User Instruction & Installation Manual
L230 LED 90 Watt Searchlight
Product Reference Number:
A6138 – 240v DECK
A6161 – 240v CABIN
Manufacturer's details:
Francis Searchlights Ltd
Union Road, Bolton
Lancashire, BL2 2HJ, UK
Tel:
+44 (0) 1204 558960
Fax:
+44 (0) 1204 558979
http://www.francis.co.uk
E-mail: sales@francis.co.uk
Manual Part Number: C27703
A6144 – 24v DECK
A6162 – 24v CABIN
Issue: 1
6.2.18
Distributor details:
Advertisement
Table of Contents
Summary of Contents for Francis A6138
- Page 1 User Instruction & Installation Manual L230 LED 90 Watt Searchlight Product Reference Number: A6138 – 240v DECK A6144 – 24v DECK A6161 – 240v CABIN A6162 – 24v CABIN Manufacturer’s details: Distributor details: Francis Searchlights Ltd Union Road, Bolton Lancashire, BL2 2HJ, UK...
-
Page 2: Table Of Contents
CONTENTS - Introduction - Safety Precautions - Technical Information - Unpacking and Installation Instructions - Electrical Installation - Operating Instructions - Fault Finding - Maintenance and Servicing - Wiring Diagrams & General Assemblies - Spare Parts List Back To Top... -
Page 3: Introduction
For your future reference please keep this manual in a safe place. Thank you for specifying a product from the Francis Searchlights range. All Francis products are designed to give complete customer satisfaction and are manufactured to the highest engineering standards in order to ensure optimum performance and service life. -
Page 4: Safety Precautions
2 - Safety Precautions The following instructions must be adhered to, in order to ensure a safe working environment and the safety of the user. Note: When unpacking or manoeuvring the searchlight into its fixing position, suitable lifting points must be used in order to prevent damage to the equipment or personal injury. -
Page 5: Unpacking And Installation Instructions
4 - Unpacking and Installation Instructions The following instructions should be read and fully understood prior to installing the equipment to ensure that the correct procedures are followed, and all safety precautions are observed. Note: If the equipment has been in storage for a considerable amount of time, it is advisable to conduct a routine maintenance check on all parts before installation. - Page 6 Fitting Instructions for Lite Range Cabin Model Preparing the Mounting Position Using the template provided mark out and drill the fixing holes through the deck or cabin roof. In the case of cabin control models, a centre hole is also required to allow the mechanism to pass through.
- Page 7 5. Remove the Blanking Plug 6. Insert the Under Deck through the centre hole making sure it’s aligned as photos below from the Bellows Bottom Bush. 7. Fasten the Under Deck mechanism Using the 3 off M6 x 16 screws 8.
- Page 8 9. Bellows Top Bush. 10. Bellows 11. M12 plain washer. U-Piece Assy. M8 plain washer. M8 nyloc nut. 12. Make sure the mechanism is in this position before tightening the M5 x 8 hexagon screw onto the flat of the push rod 13.
- Page 9 For Pedestal Models: Mark out and drill through cabin roof using the template provided. Remove the cable gland in the base and replace with the blanking plug supplied. Secure the pedestal to the deck using appropriate fixings and then mount the searchlight to the pedestal and secure using the fixings provided.
-
Page 10: Electrical Installation
5 - Electrical Installation For safety purposes, only competent personnel should perform the electrical installation. All equipment should be installed to current Electrical Regulations and Standards. In order to obtain the maximum light output from the searchlight, it is essential that the full operating voltage of the LED fitted be applied to the LED contacts. -
Page 11: Operating Instructions
6 - Operating Instructions This equipment is designed for use out of doors, in free air. Never place anything on or cover the searchlight when in use as this may present a hazard. The beam of the searchlight cannot be adjusted. This product should not be used for any purpose other than for which it was designed. -
Page 12: Wiring Diagrams & General Assemblies
9 - Wiring Diagrams & General Assemblies Drawing Number Description A6138/A6144 L230 LED 90w Deck GA A6161/A6162 L230 LED 90w Cabin GA C27105 Wiring Diagram 100-240v C27106 Wiring Diagram 24v C27095 Junction Box Assembly... -
Page 18: Spare Parts List
24v to 240v Inverter In order to prolong the life and performance of your product, we recommend that you only specify Francis Searchlights spare parts. This will ensure that any warranties on your equipment will not be invalidated. When ordering spare parts please contact the Sales Department at Francis Searchlights Limited.
