Programmable DC Electronic Load
LP Series
User Manual
Manual Part NO. 018LP-2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LP Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ODA LP Series

  • Page 1 Programmable DC Electronic Load LP Series User Manual Manual Part NO. 018LP-2.0...
  • Page 2 ODA shall not be liable for errors or for incidental or be liable for errors or for incidental or consequential damages in connection with the furnishing, use, or performance of this document or of any information contained herein.
  • Page 3 Failure to comply with these precautions or with specific warnings or instructions elsewhere in this manual violates safety standards of design, manufacture, and intended use of the instrument. ODA Technologies assumes no liability for the customer's failure to comply with these requirements. General...
  • Page 4 Safety Symbol Direct current Alternating current Both direct and alternating current Three phase alternating current Earth (ground) terminal Protective earth ground terminal. Frame or chassis terminal Terminal is at earth potential. Neutral conductor on Line conductor on permanently installed permanently installed equipment. equipment Standby supply.

  • Page 5: Table Of Contents

    CONTENTS 1. General Information 1-1. Feature -------------------------------------------------------- General Feature Remote Interface Characteristics Calibration Factory Function 1-2. Accessories and Options -------------------------------------------------- Accessories Option 1-3. Inspecting the Unit ------------------------------------------------------- Instrument Check Electrical Check 1-4. Operating Conditions ---------------------------------------------------- Check Before Power On ---------------------------------------------------- Output Terminal Check Input AC Power Line Check 1-6.
  • Page 6 3. Front-Panel Operating Overview ----------------------------------------------------------------- 3-1. IN ON/OFF ------------------------------------------------------------ 3-2. Constant Current Operating (CC) ------------------------------------------ 3-3. Constant Resistance Operating (CR) --------------------------------------- 3-4. Constant Voltage Operating (CV) ------------------------------------------ 3-5. IO/Local -------------------------------------------------- 18 RS232C Setting RS232C Configuration RS485 Setting RS485 Configuration USB Setting 3-6.
  • Page 7 3-17. STEP -------------------------------------------------------------- STEP NUMBER MODE Set VALUE SETTING SLOPE TIME SETTING DELAY TIME SETTING 3-18. REP (REPEAT) ------------------------------------------------------- 3-19. SEQ (SEQUENCE) ---------------------------------------------------- START NUMBER FINISH NUMBER 3-20. FUSE RUN --------------------------------------------------------- 3-21. FUSE STEP --------------------------------------------------------- FUSE TIME FUSE CURRNET 3-22. Error Message Display ------------------------------------48 3-23.
  • Page 8 4-6. Remote Interface Calibration -------------------------------------------- Current Calibration Voltage Calibration 5. FACTORY 5-1. Characteristic --------------------------------------------------------- 5-2. FACTORY KEY Structure ----------------------------------------------- 5-3. USER-MEM CLEAR ------------------------------------------------- 5-4. LAST STATE -----------------------------------------65 5-5. AUTO KEY LOCK -----------------------------------------66 5-6. CAL-DEFAULT -------------------------------------------- 67 5-7. CAL-RESTORE -------------------------------------------- 68 5-8.

  • Page 9: General Information

    1. General Information 1-1. Feature LP Series is a highly efficient, programmable electric load (300W~1500W Capacity). It has RS-232C, RS-485, USB Remote control interface based on SCPI Protocol. (Standard Commands for Programmable Instruments) General Feature ▌Easy-to-use knob control settings. ▌Big size 20Char LCD Display ▌Output ON/OFF Key.

  • Page 10: Accessories And Options

    1-2. Accessories and Option Accessories ▌1.5M Output cable 1 pc ▌Rack mount ▌Voltage Sensing Short bar 2 pc ▌User's Manual 1 pc. Option ▌RS232C Cable 1M, 2M, 4M ▌RS485 Cable 2/4/8-Channel 1M, 2M, 4M, 10M ▌AC Input Cable (Special order type) ▌Output Cable (Special order type) - 2 -...

  • Page 11: Inspecting The Unit

    Sales Office immediately. Warranty information is shown in the front of the manual. Keep the original packing materials in case the electric load has to be returned to ODA Technologies in the future. If you return the electric load for service, attach a tag identifying the owner and model number.

  • Page 12: Check Before Power On

    1-6. Check After Power On Turn on the power and load will be set in the previous setting value. Display Procedure on the LCD ▌Display "ODA Technologies" ▌Display "LP" ▌Annunciators of ERR, LMT, RMT, LOCK on front side are lit and go off.

  • Page 13: Installation

    1-7. Installation Cooling ▌Load's quality is guaranteed in the circumstances of 0℃ ~ 40℃. If you use 40℃ ~ 55℃ circumstances, please lower the output current to 0~70% of maximum current. If you use load by installing in the rack, please keep attention to ventilation. <Figure 1-4 Bottom view>...

