any active programs to prevent data loss.
Page 101 Inserting and removing floppy disks Floppy disks are portable devices that store data. To protect your floppy disks, keep them away from magnets and direct sunlight or other heat sources. To insert a floppy disk Hold the floppy disk with the label facing up. Push the floppy disk into the drive until it clicks into place.
Page 102 Notes on handling floppy disks  Do not open the shutter manually and touch the surface of the floppy disk.  Keep floppy disks away from magnets.  Keep floppy disk away from direct sunlight and other heat sources. Page 102...
Page 103 Disconnecting a floppy disk drive You can disconnect a floppy disk drive when the computer is on or off. Disconnecting the drive when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. To disconnect a floppy disk drive Close any active programs to prevent data loss.
Page 104 Carrying the floppy disk drive Fold the floppy disk drive cable and connector into the side compartment on the floppy disk drive. Carrying a Floppy Disk Driv e Page 104...
Page 105 Frequently asked questions Why doesn't the Unplug or Eject Hardware icon The computer does not recognize that the floppy disk drive is connected to the computer. First, make sure the USB connector is properly inserted into the USB port. If you need to secure the connection, wait a few moments for the computer to recognize the drive.
Page 106: Using Pc Cards
Using PC Cards Your computer includes one or more PC Card slots. A PC Card enables you to connect portable external devices, such as another hard disk drive or a PC Network Interface Card (NIC), to connect to a network. See your VAIO Computer Specifications for the type of PC Card that is compatible with your computer.
Page 107 Your computer may contain PC Card slot protectors. Remove these protectors before you insert a PC Card into the slot. To remove slot protectors. Some PC Cards may require you to disable idle devices when using the PC Card. You can use Sony Notebook Setup to disable devices.
Page 108 Removing PC Cards You can remove PC Cards while the computer is on or off. PC Cards draw power from the computer when they are inserted into the PC Card slot, whether or not you use the card. If you are not using your PC Card and you are using a battery as a power source, remove the PC Card from the PC Card slot to conserve battery power.
Page 109 The PC Card drive enables you to read data stored on a DVD or CD. Your computer may come with an external PC Card drive, depending on the model you purchased. If you wish to purchase an optional PC Card drive, shop Sony online at http://www.sonystyle.com/vaio...
Page 110 Click Stop. The Stop a Hardware device window appears. Make sure the PC Card drive is selected, and click OK. A message appears stating it is now safe to remove the hardware device. Eject the PC Card from the PC Card slot. Page 110...
Page 111 Make sure the PC Card is inserted properly. See  Make sure the PC Card is compatible with the Microsoft  Use the Sony Notebook Setup utility to disable devices you are not currently using. See Setup for more information. ...
Page 112: Audio And Video Connections
Audio and Video Connections  Using i.LINK Digital-Video Recorders  Using Computer Monitors and Projectors  Using Speakers, CD Players, or Amplifiers  Using Microphones Page 112...
Page 113: Using I.link Digital-Video Recorders
N K is a trademark of Sony us ed to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tor. T he i.LI...
Page 114 Connecting an i.LINK digital video recorder You can connect an i.LINK digital video (DV) recorder when the computer is powered on or off. Connecting the DV recorder when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. To connect an i.LINK digital video recorder Turn on the DV device and the computer.
Page 115 Disconnecting the i.LINK digital video recorder You can disconnect the i.LINK digital video recorder when the computer is powered on or off. Disconnecting the DV device when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. To disconnect the i.LINK DV recorder when the computer is off Turn off the computer and the i.LINK DV device.
Page 116 Using a digital video camera recorder Your computer comes with preinstalled driver software that is compatible with most Sony digital video camera recorders. If you purchased a camera that comes with its own driver software, install these drivers before you use the camera.
Page 117 Notes on connecting an i.LINK device  Do not connect more than one digital video camera recorder at a time. The software supplied with your computer will not recognize multiple cameras.  Do not connect an external device that requires power from the i.LINK port. The i.LINK port cannot supply power to the external device.
Page 118 N K is a trademark of Sony us ed only to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Page 119: Using Computer Monitors And Projectors
Using Computer Monitors and Projectors You can connect an external display (such as a computer monitor or a projector) to your computer or port replicator (not supplied).  Connecting a computer monitor  Connecting a multimedia computer monitor  Connecting a TV ...
Page 120 Connecting a computer monitor You can display the images on the computer screen (LCD) onto an external computer monitor. The external monitor displays the operations you perform on your computer. To connect a computer monitor Make sure the computer monitor is plugged into an AC outlet. Turn off the computer.
Page 121 Connecting a multimedia computer monitor A multimedia computer monitor has built-in speakers and/or a microphone device. Before you can connect your computer to a multimedia computer monitor, it must have an A/V OUT jack. For more information, see Locating Controls and Ports in the Setting Up chapter of your supplied VAIO To connect a multimedia computer monitor Plug the multimedia computer monitor into an AC outlet.
Page 122 Connecting a TV You can connect a multimedia display, such as a TV or a VCR, to the computer or the port replicator (not supplied). To connect a TV to the computer Plug the display into an AC outlet. Plug the display cable into the A/V OUT jack on your computer. Plug the other end of the AV cable into the video-in port on the display.
