Indoor Location Beacon
FAP5030-030
Installation and User Guide
Innovative Wireless Technologies, Inc.
1100 Main Street
Lynchburg, VA 24504
Phone: 434-316-5230 (United States)
Fax:
434-316-5232 (United States)
www.iwtwireless.com
(United States)
Revised: 11/24/2020
6650-20-0014, Rev. A
Approval:
Page 1 of 13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FAP5030-030 and is the answer not in the manual?

Questions and answers

Summary of Contents for IWT FAP5030-030

  • Page 1 Indoor Location Beacon FAP5030-030 Installation and User Guide Innovative Wireless Technologies, Inc. 1100 Main Street Lynchburg, VA 24504 Phone: 434-316-5230 (United States) Fax: 434-316-5232 (United States) www.iwtwireless.com (United States) Revised: 11/24/2020 6650-20-0014, Rev. A Approval: Page 1 of 13...

  • Page 2: Table Of Contents

    LLOWABLE IMITS FOR ENERAL XPOSURE MODIFICATIONS .............................. 4 SPECIFICATIONS FOR FAP5030-030 (TYPICAL UNLESS OTHERWISE SPECIFIED) ..........4 INDOOR LOCATION BEACON DESCRIPTION ....................5 INPUTS AND OUTPUTS ............................. 5 CONFIGURING THE ILB ..........................6 INSTALLATION ............................12 SITE SURVEY ..............................12 OPERATING AND MAINTENANCE INSTRUCTIONS ..................

  • Page 3: Integrated Mesh Node Overview

    1. INDOOR LOCATION BEACON OVERVIEW Innovative Wireless Technologies’ FAP5030-030 Indoor Location Beacon (ILB) is a PoE powered device containing a Wi-Fi AP and a Bluetooth® Low Energy (BLE) beacon that can be used to provide enhanced location support for indoor facilities. An internal configuration webpage allows the Wi-Fi and Bluetooth®...

  • Page 4: Fcc Allowable Limits For General Rf Exposure

    MODIFICATIONS Changes or modifications to the ILB not expressly approved by Innovative Wireless Technologies, Inc. may void the user’s authority to operate this equipment. 3. SPECIFICATIONS FOR FAP5030-030 (Typical unless otherwise specified) PHYSICAL & ENVIORNMENTAL Operating Temperature -20C to +60C...

  • Page 5: Indoor Location Beacon Description

    Types iBeacon, Eddystone Transmit Power 0 dBm ETHERNET 10/100 Mbps PoE IEEE 802.3a, class 0 RJ45 interface with PoE support 4. INDOOR LOCATION BEACON DESCRIPTION To begin using the ILB, review the information below covering the basic information you need to know to get started.

  • Page 6: Configuring The Ilb

    Input Figure 2 - Bottom View of ILB The following is an explanation of the IMN inputs and outputs as shown in Figure 1: PoE INPUT: The ILB is powered by PoE. The power input to the ILB is an RJ45 connector on the back side of the enclosure.
  • Page 7 Figure 3 - Connecting to ILB with device ID 6883 (Wi-Fi) 3. Connect to the ILB. The default network security key is Beacon123. This passphrase may be changed as part of the configuration process using the ILB Configuration Webpage. 4. When the laptop is successfully connected to the ILB, open the device’s internal Configuration Webpage by typing the following into a browser (Chrome, Firefox, Microsoft Edge recommended): https://192.168.3.1...
  • Page 8 Figure 4 - Opening the Configuration Webpage The ILB Configuration Webpage will open and Login information is requested. The default Login information for each ILB device is as follows: username: admin password: Beacon123 Revised: 11/24/2020 6650-20-0014, Rev. A Approval: Page 8 of 13...
  • Page 9 After a successful log-in, the MAIN screen of the Configuration Webpage will appear (Figure 5): Figure 5 - Main page of the Configuration Webpage (LOCATION tab) The four tabs on the Configuration Webpage can be used to switch between the different configuration options.
  • Page 10 Figure 6 – Wi-Fi AP Configuration Screen The last four digits of the SSID match the ID of the individual ILB device (labeled on enclosure). The Passphrase is the network security key used to connect to the device. The default Passphrase for each ILB is Beacon123.
  • Page 11 Figure 7 - BLE Beacon Configuration Screen The ILB’s BLE beacon is Disabled by default. To enable the Bluetooth beacon, select the desired Beacon type (iBeacon or Eddystone) and press the Update button at the bottom of the screen. If the beacon is not detected, power cycle the device.

  • Page 12: Installation

    Figure 8 - Ethernet Configuration Screen If the ILB is connected wirelessly to a laptop/tablet/phone for configuration, the IPv4 Address and Netmask boxes will indicate ‘None’ as in the figure above. 6. INSTALLATION IMPORTANT! TRAINED PERSONNEL MUST PROFESSIONALLY INSTALL THE ILB. SITE SURVEY Conduct a survey to determine the appropriate sites to install the ILBs.

  • Page 13: Operating And Maintenance Instructions

    Figure 9 - ILB Mounting holes An optional aluminum mounting bracket is available for use with the ILB. Note: The ILB should not be installed in plenum spaces above ceiling tiles. 7. OPERATING AND MAINTENANCE INSTRUCTIONS POWERING THE ILB The ILB is automatically powered ON when a PoE input cable is plugged into the RJ45 connector on the back of the device.