  • Page 14: Front Panel, Rear Panel Composition & Function

    2. Front Panel, Rear Panel Composition & Function 2-1. Front Panel Composition 1 Power Switch 18 Slew 2 Ventilation slit 19 IO/Local 3 20Char *2Line LCD Display 20 Short On/Off 4 CC Mode Lamp 21 Recall , Save Key 5 CR Mode Lamp 22 ESC &...
  • Page 15 1. POWER switch. The load is turned on or off by this switch. It is adopted by following electric load's capacity. 2. Ventilation slit. Air flow flows from front ventilation slit to rear ventilation slit compulsorily. 3. 20Char * 2Line Type LCD Display Voltage/current and, all kinds menu/message displayed.
  • Page 16 13. Left cursor Key Move cursor to the left direction. 14. Right cursor Key Move cursor to the right direction. 15. Input voltage/current On/Off Key Enables and disables the load input voltage/current. 16. Mode Setting Key Adjust the Mode setting (CC mode, CR mode, CV mode). 17.
  • Page 17 24. A-Memory Setting, Calibration mode If you're in Dynamic Mode, This key function as A-Memory Setting Key. Press for 3 seconds and set the A-Memory Setting For the Calibration, Power on the load with pressing this key. You can enter to calibration mode. In this mode, you can do calibration of current, voltage.

  • Page 18: Rear Panel Composition

    2-2. Rear Panel Composition 1 - Input bus bar 8 RS485 Interface Port 2 + Input bus bar 9 USB 2.0 Interface Port 3 External Option Input, Output 10 AC Input 4 V-Sensing Setting S/W 11 Ventilation Slit 5 Firmware Connector 6 Firmware download switch 7 RS232C Interface Port 1.
  • Page 19 4.V-Sensing Setting S/W Switch for V-Sensing or Normal mode. 5.Firmware Connector Firmware download port. For downloading, please check if download switch is up. 6.Firmware download switch Able and disable firmware download ( Up : available Down : not available ) 7.

  • Page 20: Front-Panel Operating

    3. Front-Panel Operating If there's no change for 5 seconds, local mode will be automatically started. Set the menu and Save the menu setting by each menu key Overview 1. IN ON/OFF Explain about input on/off. 2. Constant Current Operation(CC) Explain about the operating constant current output mode.
  • Page 21 3-15. SHORT Explain about short function. 3-16. CYC RUN Explain about run function in cycling mode. 3-17. STEP Explain about setting step in cycling mode. 3-18. REP (REPEAT) Explain about repeat setting in cycling mode. 3-19. SEQ (SEQUENCE) Explain about sequence setting in cycling mode. 3-20.

  • Page 22: In On/Off

    3-1. IN ON/OFF Connect and disconnect the input current to the load. So, you can disconnect the input current without eliminating source. Following is about using In ON/OFF function. (Last State Mode is Disabled ) ▌Power Switch ON Turn on load and check load is in OFF MODE. ▌Initially, IN OFF Status.

  • Page 23: Constant Current Operating (Cc)

    3-2. Constant Current Operating (CC) To set up the power supply for constant current (CC) operation, proceed as follows. ▌Turn on the power supply. After turned on, check the power supply displays ▌Connect power and load(wire,condensor, motor) to the load. ▌Press Mode key and enter to CC Mode.

  • Page 24: Constant Resistance Operating (Cr)

    3-3. Constant Resistance Operating (CR) To set up the load for constant Resistance operation, proceed as follows. ▌Turn on the load. After turned on, check the load is in Off Mode. ▌Connect power and load(wire,condensor, motor) to the load. ▌Press Mode key and enter to CR mode. MODE On the left bottom in display panel, "OFF-RSET"...

  • Page 25: Constant Voltage Operating (Cv)

    3-4. Constant Voltage Operating (CV) To set up the load for constant Voltage operation, proceed as follows. ▌Turn on the load. After turned on, check the load is in Off Mode. ▌Connect power and load(wire,condensor, motor) to the load. ▌Press Mode key. And enter to CV Mode. MODE On the left bottom on display, "OFF-VSET"...

  • Page 26: Io/Local

    3-5. IO/Local To configure the power supply for the RS-232, RS485, USB and TCP/IP interface. RS232C, RS485 and USB interface is standard, in case of TCP/IP, it is optional. When the load is shipped, I/O interface is set the RS232C protocol and baud rate is 9600bps. Communication setting is only able to be set by front panel key.