Page 123 Connecting a TV to the Port Replicator Switch the TV input channel to external input. See the guide that came with your peripheral device for more information on its installation and use. Disable the screen saver and the virus checker. Select a display.
Page 124 Connecting a projector You can use a projector to display the actions and images on your computer's LCD screen. To connect a projector Plug the projector into an AC outlet. Turn off the computer. Plug the display cable connector into the Monitor (VGA) port Plug the other end of the display cable into the projector.
Page 125 Selecting a display mode This computer uses the ATI video controller. When you connect your computer to an external display (projector, computer monitor, or TV), you can switch the display mode between your computer's LCD display and the external display, using shortcut keys or the Display Properties settings.
Page 126 If you cannot see your movie or DVD on the external display, change the monitor or TV setting by clicking the Primary icon on the display panel of your choice. You may not be able to display the computer screen (LCD) and an external display or projector at the same time, depending on the types of computer displays and projectors you are using.
Page 127 Disconnecting a computer monitor or projector You can disconnect the external computer monitor or projector by unplugging the display or Monitor (VGA) cable from your computer's port. Disconnecting the external display when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction.
Page 128: Using Speakers, Cd Players, Or Amplifiers
Using Speakers, CD Players, or Amplifiers Your computer comes with built-in stereo speakers. If you wish to enhance the sound quality of your computer, you can purchase and connect external speakers. You can also purchase and connect other audio devices, such as a CD player or an amplifier.
Page 129 Connecting standard speakers Do not place floppy disks on the speakers. The speakers' magnetic field may damage the data stored on the floppy disks. To connect standard speakers to your computer Turn down the volume of the speakers. Plug the speaker cable into the Headphone jack Plug the other end of the speaker cable into the speaker.
Page 130 Disconnecting standard speakers You can disconnect external speakers when the computer is on or off. Simply unplug the speaker cable from the Headphone jack on the computer. Page 130...
Page 131 Connecting active speakers or amplifiers You can connect amplifiers or active speakers, which are equipped with amplifiers, to the port replicator or the computer. To connect active speakers or amplifiers to the port replicator Connect the port replicator to the computer. See Plug the audio cable into the LINE OUT jacks on the port replicator.
Page 132 Disconnecting active speakers or amplifiers You can disconnect active speakers or amplifiers when the computer is on or off. Simply unplug the audio cable from the LINE OUT on the port replicator or the A/V OUT jack on the computer. Page 132...
Page 133 Connecting CD, MiniDisc, or audio cassette players You can connect CD, MiniDisc, or audio cassette players to the port replicator. To connect CD, MiniDisc, or audio cassette players Connect the port replicator to the computer. See Plug the audio cable into the LINE IN jacks on the port replicator. The LINE IN jacks consist of one Audio (L) jack and one Audio (R) jack.
Page 134 Disconnecting CD, MiniDisc, or audio cassette players You can disconnect CD, MiniDisc, or audio cassette player when the computer is on or off. Simply unplug the audio cable from the LINE IN jack on the port replicator. Page 134...
Page 135 Adjusting the volume To adjust the volume for playing CDs and DVDs, use the Volume icon control. Adjusting the volume for playing CDs or DVDs does not adjust the volume for recording CDs or DVDs. You can only adjust the recording volume in the Recording Control window. See record for instructions on how to open this window.
Page 136 Enabling the audio feature If you do not hear sound when playing a CD or DVD, you may need to enable the audio feature. To enable the audio feature Click Start, Settings, Control Panel, and System. The System Properties window appears. Select the Hardware tab, and click Device Manager.
Page 137 Frequently asked questions Why won't my speakers work?  Make sure the speakers are properly connected and the volume is turned up loud enough to hear sound.  Your speakers may not be designed for computer use.  If the speakers have a mute button, set the button to off. ...
Page 138: Using Microphones
Using Microphones You can connect an external microphone to your computer to enhance the sound input to your computer. Make sure your microphone is designed for computer use. If you wish to purchase a microphone, shop Sony online at http://www.sonystyle.com/vaio or contact your local retailer.
Page 139 Connecting a microphone Plug the microphone cable into the Microphone jack on the computer. Connecting a Microphone Jack See the manual that came with your microphone for more information on its installation and use. A protruding dot loc ated next to the M ic rophone jac k dis tinguis hes this jac k from the H eadphone jac k. Page 139...
Page 140 Disconnecting a microphone You can disconnect an external microphone when the computer is on or off. Simply unplug the microphone cable from the Microphone jack on the computer. Page 140...
Page 141 Using a microphone or other device to record You can record messages, memos, or other recordings in analog by connecting a microphone or other audio device to the Microphone jack on your computer or port replicator and switching the jack functionality. The Microphone jack MIC IN (monaural).
Page 142 Frequently asked questions Why doesn't my microphone work? If you are using an external microphone, make sure the microphone is properly plugged into the Microphone jack on the computer. See Connecting a microphone for more information. Page 142...
Page 143: Preinstalled Programs
Preinstalled Programs  Software Programs On Your Computer  DVgate Program Notes  Program Support Information Page 143...
