- Page 1 TLX CSS-SUB1 POWERED SUBWOOFER SERVICE MANUAL THE TLX CS-SUB1 SUBWOOFER IS PART OF THE TLX CS-SP1OOO SYSTEM JBL Consumer Products 250 Crossways Park Dr. Woodbury, New York 11797 Rev0 8/2002...
- Page 2 TEST PROCEDURE ……………………….….………..…………..5 PARTS LIST ……………..…………..………………..…………6 IC BLOCK DIAGRAMS ……………………………………………..…7 SCHEMATICS ..………..……… ……………….…………………..8 PACKING ……………………………………………………………..11 TLX CSS-SUB1 SPECIFICATIONS Driver Low Frequency 8” Woofer (Nominal Impedance 8 W) DCR = 7.0 W Enclosure Design Bass Reflex Amplifier Power 75 watts RMS 45Hz - 150Hz (±...
- Page 5 TLX CSS-SUB1 TEST PROCEDURE Equipment needed: · Function/signal generator/sweep generator · Integrated Amplifier · Multimeter · Speaker cables General Function UUT = Unit Under Test Connect one pair of speaker cables to either high level input terminal on UUT. Cables should be connected to an integrated amplifier fed by the signal generator.
- Page 6 TLX CSS-SUB1 PARTS LIST MECHANICAL/PACKING PARTS LIST Reference Part Number Description Quan. 15-30-4262-00 Owner’s manual for TLX CS-SP1000 CABINET Not for Sale Enclosure DRIVER 44421 8” Woofer Feet 846-7652 or 15-71-4039-00 Plastic Feet A3D1F03U1013 Complete Amplifier Assembly TM501 CO1334 High Level Input Terminal Block...