  • Page 27: Rs232C Configuration

    RS232C Configuration ▌RS232C are fixed as following. Data Bit : Stop Bit : Parity Bit : None ▌RS232C Data Frame Stop Start 8 Data Bits ▌For connect the power supply of RS485 type, Standard cross cable (Female type ) is necessary. Below is connection drawing of female type cross cable. "Refer to chapter 1-2.

  • Page 28: Rs485 Setting

    RS485 Setting It is possible to control up to 255 devices include remote device after connected each devices by parallel interface method. RS485 setting procedure. ▌Turn on the load. After turned on, check the load in in OFF mode. IO/LOCAL ▌Press "I/O"...

  • Page 29: Rs485 Configuration

    RS485 Connection Drawing ▌RS 485 connector consists of 4 pin one-touch terminal and below figure 3-5 is rear side view. Pin Description Description DC +5V/0.2A Output Data + Data - GND(Earth Ground) < Figure 3-5 > RS485 Configuration ▌To connect RS485 Line to Remote device, you need to prepare extra wire for harness. Below figure is a wire diagram of connecting remote device and electric load by 485 to 232c converter.

  • Page 30: Usb Setting

    "USB Save Done…" will be displayed. Now, USB setting is finished. Note1 For making window application, please install ODA USB Driver. Driver is not included in the package, you can download the latest Driver in Web site. Note2 Use Standard USB Cable.

  • Page 31: Range

    3-6. Range In the CC Mode, CR Mode, There's a Range. Refer Specification sheet for further information about Range. ▌Turn on the load. Check the load is in OFF MODE. RANGE ▌Set the Range. ≫ Related Remote Interface Command CURR:RANG:{<L>,<H>} RES:RANG:{<L>,<M>,<H>} Application 1: CURR:RANG L...

  • Page 32: Save

    3-7. Save You can save current load status in "User Memory". There are 10 user memory and Mode status, Range, Voltage, Current, Slew Level, A-Memory, B-Memory, DUTY, Cycling Time value will be saved. Below is the process of saving data in user memory. Save Key also provide Software Calibration function.

  • Page 33: Recall

    3-8. Recall Recall function is recalling the data in 『non-volatile memory』. There are 01~10 location in non-volatile memory and you can recall mode state, Range, Voltage, Current, Slew Level, A-Memory, B-Memory, DUTY, FREQ setting value. ▌Power Switch ON Turn on load and check load is in OFF MODE. REC/SAVE ▌...

  • Page 34: Esc

    3-9. ESC ESC is for menu cancellation , protection cancellation, Error check. Menu Cancellation - In case of cancellation of menu Section, press esc key and get back to previous state. Error Check - When error occurs, there will be beep sound and error led lamp will be on. Press ESC/ERR key to check error number.

  • Page 35: Dynamic On/Off

    3-10. DYNAMIC ON/OFF Dynamic mode allows voltage and current to change in high-speed. Users are able to set Cycle time, cycle duty to make pulse that user wants. ▌Power Switch ON Turn on load and check load is in OFF MODE. DYN /A ▌To proceed dynamic mode, press DYN/A one time shortly.
  • Page 36 3-11. SLEW Slew Rate function allows to control rising and falling speed of voltage and current. In CV Mode, you can control rising and falling speed of voltage. And in CC Mode, you can control rising and falling speed of current. Current SLEW Set ▌Power Switch ON Turn on load and check load is in OFF MODE.

  • Page 37: Slew

    Voltage SLEW Set ▌Power Switch ON Turn on load and check load is in OFF MODE. MODE ▌Press MODE Key and Set CV Mode. SLEW ▌Press SLEW/B and put SLEW mode on. ▌Use encoder to Set the level of slew. ▌To save the slew value, press slew key one more time.

  • Page 38: A-Memory

    3-12. A-Memory A-Memory key will save and recall the setting data (voltage and current) in A-Memory. ▌Power Switch ON Turn on load and check load is in OFF MODE. ▌To set A-Memory, press A key. ▌Use encoder to Set the value. ▌To save the value, press A key one more time.

  • Page 39: B-Memory

    3-13. B-Memory In dynamic mode, B-Memory will save and recall the data of Load to B-Memory. ▌Power Switch ON Turn on load and check load is in OFF MODE. ▌To set the B-Memory, press SLEW/B key. ▌Use encoder to set the value of B-Memory value. ▌To save the B-Memory, press SLEW/B key one more time.

  • Page 40: Dynamic Cycling Time / Duty

    3-14. Dynamic Cycling Time / Duty Dynamic Cycling Time - Set the cycling time of Dynamic Mode ▌Power Switch ON Turn on load and check load is in OFF MODE. CYC TIME ▌To set the Dynamic Cycling Time, press CYC TIME/DUTY key. /DUTY ▌Use encoder to set the value of Dynamic Cycling Time.
  • Page 41 DUTY - Set the value of Duty in Dynamic Mode. Duty will be set on 100% standard, and duty value will be set in Dynamic A. For example, if you set duty to 60%, dynamic A will be 60%, dynamic B will be 40%. ▌Power Switch ON Turn on load and check load is in OFF MODE.