Page 144: Software Programs On Your Computer
Software Programs On Your Computer Your computer may not be supplied with all of the programs listed in purchased. Preinstalled software may not be identical to retail versions or include supporting documentation.  Program overview  Frequently asked questions Program overview, depending on the configuration you Page 144...
Page 145 Click to DVD (On selected models) Sony Electronics Inc. At the touch of a button, Click to DVD software enables you to automatically burn DVDs from videos or still pictures. Create DVDs by capturing video content straight from a digital video (DV) device or stored video files — and you can also edit the video if desired.
Page 146 Sony Electronics Inc. PictureGear Studio image management software displays images from your hard drive or a Sony digital still camera. The images appear in a convenient light-table format, so that you can easily view the contents of an entire folder and create your own photo albums and make prints.
Page 147 Internet content. Sony on Yahoo! Yahoo! Inc. Personalize your own Web portal with Sony on Yahoo! Get a free Web mail account, customized news and local weather reports, comics, instant messaging, and more. VAIO Edit Components Sony Electronics Inc.
Page 148 Make sure you place the CD in the tray with the label facing up. Which program do I use for CD-R/CD-RW functions? Use the preinstalled Sony SonicStage program and Windows model you purchased is preconfigured with all of the necessary components for CD-R and CD-RW capability.
Page 149: Dvgate Program Notes
DVgate Program Notes  Recording images to a digital video device  Adjusting image resolution  Saving to your hard disk drive Page 149...
Page 150 Recording images to a digital video device If your system displays the message, "Failed to record to DV deck, please check deck's power status, cable connection...," while you are recording images to a digital video device using the DVgate program, close all open programs, and restart your computer.
Page 151 Adjusting image resolution If the images on the computer screen (LCD) do not display smoothly, the resolution may not be set correctly. To check the resolution From the DVgate Motion-Monitor window, click Setup. From the shortcut menu, point to Settings, and then select Low Resolution. The settings you change in this menu affect the images in the monitor window only.
Page 152 Saving to your hard disk drive In order to improve the performance of your computer's DVgate been formatted with two partitions, C and D. The C partition holds 40 percent and the D partition holds 60 percent of the entire drive capacity. The DVgate program saves files to the D partition. This prevents large video captures from consuming the available space on your C partition.
Page 153: Program Support Information
Program Support Information  Sony Service Center Adobe Acrobat Reader , Photoshop ® ® ® Web site http://www.adobe.com/ e-mail techdocs@adobe.com telephone 206-675-6126 (fee-based support) 206-628-5737 hours M-F, 6 A.M.-5 P.M. (Pacific time) America Online (America Online, Inc.) ® Web site http://www.aol.com/...
Page 154 RealOne Player (RealNetworks, Inc.) Web site http://service.real.com/rjoptions.html e-mail http://service.real.com/help/call.html Sony Applications (Sony Electronics Inc.) Web site http://www.sony.com/pcsupport telephone 888-4-SONY-PC (888-476-6972) hours 7 days a week, 24 hours a day Support from 1 -8 8 8 -4 -SO N Y -P C is free of c harge for 9 0 days after the original date of purc has e.
Page 155 Sony Service Center For the Sony Service Center nearest you, call 1-888-4-SONY-PC (1-888-476-6972) or find Sony Customer Service on the Web at http://www.ita.sel.sony.com/support. Page 155...
Page 156 N K is a trademark of Sony us ed to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Page 157 Editing Video with MovieShaker Software MovieShaker software can be used to create fun and innovative movies without any previous knowledge of film editing. In a few simple steps, video files can be created from video clips and still images with added special effects and music. This guide provides only a simple overview of using the MovieShaker software.
Page 158 To preview the entire movie, click the Story Board panel above the first clip so that a white triangle appears above the clip, and click the Play button on the Edit panel. The entire movie, including transitions, plays in the monitor window. After you have arranged and trimmed your video clips and placed transitions between them, you are ready to export your finished movie back to your digital video camera.
Page 159 Editing Video with DVgate Software DVgate software offers professional-level control over all aspects of capturing, trimming, and combining digital video clips from a compatible digital video (DV) camera. After you have combined your clips into a finished movie, you can export it back to your compatible digital video camera.
Page 160 You can select multiple clips by holding down the Ctrl key and clicking several files. Your selected clips appear in the Assemble list in the DVgate Assemble window. If necessary, edit the order of clips in the Assemble list. For the combined movie, clips are combined in the order they appear in the Assemble list, starting from the top. ...
Page 161 The ADD dialog box appears. In the ADD dialog box, select the movie file you want to export, and click Open. The ADD dialog box closes, and your selected movie appears in the Record list in the DVgate Motion - AVI file list window.
Page 162: Working With Still Images
Working with Still Images The Microsoft Windows XP operating system and the multimedia software preinstalled on your VAIO computer make it ® ® ® easy to import, edit, and print your photographs and other images. Page 162...
Page 163: Importing Still Images
Importing Still Images There are a variety of ways to bring still images into your computer. Which approach is right for you depends upon whether you have a digital camera or a traditional film camera.  Many digital cameras connect directly to your computer. The Microsoft Windows XP operating system already contains all the necessary software to import pictures from...
Page 164: Editing Still Images
Editing Still Images After you have gotten your images into your computer, you can use image-editing software to enhance them. You can perform traditional darkroom tasks such as resizing, cropping, and altering colors. You can also add creative touches such as painting on top of your photographs, adding text, or combining multiple photographs into one.
