TV Wall Mount Instruction Manual
V4.0
Model: APPSMTK1
Thank you for choosing this Alphamount product! At Alphamount we strive
to provide you with the best quality products and services in the industry.
Should you have any issues, please don't hesitate to contact us at
Email: support@alphamount.com (US/CA/DE/UK/FR/IT/ES/AU)

Advertisement

loading
Need help?

Need help?

Do you have a question about the APPSMTK1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Am APPSMTK1

  • Page 1 TV Wall Mount Instruction Manual V4.0 Model: APPSMTK1 Thank you for choosing this Alphamount product! At Alphamount we strive to provide you with the best quality products and services in the industry. Should you have any issues, please don't hesitate to contact us at...

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION Please carefully read all instructions before attempting installation. If you do not understand the instructions or have any concerns or questions, please contact our customer service at support@alphamount.com. CAUTION: Avoid potential personal injuries and property damage! • Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3 Tools Needed (Not lncluded) Philips Stud Finder Tape Measure Pencil Level Drill Screwdriver 3/8 in. (10mm) 7/32 in. (5.5mm) 3/8 in. (10mm) Hammer 1/2in. (13mm) Wrench Wood Drill Concrete Drill Socket Wrench Supplied Parts and Hardware Warning: This product contains small items that could be a choking hazard if swallowed.
  • Page 4 TV Bolts (Only one bolt size fits your TV) Note: The bolts are shown in accordance with the actual size M4x30mm M6x15mm M6x30mm M8x15mm M8x45mm Supplied Parts and Hardware for Step 2 Wall Plate Note: The lag screw is shown in accordance with the actual size Lag Screw M8x50 mm Washer...
  • Page 5 Step 1 Secure the TV Brackets to TV Select TV Bolts Only one bolt size fits your TV. Bolt length: Verify adequate thread engagement with bolts or bolts/spacers combination. We recommend thread engagement by at least 5 turns. -Too short will not hold the TV. -Too long will damage the TV.
  • Page 6 Option A (For Flat Back G/H/J Alternate Spacer Setups Note: Keep the arrow up Option B (For Round Back TV) G/I/K Alternate Spacer Note: Keep the arrow up Setups...
  • Page 7 Option C (For TV with A “Bump”) Spacers may be necessary for 2 holes ONLY. G/I/K F/D2/E2/E3 (If needed) G/H/J B2/B3/B4 Alternate Spacer Setups Alternate Spacer Note: Keep the arrow up Setups Option D For cable interference or inset holes, use spacers [E] and [F] to create extra space between the TV and TV brackets.
  • Page 8 Step 2 Attach the Wall Plate [01] to Wall For wood stud installation, follow STEP 2A For concrete installation, follow STEP 2B Step 2A Wood Stud Option WARNING: Avoid potential personal injury or property damage! DO NOT over-tighten the lag screws [A]. Tighten the lag screws [A] only until the washers [B] are pulled firmly against the wall plate [01].
  • Page 9 2A-2 Position the wall plate at your desired height and line up the holes with your stud center line. Level the wall plate and mark the holes. 2A-3 Drill 4 pilot holes using a 7/32 in (5.5mm) diameter drill bit. Make sure the depth is not less than 2 in.
  • Page 10 Step 2B Solid Concrete or Concrete Block Option WARNING: Avoid potential personal injury or property damage! DO NOT over-tighten the lag screws [A]. Tighten the lag screws [A] only until the washers [B] are pulled firmly against the wall plate [01]. Ensure the wall plate is securely fastened to the wall before continuing to the next step.
  • Page 11 2B-3 Use the hammer to knock Install wall plate [01] using lag screws [A] anchors [C] into the wall. Be and washers [B]. DO NOT over-tighten sure the anchors [C] are the lag screws [A]. Tighten the lag seated flush with the screws [A] only until the washers [B] are concrete surface.
  • Page 12 Step 4 Secure the TV onto the Wall Plate HEAVY! You may need assistance with this step. Wall Locking To Hang TV onto Wall Plate 1. Hang the TV with brackets [02] and [03] onto the wall plate [01]. 2. While pulling and hold both ropes [R] , press the bottom of the TV into the wall plate [01] until the latches lock the TV brackets [02] and [03], then release the ropes.