  • Page 42: Short

    3-15. SHORT This is the explanation for SHORT. ▌Power Switch ON Turn on load and check load is in OFF MODE. INPUT ON ▌Press INPUT ON key. SHORT ▌Press SHORT key for 3 seconds. SHORT ▌To stop the Dynamic Mode, press SHORT key one more time. ≫...

  • Page 43: Cyc Run

    3-16. CYC RUN This function makes cycles run. ▌Power Switch ON Turn on load and check load is in OFF MODE. CYC RUN ▌To run Cycling mode, press CYC RUN key. CYC RUN ▌Press CYC RUN key to stop Cycling mode. ≫...

  • Page 44: Step

    3-17. STEP Set step in Cycling mode. You can set below setting menu. Setting 1. STEP NUMBER 2. STEP OFF Set 3. MODE Set 4. VALUE SETTING 5. SLOPE TIME SETTING 6. DELAY TIME SETTING After setting, please escape by pressing ESC key. 1.
  • Page 45 2. STEP OFF Set ▌Power Switch ON Turn on load and check load is in OFF MODE. STEP ▌Press STEP Key. ▌Set [2. STEP OFF Set] by cursor key. STEP ▌Press STEP Key. ▌Set STEP mode by cursor key. (INPUT ON or INPUT OFF Mode) STEP ▌Press STEP Key to save setting value.
  • Page 46 3. MODE Set ▌Power Switch ON Turn on load and check load is in OFF MODE. STEP ▌Press STEP Key. ▌Set [2. MODE Set] by cursor Key. STEP ▌Press STEP Key. ▌Set STEP Mode by cursor Key. STEP ▌Press STEP Key to save setting value. ≫...
  • Page 47 4. VALUE SETTING ▌Power Switch ON Turn on load and check load is in OFF MODE. STEP ▌Press STEP Key. ▌Set [3. VALUE SETTING] by cursor key. STEP ▌Press STEP Key. ▌Set Cycling Step by encoder. STEP ▌Press step key to save setting value. When you are in CC Mode, if one step is high current value, Range is high .
  • Page 48 5. SLOPE TIME SETTING ▌Power Switch ON Turn on load and check load is in OFF MODE. STEP ▌Press STEP Key. ▌Set [4. SLOPE TIME SETTING] by encoder. STEP ▌Press STEP Key. ▌Set slope time by encoder. STEP ▌Press step key to save setting value. SLOPE TIME SETTING is SLEW SETTING.
  • Page 49 6. DELAY TIME SETTING ▌Power Switch ON Turn on load and check load is in OFF MODE. STEP ▌Press Step key shortly. ▌Set [5. DELAY TIME SETTING] by cursor key. STEP ▌Press Step Key ▌Set the delay time by encoder. STEP ▌Press Step key to save the setting value.

  • Page 50: Rep (Repeat)

    3-18. REP (REPEAT) Set Step repeat time in Cycling mode. Step Repeat time is available from 1 to 10000. ▌Power Switch ON Turn on load and check load is in OFF MODE. ▌Press REP Key. ▌Set step repeat time by encoder. ▌Press REP Key to save the setting value.

  • Page 51: Seq (Sequence)

    3-19. SEQ (SEQUENCE) Set Start Step, Finish Step in cycling mode. SEQUENCE consists of 1. START NUMBER 2. FINISH NUMBER After setting SEQUENCE, press ESC Key and escape the menu. 1. START NUMBER ▌Power Switch ON Turn on load and check load is in OFF MODE. ▌Press SEQ Key.
  • Page 52 2. FINISH NUMBER ▌Power Switch ON Turn on load and check load is in OFF MODE. ▌Press SEQ Key. ▌Set [2. FINISH NUMBER] by cursor key. ▌Press SEQ Key. ▌Set FINISH NUMBER by encoder. ▌Press SEQ Key to save the setting value. ≫...

  • Page 53: Fuse Run

    3-20. FUSE RUN Fuse mode can figure out Fuse time, fuse current information. ▌Power Switch ON Turn on load and check load is in OFF MODE. CYC RUN ▌Press CYC RUN key for 3 seconds. (Fuse mode is ON) CYC RUN ▌Press CYC RUN to stop the fuse mode.