Page 165: Printing Still Images
Printing Still Images Many of today's inexpensive computer printers can print images as sharp and bright as professionally developed film photos. There are a variety of options for printing your digital images:  You can print most images directly from the Microsoft the image and clicking Print from the shortcut menu.
Page 166 CDs, and check music out to portable digital music devices, such as Net MD Music Players. SonicStage software employs Sony's OpenMG allow you to enjoy digital music while protecting the rights of copyright holders. You can enjoy digital music with SonicStage software in a wide variety of ways: ...
Page 167 Start SonicStage. On the Help menu, click SonicStage Help. To make a backup copy of an audio CD On computer models equipped with a CD recording device, you can use the Backing Up Audio CDs utility to make a backup copy of an audio CD.
Page 168 Sharing Video, Images, and Music on a Network VAIO Media software is available on select VAIO computer models. ® The VAIO Media software preinstalled on your VAIO computer makes it easy to share video, images, and music between ® the VAIO computers on your network. One VAIO computer becomes the "media server" for your network, providing a central place for all your video, image, and music files, which you can then enjoy from any VAIO computer connected to your wired or wireless network.
Page 169 How VAIO Media Works This guide provides only an overview of the VAIO Media system. For detailed instructions about setting up and using VAIO Media, refer to the online Help for VAIO Media. To share music, video, and photos with the VAIO Media system, set up one computer on your network as the central library or "media server,"...
Page 170 Setting up a VAIO Media server computer Any networked VAIO computer that came from the factory with VAIO Media installed can be used as a VAIO Media server ® for music and image files. To be a VAIO Media server for video files, a computer must have Giga Pocket 5.0 software or later installed.
Page 171 Setting up a VAIO Media client computer Any networked VAIO computer that came from the factory with the Microsoft ® be a VAIO Media client computer and view or listen to media content made available by a VAIO Media server computer. For detailed instructions about setting up a VAIO Media client computer, refer to the online Help for VAIO Media.
Page 172 Using VAIO Media For detailed instructions about using the VAIO Media client software, refer to the online Help for VAIO Media. Starting the VAIO Media client software  Click Start, click All Programs, point to VAIO Media, and click VAIO Media. Viewing or listening to images, video, and music with VAIO Media Start the VAIO Media client software.
Page 173  Playlists screen When you click a playlist on the Playlist screen, a list of the music files on the playlist is displayed, and the first music file on the playlist begins playing.  Folders screen When you click a folder on the Folders screen, thumbnail images of the image files in that folder are displayed.
Page 174: Creating Dvds
Creating DVDs The information in this Creating DVDs guide applies only to VAIO computer models that come from the factory with a DVD-RW drive preinstalled. The DVD-RW drive and DVD creation software included with your VAIO With these tools, you can create: ...
Page 175 About Disc Formats, Media, and Compatibility Use the information in this section as a guide to which type of blank recording media and which kind of playback equipment you can use with different disc formats.  Using the Right Recording Media ...
Page 176 Using the Right Recording Media All DVDs and CDs look similar, but different types have different capabilities. Using the correct recording media is necessary to the success of your recording project. The table below indicates the appropriate media types for each kind of disc-recording project supported by your DVD-RW drive.
Page 177 Using the Right Disc Format with the Right Playback Equipment The table below gives a general idea of the compatibility of disc formats with different playback equipment. Compatibility between a specific disc and a specific kind of playback equipment cannot be guaranteed. For example, some models of home DVD players can play video DVDs recorded on your computer, while other models cannot.
Page 178 Creating DVDs with Click to DVD With Click to DVD software, you can create full-featured video DVDs with multi-level menus and attractive, pre-built themes and music from video recorded on your digital video (DV) camera. You can also create photo album and slide show DVDs of digital pictures stored on your computer, stored in your digital still camera, or stored on Memory Stick Click to DVD software comes in two parts: ...
Page 179 Using Click to DVD software This guide provides an overview of creating a DVD from a digital video (DV) device using the Click to DVD program. For detailed information about creating DVDs with Click to DVD software, including creating photo album and slide show DVDs, and about creating a DVD in a few clicks of the mouse with Click to DVD Automatic Mode software, consult the online Help files for Click to DVD and Click to DVD Automatic Mode.
Page 180 You may have to scroll down to display this option. Click to DVD software starts and displays the Start window. Start window Type a title for your DVD into the DVD Title: box. This title will appear in the title menu screen of your completed DVD. In the Select a theme...
Page 181 Make sure the Automatic Capture option and the Rewind tape check box are selected. With these settings, the Click to DVD tape. For details about manually capturing individual clips and about importing video clip files stored on your computer, refer to the online Help for Click to DVD. 10.
Page 182 In the Edit Video screen, your video clips appear in the order they will be played on your DVD. You can:  Delete unwanted clips by dragging them to the Recycle Bin  Drag clips to a new position to change the order ...
Page 183 13. To view the title and chapter menu screens of your DVD, click the Title Menu and Video Menu buttons at the left of the window. When viewing the chapter menu screens, click Next and Previous to move through multiple chapter menu screens.
