qpcom QP-W24HPUSB User Manual

Windows 7 wireless lan usb adaptor

Advertisement

Quick Links

User's Manual
QP-W24HPUSB
WINDOWS 7
Wireless LAN USB Adaptor
www.qpcom.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the QP-W24HPUSB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for qpcom QP-W24HPUSB

  • Page 1 User’s Manual QP-W24HPUSB WINDOWS 7 Wireless LAN USB Adaptor www.qpcom.com...
  • Page 2: Table Of Contents

    USING THIS DOCUMENT This document provides detailed user guidelines for Wireless LAN USB Adapter operation and setting-up. Though every effort has been made to ensure that this document is up-to-date and accurate, more information may have become available subsequent to the production of this guide. Content Chapter 1 Introduction ------------------------------------------------------------------- 3 Chapter 2 Specifications ------------------------------------------------------------------ 4...
  • Page 3: Chapter 1 Introduction

    Chapter 1 Introduction Thank you for purchasing Wireless LAN USB Adapter. Wireless LAN USB Adapter is a perfect combination of both performance and cost-effective product introduced. It is sincerely hoped that you can enjoy the wireless world through this solidly profiled wireless adapter.
  • Page 4: Chapter 2 Specifications

    Chapter 2 Specifications Host system connections Interface USB 2.0 and UPnP USB date transfer rate USB high speed (480Mbps), and full speed (12Mbps) Wireless LAN (WLAN) environment connections Multimode features WLAN Interface Fully complies with IEEE 802.11 b/g specifications 802.11g: 54, 48, 36, 24, 18, 12, 9 & 6Mbps WLAN transfer rate 802.11b: 11, 5.5, 2 and 1 Mbps with auto-rate fall back WLAN Frequency Band 2.400GHz ~ 2.484 GHz...
  • Page 5: Chapter 3 Installation/ Uninstallation

    Chapter 3 Installation/ Uninstallation Warning! Do not cover or block the airflow to the adapter. The adapter will reach a high temperature during use. 3.1 Installation Before you proceed with the installation, please notice the following descriptions. Note1: The following installation was operated under Windows Win7. (Procedures are similar for Windows 98SE/Me/2000/XP/Vista.) Note2: If you have installed the WLAN USB driver &...
  • Page 6 2.While the following screen pops out, click Driver Installation 3.Click Driver Installation - 6 -...
  • Page 7 4.Choose a set up language. Click Next to process the installation. 5.Click Next - 7 -...
  • Page 8 6.Click Install 7.The system starts software installation of the WLAN USB adapter. - 8 -...
  • Page 9 8.Click Finish to complete the installation - 9 -...
  • Page 10 9.After click Finish to complete the installation, under Windows Win7 <ALL Programs> menu, REALTEK USB wireless LAN Utility program installed. 10. Insert the wireless LAN USB adapter into your computer USB port, the computer detected and active the wireless LAN USB adapter automatically. - 10 -...
  • Page 11: Uninstallation

    3.2 Uninstallation From “Wireless Network Driver and Utility” or “Control Panel” ”Change or Remove Programs”. A. Uninstall the WLAN USB Adapter Driver from “Start” “All Programs” Click “Uninstall”(or “Change/Remove”) to remove Wireless LAN USB Adapter driver. - 11 -...
  • Page 12 B. Click“Yes”if you want to remove Wireless LAN USB Adapter Driver. C. Click“Finish”to complete the uninstallation - 12 -...
  • Page 13: Chapter 4 Rtwlan: Wireless Lan Management Gui

    Chapter 4 Rt WLAN: Wireless LAN Management GUI 4.1 Introduction of Main Window A. Main Menu C. Properties Area B. Adapter List Area D. Global Control Bar A.Main Menu The main menu includes two submenus. 1.Refresh(R) When clicking the refresh menu, you can update and re-enumerate the contents of adapter list area.
  • Page 14 2.About(A) Click the “About” to show the about dialog. The application version and license information are shown in the about dialog. - 14 -...
  • Page 15 B. Adapter List Area All connected adapters on this system with multiple adapter installations are displayed in this area. It is easy for users to change the selected adapter by one click. The contents of properties area are dependant on wireless configuration that the selected adapter is set up.
  • Page 16 C. Properties Area The contents of this area are dependent on current wireless configuration. The more detailed contents in 4.2 Properties Area - 16 -...
  • Page 17 D. Global Control Bar Each control item on this bar affects the adapter or management GUI directly. Show Tray Icon Checking "Show Tray Icon" and clicking “Close” button, the management GUI will be minimized and stay on the tray icon located at the right bottom corner of Windows. If not, management GUI will shut down while clicking "Close"...
  • Page 18 Virtual Wi-Fi allowed - 18 -...
  • Page 19: Properties Area

    4.2 Properties Area A. General Page This page represents the general information of this adapter. 1. Status The status of station connection to AP. 2. Speed Current transition speed in Mbps (Mega-Bits-Per-Second). 3. Type Current wireless LAN configuration type. 4. Encryption Current encryption mode used.
  • Page 20 B. Profile Page This page provides profiles management such as add, remove, edit and duplicate just by pressing the respected button. Available Profile(s) The list box shows all the created profiles. 1. Add Add a new profile for AP or IBSS (Ad-Hoc mode). 2.
  • Page 21 C. Available Network Page This page presents all BSS, including AP and IBSS, around this system. You can pick any one of these network connections 1. Refresh Rescan network connection around this system. 2. Add to Profile Create profile for selected network connection and add it to profile list. - 21 -...
  • Page 22 D. Advanced Page 1. Power Save None: without power save function. Min: wake up more frequently to receive packets. Max: wake up less frequently to receive packets. 2. Wireless Mode 802.11b 802.11b/g 3. Fragment Threshold The threshold of fragment length. Higher threshold increase data transition performance with good signal quality.
  • Page 23 E. Status Page 1. NDIS Driver Version Driver version 2. Short Radio Header 3. Encryption Current encryption mode. 4. Authenticate Authentication state 5. Channel Set Selected channel plan currently. 6. MAC Address MAC address of this adapter. 7. Data Rate Wireless LAN transition speed 8.
  • Page 24 13. Associated AP MAC MAC address of connecting AP 14. Up Time Total connection time F. Statistics Page You could watch the Tx/Rx status of current wireless connection. This page shows a statistic analysis of packet transition. - 24 -...
  • Page 25 G. Wi-Fi Protect Setup Page - 25 -...