  • Page 54: Fuse Step

    3-21. FUSE STEP Set step of FUSE Mode. STEP Menu 1. FUSE TIME SET 2. FUSE CURRENT SET Escape FUSE Mode by ESC Key. 1. FUSE TIME SET ▌Power Switch ON Turn on load and check load is in OFF MODE. STEP ▌Press STEP Key for 3 seconds.
  • Page 55 1. FUSE CURRENT SET ▌Power Switch ON Turn on load and check load is in OFF MODE. STEP ▌Press STEP Key. ▌Set [2. FUSE CURRENT SET] by cursor key. STEP ▌Press STEP Key. ▌Set FUSE CURRENT by encoder. STEP ▌Press STEP Key to save the setting. ≫...

  • Page 56: Error Message Display

    3-22. Error Message Display When error occurs, error will be saved up to 10 to volatile memory. Please refer to "7. Error Messages" about error information. ▌ERROR memory is Stack structure type. First error will be lastly accessed. ▌11th and after error message will be discarded. ▌Press ERROR Key and check error message backwards.

  • Page 57: Protection

    3-23 Protection LP Series have protection mode (OVP, OPP, OTP) Below is the explanation about each protection. OVP is " Over Voltage Protection". If load output more voltage than capacity, Protection will be on. "OVER Voltage" will be displayed. To remove OVP, set power supply's setting appropriate to load's spec and press ESC.

  • Page 58: Remote Voltage Sensing

    3-24. Remote Voltage Sensing When using load, there will be voltage regulation in lead line. To use more correct voltage, there's a Remote Voltage Sensing function. Remote Voltage Sensing Connection Set rear panel switch to "Remote", and connect Sensing terminal to power supply terminal. And +S sensing terminal should be connected to + terminal (power supply).

  • Page 59: Calibration

    4. CALIBRATION Warning Calibration process is recommend to someone who is specialized in calibration only. Calibration period > For Test : 180 days > For normal use : 365 days (Recommended) Because of worn out device and temperature, humidity, device can have function error. Calibration is for setting function to standard.

  • Page 60: Equipment Required For Calibration

    Recommended Function Recommended device Users Digital Voltmeter Resolution: 0.1 mV Agilent 34401A Voltage Calibration Current Calibration, Power Supply Voltage Range: 80 Vdc ODA Technologies Power supply protection Current Range: 400 Adc Ex-Series (Normal load available) Current Current Calibration monitoring 0.001Ω , 0.01%...

  • Page 61: Current-Monitoring Resistor(Shunt)

    Power Supply ▌Power supply can be used for source for Calibration. ▌When you do Current calibration operation, Power supply's + terminal should be connected to load's + terminal. And load's - terminal should be connected to current monitoring shunt's one lead line. Other side lead line should be connected to power supply's - terminal.
  • Page 62 4-5. Calibration using front panel key CALIBRATION KEY Structure A/ CAL POWER ON 1.CC-Range:High_High 2.CC-Range:High_Low 3.CC-Range:Low_High 4.CC-Range:Low_Low 5.CV_HIGH 6.CV_LOW 7.DYN-CC:High_High 8.DYN-CC:High_Low 9.DYN-CC:Low_High 10.DYN-CC:Low_Low 11.DYN-CV:HIGH 12.DYN-CV:LOW - 54 -...
  • Page 63 Current CALIBRATION ▌Before calibration, connect dc power supply and measuring devices. > Connect power supply's (+) output terminal to load's (+) input terminal. load (-) input terminal is connected to Current Monitoring resistance. Connect Current monitoring resistance's other side of lead line to power supply's (-) output terminal.
  • Page 64 ▌After setting, press A/Calibration key to save the setting value. "ADC-DATA VALUE 0970" will be displayed. A/Cal ps. Display value can be different. Go back to before Cal status. ▌Press Calibration key in "2.CC-Range:HIGH_LOW" status. "CC-HIGH_LOW 000.4A" will be displayed. ps.
  • Page 65 ▌Press A/Calibration key to save the setting value. "ADC-DATA VALUE 0980" will be displayed. A/Cal ps. Display value can be different. Go back to before Cal status. ▌Press calibration key in "4.CC-Range:LOW_LOW" status. "CV-HIGH 000.4A" will be displayed. ps. Display value can be different. Wait for 5 min ▌Wait until DVM Meter shows stable voltage.
  • Page 66 Voltage CALIBRATION ▌Before calibration, connect dc power supply and measuring devices. > Connect power supply's (+) output terminal to load's (+) input terminal. load (-) input terminal is connected to Current Monitoring resistance. Connect Current monitoring resistance's other side of lead line to power supply's (-) output terminal.
  • Page 67 - 58 - Wait for 5min ▌Wait until DVM Meter shows stable voltage. ▌Set power supply voltage value to DVM Meter's voltage value. ▌After setting, press A/Calibration key and save the setting value. "ADC-DATA VALUE 0012" will be displayed. A/Cal ps.