Page 184 17. After previewing your DVD, click Close to close the Preview window. 18. If, after previewing, you want to make changes to your menu screens, click Create Menu in the step guide at the top of the window, and use the menu creation features described in step 14 to edit your menu screens. 19.
Page 185 Creating DVDs with RecordNow DX RecordNow DX software enables you to create data CDs and DVDs and music CDs using an interface that is both easy to use and sophisticated. The RecordNow DX Wizard walks you through creating data and music discs or duplicating discs you already own.
Page 186 Using RecordNow DX Software To start RecordNow DX Click Start in the Windows ® Point to VERITAS Software, point to RecordNow DX, and click RecordNow DX. To view the online Help for RecordNow DX The online Help for RecordNow DX provides detailed information about using the program. Click Start in the Windows ®...
Page 187 Topics What type of data can I record to DVD-R for General, DVD-RW, CD-R, and CD-RW media using RecordNow DX software? You can only record files that originated on a computer or on a music CD. RecordNow DX simply transfers data and music files to the recording media without converting it in any way.
Page 188 Creating DVDs with Drag'n Drop CD/DVD Drag'n Drop CD/DVD brings a unique drag-and-drop approach to the creation of data CDs and DVDs and music CDs. Three icons, Music, DISC Backup, and Data, are always available on your desktop. Just drag data files, music files, or a CD or DVD that you want to back up to the appropriate icon, insert a blank disc, and click the record button.
Page 189 Using Drag'n Drop CD/DVD Software To start Drag'n Drop CD/DVD Click Start in the Windows ® Point to Drag'n Drop CD, and click Drag'n Drop CD. Drag'n Drop CD/DVD starts, and the three Drag'n Drop CD/DVD icons (Music, DISC Backup, and Data) appear on your desktop.
Page 190: Vaio Av Applications
VAIO AV Applications Your VAIO computer is preconfigured with a collection of audio and video (AV) applications that make it easy to use ® advanced multimedia technology. This section describes the VAIO AV applications. ® Your computer may not be supplied with all of the software applications listed, depending on the system configuration you purchased.
Page 191: Overview Of Preinstalled Software
N K is a trademark of Sony us ed only to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Page 192: Dvgate Software
DVgate Software For detailed information about using DVgate Connecting a digital video camcorder Turn off the power to your digital video camcorder before connecting it to your computer. After connecting the device, turn its power back on. You do not need to turn off the computer when connecting the camcorder. DVgate software does not support MICROMV To use DVgate software with a digital video camcorder...
Page 193: Movieshaker Software
MovieShaker Software MovieShaker software can be used to create fun and innovative movies without any previous knowledge of film editing. In a few simple steps, you can turn a collection of video clips, still images, and audio files into a finished movie with special effects and music.
Page 194 Creating movies with MovieShaker software Using your imported clips, you can create a short movie using the Shake feature. The Shake feature selects clips from the Story Board tray, adds effects, and combines them randomly into a 30-second movie. After you "Shake" your video, you can edit it by adding effects and text, by adjusting the color and contrast, and by modifying its length.
Page 195 Double-click or drag the desired clip or scene to move it to the Story Board tray. Click the Effect button on the Effect tray. Effect tray window (Effect button selected) Drag the Effect icon you want to add from the Effect tray to the Effect palette on the Edit tray. Click the Play button on the Edit tray to preview the effect.
Page 196 Click the Play button on the Edit tray to preview the text effect. The clip displays the text effect in the Effect tray window. A preview of the added text and text effect is displayed in the Effects tray window. From the Edit tray, you can eliminate a text effect by dragging it from the Effect palette to the trash icon.
Page 197 Using the ImageStation online service with MovieShaker software ImageStation is an online service that allows you to store your pictures and movies on the Internet to share with family and friends. The ImageStation service requires an Internet connection and registration for the Web-based service. You must be connected to the Internet before uploading your pictures or movies using the MovieShaker software and ImageStation applications.
Page 198: Network Smart Capture
N K is a trademark of Sony us ed only to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Page 199 The Network Smart Capture main window Network Smart Capture opens with a blue screen in the Finder Window, indicating there is no data input from a digital camera or camcorder. When you connect your digital camera or camcorder to your system with an i.LINK on, an image appears in the main window.
Page 200 11 Capture button 12 Web Camera button 13 Movie Mode button 14 Still Mode button Records the image in the Finder Window Captures still images according to specified settings Captures moving images Captures still images Page 200...
Page 201 Capturing still images The following information tells you how to set preferences and capture a still image. To set Still mode preferences Open Network Smart Capture:  (Microsoft Windows XP) From the Start menu, click All Programs, Network Smart Capture, and click ®...
Page 202 Click the thumbnail images or arrows to the right of the Finder Window to view your captured images. As each image is captured, it appears in the Finder Window. Page 202...
Page 203 Capturing movie clips The following information tells you how to set preferences and capture movie clips. To set Movie mode preferences Open Network Smart Capture:  (Microsoft Windows XP) From the Start menu, click All Programs, Network Smart Capture, and click ®...
Page 204 Click Stop when you have finished recording your movie. The first frame of your movie appears in the Data list to the right of the Finder Window. Network Smart Capture automatically stops recording according to the recording time set in the Movie Clip Setting window. You can review your movie in the Finder Window by double-clicking the movie thumbnail in the data list.
