Page 2
Safety information IB-2242U2K Please read carefully the following information to prevent injuries, damage to material and device as well as data loss: Warning levels Signal words and safety codes indicate the warning level and provide immediate information in terms of the probability of occurrence as well as the type and severity of the consequences if the measures to prevent hazards are not complied with.
Page 3
Safety information IB-2242U2K • Avoid direct sunlight on the device/power unit • Guarantee sufficient ambient air for the device/power unit • Do not place objects on the device/power unit 4. Hazards caused by very small parts and packaging Risk of suffocation...
Page 4
Sicherheitshinweise IB-2242U2K Zur Vermeidung körperlicher Schäden, sowie von Sach-, Geräteschäden und Datenver- lust beachten Sie bitte folgende Hinweise: Warnstufen Signalwort und Sicherheitszeichen kennzeichnen die Warnstufe und geben einen sofortigen Hinweis auf Wahrscheinlichkeit, Art und Schwere der Folgen, wenn die Maßnahmen zur Vermeidung der Gefahr nicht befolgt werden.
Page 5
Sicherheitshinweise IB-2242U2K • externe Erwärmung vermeiden und Luftaustausch zulassen • Lüfter-Auslass und passive Kühlkörper freihalten • direkte Sonneneinstrahlung auf Gerät/Netzteil vermeiden • ausreichend Umgebungsluft für Gerät/Netzteil sicherstellen • keine Gegenstände auf dem Gerät/Netzteil abstellen 4. Gefahren durch Kleinstteile und Verpackung...
Page 6
Manual IB-2242U2K Product overview / Produktübersicht Front view / Frontansicht LED indicator/ LED Anzeige Lock/ Schloss Tray release latch/ Schachtverriegelung Tray door/ Schachttür Back view / Rückansicht Fan Switch/ Lüftungsschalter Fan/ Lüfter SATA power port/ SATA Stromanschluss Mini SAS HD port/ Mini SAS HD Anschluss...
Page 7
Manual IB-2242U2K Package Content 1x IB-2242U2K, 8x frame screw, 16x HDD tray screw, 2x key, 1x manual *cables not included! Key Features • Host connector: 4x U.2 / Mini SAS HD (SFF-8643) • Supports U.2 (SFF-8639) SSD, up to 32 Gbit/s •...
Manual IB-2242U2K Hardware installation Turn OFF the PC and any other connected peripheral devices. Unplug the power cable from the back of the PC and remove the cover of your PC. Remove the panel from the available 5.25" bay. Insert the Backplane into the bay and fix it with 2 screws on each side.
Manual IB-2242U2K Replace the PC cover and reconnect the power cable of the PC. The backplane is now ready for use. Note: A new SSD must first be initialized, partitioned and formatted in the operating system in order to be recognized and displayed by the system.
Page 10
Handbuch IB-2242U2K Verpackungsinhalt 1x IB-2242U2K, 8x Rahmenschrauben, 16x Festplattenschrauben, 2x Schlüssel, 1x Handbuch *Kabel sind nicht im Lieferumfang enthalten! Hauptmerkmale • Hostanschluss: 4x U.2 / Mini SAS HD (SFF-8643) • Unterstützt U.2 (SFF-8639) SSD, bis zu 32 Gbit/s • Vollaluminium und Metall Backplane für 5,25" Schacht •...
Page 11
Handbuch IB-2242U2K Hardware Installation Bitte schalten Sie den PC und alle anderen angeschlossenen Peripheriegeräte aus! Ziehen Sie das Netzkabel von der Rückseite des PCs ab und entfernen Sie die Abdeckung Ihres PCs. Entfernen Sie nun das Panel des verfügbaren 5,25" Schachts.
Page 12
Handbuch IB-2242U2K Anschließend bringen Sie die PC Abdeckung wieder an und stecken das Netzkabel des PCs an. Die Backplane ist nun betriebsbereit. Hinweis: Eine neue SSD muss im Betriebssystem erst initialisiert, partitioniert und formatiert werden, um vom System erkannt und angezeigt zu werden.