  • Page 68: Remote Interface Calibration

    4-6. REMOTE INTERFACE Calibration You can do Calibration by using Remote Interface. During Remote Calibration process, load can not proceed other command. Measurement device Connection ▌Before calibration, connect measurement device like <Figure 4-2>. ▌Set communication setting in each devices. ▌warming-up is required for all measuring device before calibration. Remote Calibration Command process ▌Refer to SCPI Commands in "6-6.
  • Page 69 ▌Send HIGH Range의 Minimum Calibration. Command "CAL:CURR:H:L" ▌Power supply's setting value should be bigger than load's maximum value. ▌After several minutes, measure DVM voltage which is connected to current monitoring resistance. ▌Send measured current value to the power supply's value. For example, if measured current value is 5.55471, send command as below.

  • Page 70: Voltage Calibration

    Voltage CALIBRATION ▌Send power on command to power supply, and set power supply to suitable current and vol ▌Send Load's voltage Minimum Calibration Command. Command "CAL:VOLT:L" ▌Set power supply's setting value as more bigger than load's maximum value. Be sure to set power supply to more larger range than load's calibration range. ▌Measure DVM voltage after several minutes.

  • Page 71: Factory

    5. FACTORY By factory mode, you can set calibration back up and restoration. 5-1. Trait ▌10 memories in 『non-volatile memory』can be initialized. ▌ If you don't want to use product for a while, you can lock the front panel. ▌You can restore factory setting value by restoration function. 5-2.

  • Page 72: User-Mem Clear

    5-3. USER-MEM CLEAR ▌This command initialize non-volatile memory』1 ~ 10 data. ▌If initialization proceeded one time, previous data will not be restored again. ▌Initialization >Voltage >Dynamic A >Current >Dynamic B >MODE >DUTY >Range >FREQ 0.0001 >SLEW LEVEL 1 >Input Mode USER-MEM CLEAR B/FACT ▌Press power switch ON with pressing B/FACTORY key.

  • Page 73: Last State

    5-4. LAST STATE ▌When load is on, load will automatically restore data before last state. ▌Function > DISABLE Will be start with standard setting value. > SAFETY Will be start with OUTPUT OFF mode. Previous setting value is already set. >...

  • Page 74: Auto Key Lock

    5-5. AUTO KEY LOCK ▌If user don't use Front-panel for a long time, Front-panel will be automatically lock. ▌This function can protect from damage of operator's mistake. ▌If Auto key lock function is on, Front-panel will be lock. You can cancel lock function by pressing lock key. >...

  • Page 75: Cal-Default

    5-6. CAL-DEFAULT ▌This function will restore calibration data that was fixed in factory. ▌If you proceed calibration but want to restore fixed factory data, you can restore this data. In this case, Calibration in specialized organization is required for precise operating. CAL-DEFAULT B/FACT ▌Press power switch on with pressing B/FACTORY Key.

  • Page 76: Cal-Restore

    5-7. CAL-RESTORE ▌Restore data that was saved for calibration back up. ▌You can reset previous data before calibration by this function. CAL-RESTORE B/FACT ▌Put power switch ON with pressing B/FACTORY key. Pressing ▌Power Switch ON ▌"FACTORY MODE" will be displayed. Release B/FACTORY Key. B/FACT Releasing ▌Set "4.

  • Page 77: Cal-Backup

    5-8. CAL-BACKUP ▌To guarantee precision, Calibration of specialized organization is required for 6 months. And Calibration in 1 year is required for normal use. To prevent worst case, you can back-up authorized organization's calibration data. ▌If you proceed back-up, previous back-up data will be deleted. CAL-BACKUP ▌Press power switch ON with pressing B/FACTORY key.

  • Page 78: Load Defauld

    5-9. LOAD DEFAULT ▌You can restore factory reset of Factory Mode. LOAD DEFAULT ▌Put power switch ON with pressing B/FACTORY Key. B/FACT Pressing ▌Power Switch ON B/FACT ▌"FACTORY MODE" will be displayed. Release B/FACTORY Key. Releasing ▌Set "6. LOAD DEFAULT" by cursor key. ▌Press B/FACTORY Key.