Page 205 Capturing Web camera images The following information tells you how to set preferences and capture an image. To set Web camera mode preferences Open Network Smart Capture:  (Microsoft Windows XP) From the Start menu, click All Programs, Network Smart Capture, and click ®...
Page 206 Applying effects to your images and movies You can add effects to real-time images or movies displayed in the Finder Window. You can also use a different effect for each picture. To open the Effect Setting window Click the Select Effect icon Effect Settings Window Use the drop-down list to view and select available effects.
Page 207 Managing your images and movies The task buttons to the right of the Network Smart Capture window enable you to perform various functions with your images or movies.  Display Image — Opens captured images in the Finder Window.  Save As —...
Page 208 Using the ImageStation online service ImageStation is an online service that allows you to store your images and movies on the Internet to share with family and friends. The ImageStation service requires an Internet connection and registration for the Web-based service. You must be connected to the Internet before uploading your images or movies with Smart Capture and ImageStation programs.
Page 209 Getting more help For more information about Network Smart Capture, see the program's online Help. To view the online help  (Microsoft Windows XP) From the Start menu, click All Programs, Network Smart Capture, and click Help from the ® ®...
Page 210: Picturegear Studio
PictureGear Studio Software PictureGear Studio software is designed to creatively manage your digital pictures. With its easy-to-use features, you can quickly load images from your digital camera or camcorder, print high-quality photos, create custom labels, and design personalized photo albums or binders to share with friends and family. PictureGear Studio m ain window Photo albums, binders, and photo collections can only be viewed or edited using PictureGear Studio software.
Page 211 Using the Import Photo feature Capture and import the pictures from your digital camera or camcorder to your computer. You can select your favorite pictures and place them in handy folders for future use. When you initially connect your digital camera, camcorder or insert a Memory Stick recognize the device or media.
Page 212 Select a folder option. If you are importing to a new folder, type in the folder name before clicking Start Importing. An Adjust window appears. Adjust window Click to make any desired adjustments to the pictures. The Adjust window displays an enlarged version of the picture on the right and thumbnail versions on the left.
Page 213 Using the PhotoCollection feature You can organize and manage your imported pictures on your computer's hard drive or from your ImageStation Click PhotoCollection. A list of available photo sources is displayed on the left, with the selected source's contents displayed as thumbnail pictures on the right. PhotoCollection window From the thumbnail view, click to select pictures.
Page 214 Using the Binder feature You can add comments to your favorite photos, add custom backgrounds, clip art, and stamps, or showcase your own drawing talent. Add, remove, or change your designs to create your own unique photo art. Click Binder. A list of binder styles is displayed on the left. When you add your pictures to a binder, they are displayed as thumbnails on the right.
Page 215 Using the PhotoAlbum feature Organize your memorable photos in an electronic photo album. You can share your custom photo albums with friends and family. Click PhotoAlbum. PhotoAlbum window Click New Album. The Select Photo area appears. If you want to work on a previously created album, do not click Create New Album. Instead, select the desired album from the Album Collection view on the right side of the window.
Page 216 Click to select a design layout for your album. Use the scroll bar to view all available album designs. A Select Layout window appears. Select Layout window Click to select a page layout for your album. Use the scroll bar to view all available layout designs. A preview of your selected design and page layout is displayed.
Page 217 Click Edit Album to make changes to your album. Customize your album by adding more pictures, pages, decorations, or comments, or by deleting pages. Click Edit Page to customize a page in your album. You can customize with your own drawing, stamps or other decorations.
Page 218 Click to select an export format. A Select Folder window appears. Select Folder window Click Browse and navigate to the destination folder. Enter a file name, if desired. Click Export. A progress window appears briefly. Finish Exporting window An export completion message window appears, displaying the file name and file size. Click Return to Edit Album Screen.
Page 219 Using the PrintStudio feature Use PrintStudio to design original postcards, calendars, art, and labels using your favorite pictures. Click PrintStudio. The PrintStudio window appears. PrintStudio window Select the item you want to create and click Start Creating. The initial creation window appears. The initial window varies, depending on the item you are creating.
Page 220: Sonicstage Software
CDs and import digital audio files while maintaining copyright information. Taking advantage of Sony's copyright-protected ATRAC3 format for high-quality digital audio storage, SonicStage sports a music visualizer, a sleek player skin design, audio CD burning capability, and a parametric equalizer for fine-tuning audio playback.
Page 221 Electronic Music Distribution (EMD) Services EMD enables you to download music files via the Internet. To use Internet services that are compatible with the SonicStage software, you need:  Access to the Internet from your computer. Sign up with an Internet Service Provider (ISP) and configure your computer for Internet access before using EMD services.
Page 222 Starting SonicStage Software Click Start in the Windows taskbar, and click All Programs. Point to SonicStage, and click SonicStage. When you have registered with CDDB, the Confirm the setup of SonicStage... dialog box appears. Click Yes to continue. SonicStage feature tabs (Main window) ...
Page 223 Controls playback functions, such as play, pause, stop, fast forward, and reverse. You can increase or decrease volume and switch view modes. Internet address drop-down list (Playlist view) Displays Internet addresses associated with the currently selected song. Click Go to URL link to immediately connect to the Internet address displayed in the drop-down list.
