HERONLUX SM
READ THE INSTRUCTIONS CAREFULLY BEFORE STARTING
INSIDE THE BOX
WARNING
• Turn power off before inspection, installation or removal.
• Make sure that all electrical connections are made correctly
before operating the device.
• Installation and start up should only be done by qualified
personnel.
• Cable and luminaire components must be protected against
mechanical impacts and damage.
• Do not operate luminaire with damaged parts.
INSTALLATION
1
Seperate lumininare from back plate by twisting it.
© 2021, All rights reserved BaltLED, UAB. Specifications are subject to change without notice.
1 /
www.baltled.com
2
19th
February
, 2021
INSTALLATION GUIDE
1x Luminaire
3x Plugs
3x Screws
2
NEEDED FOR MOUNTING
• For indoor use only.
• Dry location only.
• To prevent wiring damage or abrasion, do not expose
wiring to edges of sheet metal or other sharp objects.
• The manufacturer shall not be liable for any damage
resulting from inappropriate modifications to the
luminaire or faulty installation.
If you have any questions, contact the manufacturer.
Bring power cable front of back plate by using hole in the middle.
Strip the wires.
