Related Manuals for Coast-Air CED-301B
Summary of Contents for Coast-Air CED-301B
- Page 1 Installation and Operation Instruction Manual Dehumidifier CED-301B CED-501B CED-701B www.coastair-ac.com...
-
Page 2: Table Of Contents
Installation and Operation Instruction Manual CED-301-501-701B Dehumidifier CONTENTS Contents P r e p a r a t i o n - - - - - - - - - - - - - - - - - - - - - - 3 S a f e t y P r e c a u t i o n s - - - - - - - - - - - - - - - - - 5 C a u t i o n s... -
Page 3: Preparation
CED-301-501-701B Dehumidifier Installation and Operation Instruction Manual PREPARATION Preparation Control Panel Air Intake Grille Air Filter Air Outlet Grille (behind the grille) Power Cord Band Drain Hose Outlet Water Bucket Power Cord Power Plug F r o n t R e a r www.coastair-ac.com... - Page 4 Installation and Operation Instruction Manual CED-301-501-701B Dehumidifier PREPARATION Preparation NOTE: The unit you purchased may be look like one of the following: www.coastair-ac.com...
-
Page 5: Safety Precautions
CED-301-501-701B Dehumidifier Installation and Operation Instruction Manual Safety Precautions This symbol indicates that ignoring instructions may cause death or serious injury. WARNING: To prevent death or injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause death, harm or damage. - Page 6 Installation and Operation Instruction Manual CED-301-501-701B Dehumidifier Safety Precautions WARNING: To prevent death or injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause death, harm or damage. Electrical Information: -The manufactures nameplate is located on the rear people,and people not senstive to humidity.
-
Page 7: Cautions
CED-301-501-701B Dehumidifier Installation and Operation Instruction Manual Cautions Cautions -This appliance can be used by children aged from 8 years and above and person with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 8 Installation and Operation Instruction Manual CED-301-501-701B Dehumidifier Cautions Cautions accumulates around the unit, it may cause fire. -If the appliance is knocked over during use, turn off the unit and unplug it from the main power supply immediately. Visually inspect the unit to ensure there is no damage. If you suspect the unit has been damaged, contact a technician or customer service for assistance.
-
Page 9: Operation
CED-301-501-701B Dehumidifier Installation and Operation Instruction Manual OPERATION Operation Place correctly Smart functions: -This unit is designed to operate with a working -Auto Shut Off environment between 5°C(41°F) and 35°C(95°F). When the bucket full indicator light illuminates and the setting humidity is reached, the unit will be shut off automatically. - Page 10 Installation and Operation Instruction Manual CED-301-501-701B Dehumidifier Operation NOTE: The control panel may be look like one of the followings: Mode Mode button Press to select the desired operation mode from Dehumidifying,Continuous dehumidifying and Filter Turbo Filter Comfort dehumidifying. Full Comfort At Comfort dehumidifying mode, the unit will Mode...
- Page 11 CED-301-501-701B Dehumidifier Installation and Operation Instruction Manual OPERATION Operation Timer Timer button Timer Turning the unit ON or OFF at any time or adjusting Press to initiate the Auto start and Auto stop feature, the timer setting to 0.0 will cancel the Auto Start/Stop in conjunction with the buttons.
- Page 12 Installation and Operation Instruction Manual CED-301-501-701B Dehumidifier OPERATION Operation LED display Removing the collected water Shows the set % humidity level from 35% to 85% There are two ways to remove collected water: or auto start/stop time (0~24) while setting, then 1.Use the bucket shows the actual (±5% accuracy) room % humidity When the bucket is full, remove the bucket and empty it.
-
Page 13: M A I N T E N A N C
CED-301-501-701B Dehumidifier Installation and Operation Instruction Manual OPERATION MAINTENANCE Operation Maintenance Care and cleaning of the dehumidifier WARNING: Turn the dehumidifier off and remove the plug from the wall outlet before cleaning. Clean the bucket Plastic cover Clean the bucket with water every few weeks. Clean the air filter Connector Drain hose... -
Page 14: Fault Diagnosis
Installation and Operation Instruction Manual CED-301-501-701B Dehumidifier FAULT DIAGNOSIS Fault Diagnosis Please check the following problems and possible causes before seeking maintenance: Fault Diagnosis What to check -Make sure the dehumidifier's plug is pushed completely into the outlet. -Check the house fuse/circuit breaker box. Unit does not start -Dehumidifier has reached its preset level or bucket is full. -
Page 15: Product Disposal
CED-301-501-701B Dehumidifier Installation and Operation Instruction Manual PRODUCT DISPOSAL Sociable Remark When using this dehumidifier in European countries, the following information must be followed: DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. It is prohibited to dispose of this appliance in domestic household waste. - Page 16 Installation and Operation Instruction Manual CED-301-501-701B Dehumidifier THIS PAGE INTENTIONALLY LEFT BLANK www.coastair-ac.com...
-
Page 17: Warranty
Coast-Air shall have the right to allow a credit in the amount of the current suggested retail price of the product instead of LIMITED ONE (1) YEAR EXPRESS WARRANTY providing replacement. - Page 18 www.coastair-ac.com 12/2018...
