Bushnell 78-4501 Instruction Manual

Bushnell 78-4501 Instruction Manual

114mm reflector
Hide thumbs
Table of Contents

Advertisement

Quick Links

Telescope
Instruction
Manual
78-4501 114mm RefLECtor
Lit. #: 91-0246/06-01

Advertisement

Table of Contents
loading

Related Manuals for Bushnell 78-4501

Summary of Contents for Bushnell 78-4501

  • Page 1 Telescope Instruction Manual 78-4501 114mm RefLECtor Lit. #: 91-0246/06-01...
  • Page 2 Never Look Directly At The Sun With Your Telescope ❂ Permanent Damage To Your Eyes May Occur...
  • Page 3 WHERE DO I START? Your Bushnell telescope can bring the wonders of the universe to your eyes. While this manual is intended to assist you in the set-up and basic use of this instrument, it does not cover everything you might like to know about astronomy. It is recommended you obtain a very simple star chart and a flashlight with a red bulb or red cellophane over the end.
  • Page 4 3. Telescope Main Tube 4. Primary Mirror (Internal) 5. Latitude Lock Knob 6. Tripod Leg 7. Accessory Tray Brace 8. Accessory Tray 78-4501 114mm Reflector Telescope Parts Diagram 9. Tripod Leg Lock 10. Declination Lock Knob 11. Counterweight Shaft 12. Counterweight 13.

  • Page 5: Parts List

    Reflector Counterweight 1. Spread tripod legs and attach accessory tray. 2. Attach telescope tube to pre-assembled Equatorial Mount with pre-attached tripod legs. 3. Attach Fine Adjustment Knobs. 4. Attach counterweight over counterweight shaft and attach to Equatorial Mount. 5. Attach Finderscope over mounting bolts and replace attachment nuts.
  • Page 6 Locate the Finderscope with pre-assembled Finderscope Mount. Remove the two nuts located near the front of the telescope (closest to the eyepiece) and place the Finderscope and Finderscope Mount over the exposed screws. Replace the nuts, and securely tighten the Finderscope and Finderscope Mount in place.
  • Page 7 900 mm / 20mm = 45x or 45 power. Telescope models will vary in focal length.) Included with this telescope is a Barlow lens. Barlow lenses are used to double or triple the power of your telescope. Place your Barlow between the focusing tube and the eyepiece.
  • Page 8 Loosen the Horizontal Axis Lock Knob again and turn the telescope so that it is directly aimed at Polaris. Tighten both the Horizontal Axis Lock Knob and Latitude Lock Knob. Polaris is 1 degree from the North celestial pole.
  • Page 9 Saturn, Mars, Jupiter, and Venus are good second steps to take. 2. The first thing you need to do after assembling the telescope as planned is center the desired object in the finderscope’s crosshairs. Provided you did a reasonable job aligning the finderscope, a quick look through the main telescope tube at low power should reveal the same image.

  • Page 10: Helpful Hints

    1. Your telescope is a very sensitive instrument. For best results and fewer vibrations set your telescope up on a level location on the ground rather than your concrete driveway or your wooden deck. This will provide a more stable foundation for viewing, especially if you’ve drawn a crowd with your new telescope.
  • Page 11 NOTES...
  • Page 12 www.bushnell.com...
