TV ANTENNA VHF UHF FM
TECHNICAL DATA:
• Frequency Range: VHF: 54~230MHz / UHF: 470~862MHz
• Channels: VHF: 2-13 / UHF: 14-69 / FM: 87-108
• Impedance: 75Ω
• No. of Elements: 29
• Antenna Gain: VHF: 9dBi / UHF: 15dBi
• Front-Back Ratio: VHF: 15dB / UHF: 20dB
• Bean Width: 70° / 40°
• Antenna Length: 57 in
• Range: ~175 miles (Based on open and clear terrain. Individual results will vary.)
ANI-273LR
Page 1 of 8, ANI-273LR v1.6 07/2020
Instruction Manual
Advertisement
Table of Contents
Related Manuals for AVI-AV ANI-273LR
Summary of Contents for AVI-AV ANI-273LR
- Page 1 • Front-Back Ratio: VHF: 15dB / UHF: 20dB • Bean Width: 70° / 40° • Antenna Length: 57 in • Range: ~175 miles (Based on open and clear terrain. Individual results will vary.) Page 1 of 8, ANI-273LR v1.6 07/2020...
- Page 2 • Short Coax 12 inches (30cm) connects UHF to the combiner. • Long Coax 24 inches (60cm) connects VHF/FM to the combiner. • Connect your Television down-lead to the remaining open port on the combiner. Page 2 of 8, ANI-273LR v1.6 07/2020...
- Page 3 Instruction Manual ANI-273LR TV ANTENNA VHF UHF FM ANTENNA CONNECTION: FRONT: (POINT TOWARDS BROADCAST TOWER) Page 3 of 8, ANI-273LR v1.6 07/2020...
- Page 4 Instruction Manual ANI-273LR TV ANTENNA VHF UHF FM ANTENNA CONNECTION: Page 4 of 8, ANI-273LR v1.6 07/2020...
- Page 5 17. Overloading - Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock. Page 5 of 8, ANI-273LR v1.6 07/2020...
- Page 6 23. Wall or Pole Mounting - The product should be mounted to a wall or pole only as recommended by the manufacturer. 24. Heat - The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat. Page 6 of 8, ANI-273LR v1.6 07/2020...
- Page 7 THIS PAGE IS INTENTIONALLY LEFT BLANK.
- Page 8 PROPER GROUNDING AND, IN PARTICULAR SPECIFIES THAT THE CABLE GROUND SHALL BE CONNECTED TO THE GROUNDING SYSTEM OF THE BUILDING, AS CLOSE TO THE POINT OF CABLE ENTRY AS PRACTICAL. 122 Rose Ln., Suite 303 | Frisco, Texas 75036 www.ANI-AV.com Page 8 of 8, ANI-273LR v1.6 07/2020...