  • Page 79: Scpi Command

    6. SCPI Commands LP Series can be controlled by SCPI Command. By GPIB Communication, you can control many power supply at the same time. This function is suitable to F.A, Data collecting in R&D Center. 6-1. Commands Syntax ▌You can input command without considering upper case and lower case.
  • Page 80 VOLT {VALUE} VOLT? VOLT:SLEW {VALUE} VOLT:SLEW? Measurement Commands MEAS:CURR? MEAS:VOLT? Dynamic Commands DYN:INPUT {ON | OFF} DYN:INPUT ON? DYN:MEM-A {VALUE} DYN:MEM-A? DYN:MEM-A:MODE {CC | CV} DYN:MEM-A:MODE? DYN:MEM-B {VALUE} DYN:MEM-B? DYN:MEM-B:MODE {CC | CV} DYN:MEM-B:MODE? DYN:FREQ {VALUE} DYN:FREQ? DYN:DUTY {VALUE} DYN:DUTY? Cycling Commands CYC:INPUT { ON | OFF } CYC:INPUT ON?
  • Page 81 CYC:REP {VALUE} CYC:REP? CYC:SEQ:STA {VALUE} CYC:SEQ:STA? CYC:SEQ:FIN {VALUE} CYC:SEQ:FIN? CYC:ON:STEP? CYC:ON:REP? CYC:FIN? FUSE MODE Commands FUSE:INPUT {ON | OFF} FUSE:INPUT ON? FUSE:TIME {VALUE} FUSE:TIME? FUSE:CURR {VALUE} FUSE:CURR? Calibration Commands CAL:CURR:H:{H | L} CAL:CURR:H:H {VALUE} CAL:CURR:H:L {VALUE} CAL:CURR:L:{H | L} CAL:CURR:L:H {VALUE} CAL:CURR:L:L {VALUE} CAL:VOLT:{H | L} CAL:VOLT:H {VALUE}...
  • Page 82 CAL:VOLT:DYN:{H | L} CAL:VOLT:DYN:H {VALUE} CAL:VOLT:DYN:L {VALUE} Factory Commands FACT:AUTO-LOC {ENA | DIS} FACT:AUTO-LOC? System Commands PROT? PROT:CLE SYST:ERR? SYST:BEEP *IDN? *RST *RCL {VALUE} *SAV {VALUE} *SN? - 74 -...
  • Page 83 INPUT Setting Commands Command for PC Remote Interface control. INPUT {ON | OFF} Command for controlling INPUT ON / OFF of load. >ON Able the input >OFF Disable the input ex1) input on Able the input ex2) input off Disable the input INPUT ON? Command for checking load's input status.
  • Page 84 CURR:RANG { H | L } Command for setting CC Mode Range. > H CC Mode HIGH RANGE > L CC Mode LOW RANGE ex1) CURR:RANG H CC Mode HIGH RANGE Setting ex2) CURR:RANG L CC Mode LOW Range Setting CURR:RANG? Command for checking CC Mode RANGE status.
  • Page 85 RES:RANG? Check the CR Mode Range status. Return value "H" CR Mode HIGH RANGE "M" CR Mode MID RANGE "L" CR Mode LOW RANGE RES:SLEW:{RANGE} {1|2|3|4|5|6|7|8|9|10|11|12} Command for setting CR Mode SLEW. ex) RES:SLEW:MID 2 Set 2 SLEW VALUE in CR Mode. RES:SLEW:{ H | M | L }? Command for checking CC Mode SLEW.
  • Page 86 Measurement Commands Command for checking read back voltage and current of load. MEAS:VOLT? Command for checking power supply's output voltage. Return value "voltage" ex) meas:volt? return value "11.0000" MEAS:CURR? Command for checking power supply's output current. Return value "current" ex) meas:curr? return value "1.0000"...
  • Page 87 DYN:MEM-A? Command for checking Dynamic A Memory setting value. Return value "VALUE" ex) DYN:MEM-A? return value "10.0" DYN:MEM-A:MODE {CC | CV} Command for setting Dynamic A Memory Mode. Dynamic Mode do not support CR Mode. > CC CC Mode Setting >...
  • Page 88 DYN:MEM-B:MODE? Command for checking Dynamic B Memory mode. Return value "mode" ex) DYN:MEM-B:MODE? return value "CC" DYN:FREQ {VALUE} Command for setting "time for proceeding 1 cycle". (Period) > VALUE Setting dynamic mode's velocity. ex)DYN:FREQ 0.05 Dynamic mode period 0.05s DYN:FREQ? Command for checking Dynamic Mode's period setting value.
  • Page 89 CYC:STEP:MODE:{STEP_NUM} {CC | CV | OFF } Command for setting Mode and Step for cycling mode. > STEP_NUM Set step for cycling mode. > CC CC Mode Setting > CV CV Mode Setting > OFF OFF Mode Setting ex1) CYC:STEP:MODE:1 CC ex2) CYC:STEP:MODE:1 CV ex3) CYC:STEP:MODE:1 OFF CYC:STEP:MODE:{STEP_NUM}?
  • Page 90 CYC:STEP:DELAY:{STEP_NUM} {VALUE} Command for setting DELAY Time and Step for saving. > VALUE Cycling DELAY TIME ex) CYC:STEP:DELAY:1 100 Save DELAY Time 100 s at Cycling Step 1. CYC:STEP:DELAY:{STEP_NUM}? Command for checking DELAY TIME of step. Return value "delay" ex) CYC:STEP:DELAY:1? return value "100"...
  • Page 91 FUSE:INPUT {ON | OFF} Command for ON & OFF Fuse Mode. > ON FUSE Mode ON > OFF FUSE Mode OFF ex1) FUSE:INPUT ON ex2) FUSE:INPUT OFF FUSE:INPUT ON? Command for checking Fuse mode is ON or OFF. Return value "1"...
  • Page 92 Calibration Commands Please proceed Calibration by procedure. Refer "4-6 REMOTE INTERFACE Calibration". CAL:CURR:H:{H | L} Command for Current High Range Calibration. > H HIGH RANGE's maximum Current Calibration > L HIGH RANGE's minimum Current Calibration CAL:CURR:H:H {VALUE} Command for setting High Range maximum current value. >...
  • Page 93 CAL:VOLT:{H | L} Command for selecting range for voltage Calibration. > H HIGH RANGE's Voltage Calibration > L Low RANGE's Voltage Calibration CAL:VOLT:H {VALUE} Command for setting High range voltage value. > VALUE ex) CAL:VOLT:H 6 CAL:VOLT:L {VALUE} Command for setting Low range voltage value. >...
  • Page 94 CAL:CURR:DYN:L:{H | L} Command for selecting LOW Range current calibration in dynamic mode. > H Low range's maximum current calibration in dynamic mode. > L Low range's minimum current calibration in dynamic mode. CAL:CURR:DYN:L:H {VALUE} Command for setting current LOW Range maximum value. >...
  • Page 95 Factory Commands FACT:AUTO-LOC {ENA | DIS} Command for ON/OFF of auto-lock function. > ENA Auto-Lock ON > DIS Auto-Lock OFF ex1) FACT:AUTO-LOC ENA Auto-Lock ON ex2) FACT:AUTO-LOC DIS Auto-Lock OFF System Commands PROT? Command for checking Protection mode is ON or OFF. Return value "1"...
  • Page 96 Product model name Product detail information. System controller Version Front panel Version SCPI protocol Version ex) *idn? return value "ODA Technologies,OEL-Series,1.0-1.0-1.0" *SAV {1|2|3|4|5|6|7|8|10} Command for saving data at non-volatile memory > 1 ~ 10 Memory number ex) *sav 2 Save data at memory 2 *RCL {1|2|3|4|5|6|7|8|10} Command for applying all the saved settings in 『non-volatile memory』.

