Installation Instructions
ControlKeeper® TouchScreen Logic Board
La Carte Logique du ControlKeeper® TouchScreen
La Placa Lógica ControlKeeper® TouchScreen
General Information
The ControlKeeper TouchScreen Logic Board is shipped
separately from the enclosure to protect the components
during shipping and enclosure installation. Enclosure
installation instructions have been provided for the
enclosure. Please refer to the enclosure installation
instructions for instructions on mounting the enclosure
as well as wiring loads to the relays. This document
discusses the mounting and connection of the
ControlKeeper T into the enclosure and assumes that this
step has been completed.
Getting Started
1. Do not discard these installation instructions. Please
keep for future reference and operation information.
2. It is recommended that all low voltage wiring be
done with power removed to the logic board to
protect components from potential shorts during the
wiring process.
3. Use only as intended and at the listed voltage.
4. All installation and service must be performed by
qualified personnel or service technicians.
5. Install in accordance with the National Electrical Code
and any other codes which may apply.
6. Installation and wiring information contained in this
document is based on industry-accepted standards
and practices. If conflicts exist between these
instructions and any applicable codes or ordinances,
please contact Greengate before proceeding with the
installation.
7 . High voltage is present inside the enclosure. Use
extreme caution when performing maintenance on
this equipment. Failure to follow this warning and
proper safety procedures could result in severe injury
or death and/or damage to the equipment.
Model# CKT LB
8. Document all wiring and device terminations and
locations so that devices can be properly configured
and programmed for operation.
Mounting the Logic Board in the Enclosure
The enclosure should have been mounted prior using the
installation instructions provided for this purpose. It is
recommended that the ControlKeeper T not be put into
the enclosure until all drilling is complete in the cabinet.
1. Remove all debris and metal shavings from the
enclosure.
2. Make certain that there is no high voltage wiring
exposed or in the space of the low voltage section of
the enclosure.
3. If you are using a 32 or 48 size enclosure, make
certain that the upper backplate is in place, securing
the backplate with the 1/4 turn screws as directed in
the enclosure installation instructions.
4. Press and hold the two spring hinges on the back of
the logic board backplate towards the middle of the
plate.
5. Making sure there are no cables caught beneath
the logic board, slide the logic board into the bottom
of the enclosure in the mounting space provided,
lining the spring hinges up with the mounting holes,
releasing the spring hinges once the logic board is in
place.
6. Swivel the logic board up, using the spring hinge at
the top of the board to secure the board to the top of
the enclosure or upper backplate in the slot provided.
7 . Connect the ground strap connection at the bottom
left of the circuit board to the ground strap connector
of the enclosure.
8. Do not connect RSC connections until after all low
voltage connections are made. Please see next
section for further instructions
INS #