Page 224 Recording from a CD You can record songs from audio CDs and add them to playlists in SonicStage software. When you record from an audio CD from your optical disc drive for the first time, the CD Drive Optimization dialog box appears.
Page 225 Transferring songs (Check-In/Check-Out) You can transfer songs between the playlists in the SonicStage software and external devices or media. For more information on using your external devices or media, see the instructions supplied with the device or media. These instructions are for using the Check-In/Check-Out "1-step" method. For information on using another method, see "Changing the check-in/check-out settings"...
Page 226 To cancel Check In, click process. For more information about using SonicStage software, go to the online SonicStage Help. You can access the online help file as follows: Click the Start button in the Windows taskbar, and click All Programs. Point to SonicStage, and click SonicStage Help.
Page 227 Additional features  SonicStage Tutorial — SonicStage features are described in the Tutorial. The user-friendly interface instructs you on how to use all SonicStage features.  SonicStage Backup Tool — You can back up and restore music, graphics, and information data managed by SonicStage software.
Page 228: Additional Software Information
Additional Software Information VAIO Edit Components Software VAIO Edit Components is a software plug-in for Adobe quality for capturing video from your Sony digital camcorder. If your VAIO preinstalled and you subsequently purchase and install Adobe compatibility with Sony digital camcorders.
Page 229: Legal Information
The software described herein is governed by the terms of a separate user license agreement. This product contains software owned by Sony and licensed by third parties. Use of such software is subject to the terms and conditions of license agreements enclosed with this product. Some of the software may not be transported or used outside the United States.
Page 230: Memory Upgrades
Memory Upgrades  Upgrading Your Computer's Memory Page 230...
Page 231: Upgrading Your Computer's Memory
Upgrading Your Computer's Memory Before you begin upgrading your computer's memory, make sure you read modules are available as options. For memory upgrades and information about which memory modules to use, see expansion memory configuration  Precautions and procedures  Typical expansion memory configuration ...
Page 232 The procedures described below assume familiarity with the general terminology associated with personal computers and with the safety practices and regulatory compliance required for using and modifying electronic equipment. Sony recommends that memory upgrades be performed by an authorized Sony Service Center. To find the nearest center or agent, go to: http://www.sony.com/pcsupport.
Page 233 Typical expansion memory configuration Total System Memory (MB) On board (MB) Slot (MB) 1024 Page 233...
Page 234 Removing and installing memory modules Make sure you read Precautions and procedures module, do not open the module package until you are ready to install it. The package protects the module from Electrostatic discharge (ESD). To remove a memory module Turn off the computer and all peripheral devices.
Page 235 Snap the connectors into place when the board is correctly seated, and close the computer cover. Replace the fastening screws on the bottom of the computer. Make sure the system memory matches the amount of installed memory. See for more information. Confirming added memory capacity Page 235...
Page 236 Click Start on the Windows ® Select Sony Notebook Setup from the submenu. The Sony Notebook Setup dialog box appears. On the About This Computer tab, make sure the System Memory displayed in the System Information box matches the amount of memory installed.
Page 237: Using The Recovery Cds
Using the Recovery CDs  Application and System Recovery CDs  Using Your Recovery CDs Page 237...
Page 238: Application And System Recovery Cds
CDs. If your computer does not come with an optical drive, use an external optical drive. Application Recovery CD(s) Sony Electronics Inc. This CD enables you to reinstall individual software programs and device drivers if they become corrupted or are erased.
Page 239: Using Your Recovery Cds
Using Your Recovery CDs The following sections describe how to use the Application Recovery and System Recovery utilities.  Using the Application Recovery CD(s)  Using the System Recovery CD(s) Page 239...
Page 240 ® drive. The Application Recovery utility loads automatically. Click OK in the VAIO welcome window. The Sony Application Recovery Program window appears. Double-click the Software folder icon. Select the icon for the application you want to restore, and then follow the on-screen instructions to complete the recovery process.
Page 241 17. Wait 30 seconds, and turn on your computer. If you have any questions about using the Application Recovery CD(s), visit http://www.sony.com/pcsupport, or contact Sony Customer Support at 1-888-4-SONY-PC. Page 241...
Page 242 Your system may take a few minutes to load necessary files. A blue screen may appear during the downloading process. Insert the Sony System Recovery CD in the optical drive. The first CD must be in the drive before you restart your computer.
Page 243 Your system may include one or more System Recovery CDs. If you have more than one System Recovery CDs, insert the first CD to run the System Recovery program. You are prompted to insert the second CD once the information from the first CD has been installed.
Page 244: Troubleshooting And Support
Troubleshooting and Support This section describes how to solve common problems you may encounter when using your computer. Many problems have simple solutions, so try these suggestions before you contact Sony Computing Support (http://www.sony.com/pcsupport).  Troubleshooting Your Computer  Troubleshooting Batteries ...
Page 245: Troubleshooting Your Computer
Select Exit (Save Changes), and press Enter. The Setup Confirmation window appears again. Select Yes, and press Enter. The computer restarts. If this occurs on a regular basis, contact Sony Computing Support (http://www.sony.com/pcsupport). Why does the message "Operating system not found" appear when my computer starts, and why won't Windows start? ...