  • Page 97: Error Messages

    7. Error Messages You can check error by pressing error key in front panel. +0,"No error" There is no error. 7-1. Operating Error -10, "Invalid the DAC parameter" If setting value is out of DAC parameter, setting value and real output value is different. In that case, remove load directly.
  • Page 98 -23, "En route to cal the curr" This error occurs when someone send voltage calibration command during current calibration. -24, "Over volt min parameter" Voltage value is over the minimum value. Refer "4-5. CALIBRATE ' -25, "Under volt max parameter" Voltage value is under maximum value.

  • Page 99: Calibration Error

    -34, "Not allowed command under cal" Under calibration this command does not available. 7-4. Calibration Error If you do calibration, Read back calibration inside the product will be proceeded. -74, "ADC-V low limit over" Voltage value is over from ADC-V low limit. -75, "ADC-V high limit over"...

  • Page 100: Interface Commands Error

    -87, "Memory curr length error" There's an error in current data length(Digit). -88, "Not match volt length and limit" Voltage length setting value does not matched with limit value. -89, "Not match curr length and limit" Current length setting value does not matched with limit value. 7-6.
  • Page 101 -221, "Setting conflict" This error occurs because there's no option for this command. ex)POL N This command is for changing polarity. If you use this command with single polarity product, error 221 will occur. -222, "Out of data" Setting value is out of product spec. ex)volt 1000 Solution) volt 10 -223, "Incorrect error"...
  • Page 102 9. Cautions Please refer followings to use product efficiently for long time. ▌Do not place product to extremely hot or cold space. ▌Do not use product immediately after bringing it from cold place. Due to liquefaction, operation can be harm to product. In this case, wait 20~30 minutes before operating.
  • Page 103 ODA TECHNOLOGIES CO.,LTD. 62, Bupyeong-daero 329beon-gil, Bupyeong-gu Incheon city, 403-858, Korea TEL. +82-2-1800-8644 FAX. +82-32-715-5456 www.odacore.com sales2@odacore.com...