Page 246 Turn off the computer. Remove any peripheral devices connected to the computer. Restart the computer. Press F2 when the Sony logo appears. The BIOS Setup window appears. Press the Right Arrow key Press the Down Arrow key SETUP items appears.
Page 247 Press U. The Turn off computer window opens. Press R to select restart. Press Enter. If the computer does not restart, Press Ctrl+Alt+Delete simultaneously. The Windows Security dialog box appears. Press the Right Arrow Press Enter. Press R to select restart. Press Enter.
Page 248: Troubleshooting Batteries
Troubleshooting Batteries How do I know when the battery is charged? To determine the remaining battery charge, see When is the computer using AC power? When the computer is directly connected to the AC adapter, it uses AC power, even if a battery is installed. When should I recharge the battery? ...
Page 249: Troubleshooting The Printer
Select the Ports tab, and select a different LPT Port Number.  You may need to enable the computer's printer port. Click Start, and point to Settings and Control Panel, then click Sony Notebook Setup. The Sony Notebook Setup window appears. Click the Device tab.
Page 250: Troubleshooting The Mouse And Touchpad
Why doesn't the computer recognize the USB mouse?  If you are using a Sony USB mouse, make sure the mouse is securely plugged into the USB port.  If you are using an external mouse, make sure the mouse is securely plugged into the USB port or the PS/2 port if you are connecting it to the port replicator.
Page 251 Click the Tools menu, and select Folder Options. The Folder Options dialog box appears with the General tab open. In the Click items as follows box, click to select Single-click to open an item (point to select). Click Apply.  If you are still experiencing problems, make sure another mouse was not installed.
Page 252: Troubleshooting The Modem
 Make sure the telephone number the program is dialing is correct.  Make sure the software you are using is compatible with the computer's modem. (All preinstalled Sony programs are compatible.)  If you are still experiencing problems, use the supplied Application Recovery CD(s) to reinstall the modem driver software.
Page 253: Troubleshooting Networks
Wireless LAN communication occurs on divided frequency bands known as channels. Third-party wireless LAN access point channels may be preset to different channels from Sony devices. If you are using a wireless LAN access point, refer to connectivity information contained in your access point instructions.
Page 254 N K is a trademark of Sony us ed only to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Page 255: Troubleshooting Dvds And Cds
Troubleshooting DVDs and CDs How do I maintain DVDs?  Avoid touching the surface of the disc with your fingers. Fingerprints and dust on the surface of the disc may cause reading errors.  To clean the disc, hold the edge of the disc, and use a soft cloth to wipe the surface from the center out. If the disc is badly soiled, moisten a soft cloth with water, wring it out well, and use it to wipe the surface of the disc from the center out.
Page 256  Make sure the digital CD audio is enabled for your optical drive. Follow these steps:  Click Start on the Windows Properties window appears.  Select the Hardware tab, and then click Device Manager. The Device Manager window appears. ...
Page 257: Troubleshooting Floppy Disk Drives
Troubleshooting Floppy Disk Drives Why doesn't the Unplug or Eject Hardware icon The computer does not recognize that the floppy disk drive is connected to the computer. First, make sure the USB connector is properly inserted into the USB port. If you need to secure the connection, wait a few moments for the computer to recognize the drive.
Page 258: Troubleshooting Pc Cards
Make sure the PC Card is inserted properly. See  Make sure the PC Card is compatible with the Microsoft  Use the Sony Notebook Setup utility to disable devices you are not currently using. See Setup for more information. ...
Page 259: Troubleshooting Audio-Video Connections
Troubleshooting Audio-Video Connections Why can't I use the DV recorder? You may not be able to use the DV recorder and the message, DV equipment seems to be disconnected or turned off may appear because the i.LINK cable is not securely plugged into the i.LINK ports on the computer or camera. Unplug the connectors, and plug them in again.
Page 260 N K is a trademark of Sony us ed only to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Page 261: Troubleshooting The Computer Screen (Lcd)
Troubleshooting the Computer Screen (LCD) Why did the computer (LCD) screen go blank?  Your computer screen may go blank if the computer has lost power or is in a power saving mode (Standby or Hibernate).  Make sure the computer is plugged into a power source and is turned on. The power indicator on the computer will be on if the computer is on.
Page 262: Troubleshooting Memory Stick Media
Using recorded music requires permission of the copyright holders.  Sony is not responsible for music files that cannot be recorded from a CD or downloaded from other sources. Can I copy images from a digital video camera using Memory Stick media? Yes, and you can view video clips that you have recorded with Memory Stick media-compatible video camera recorders.
Page 263: Troubleshooting Programs
Make sure you place the CD in the tray with the label side facing up. Which program do I use for CD-R/CD-RW functions? Use the preinstalled Sony SonicStage software and Windows specific model you purchased is preconfigured with all of the necessary components for CD-R and CD-RW capability.
Page 264: Computer Support Information
Sony Computing Support This service provides instant access to information on commonly encountered problems. Enter a description of your problem and the Knowledge Database searches for the corresponding solutions online. You can access Sony Computing Support at: http://www.sony.com/pcsupport. Computer Quick Start provide information on how to maximize ®...
