B23PXP88-A90
USER MANUAL
Thanks for your purchase. Any questions please don't hesitate to contact us,
We will handle all your problem ASAP. Your feedback is vital to us!
And we will always try to do better. For more details, please contact us
by email via support@rovsun.com. (Write your seller's Order # on the
subject of the email, so that we can find your order and better assist
your issue) Or call us at (1)855-882-2333 .
MADE IN CHINA

Advertisement

Table of Contents
loading

Related Manuals for Zokop B23PXP88-A90

Summary of Contents for Zokop B23PXP88-A90

  • Page 1 B23PXP88-A90 USER MANUAL Thanks for your purchase. Any questions please don't hesitate to contact us, We will handle all your problem ASAP. Your feedback is vital to us! And we will always try to do better. For more details, please contact us by email via support@rovsun.com.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFEGUARDS INSTALLATION CLEANING TIPS FOR CLEANING PRODUCT INSTRUCTION OPERATION OF CONTROL PANEL UTENSILS GUIDELINE COOKING TIPS MAINTENANCE SERVICING SAFEGUARDS...

  • Page 3: Important Safeguards

    IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE .IMPORTANT SAFEGUARDS …………。 。 。 。 。 ……………………… The following basic precautions should always be followed when using electrical appliance: 1. Read all instructions before using. 2. Make sure the voltage in your living area corresponding to the one shown on the rating label of the appliance.
  • Page 4 sealed containers. b. Use the wide -mouthed container to cook liquid, and the cooked liquid should not be removed out immediately. Several moments should be waited before removing. In order to avoid possible hazards caused by delayed eruptive boiling of liquids. c.
  • Page 5 11. Do not store food or any other things inside the oven. 12. Do not operate the oven without any liquid or food inside the oven. This would do damage the oven. 13. When the appliance is operated in the combination mode, children should only use the oven under adult supervision due to the temperatures generated.
  • Page 6 24. This appliance is intended to be used in household and similar applications, such as: • Staff kitchen areas in shops, offices and other working environments; • Farm houses; • By clients in hotels, motels and other residential environments; • Bed and breakfast type environments. 25.

  • Page 7: Installation

    30. The door or the outer surface may get hot when the appliance is operating. 31. WARNING: Accessible parts may become hot during use. Young children should be kept away. 32. This device complies with Part 18 of the FCC Rules. 33.

  • Page 8: Cleaning

    leakage, ground loop can be formed to avoid electric shock. 6. The microwave oven must be operated with the door closed. 7. The microwave oven must not be placed in a cabinet. The microwave oven is intended to be used freestanding. 8.

  • Page 9: Tips For Cleaning

    5. When the microwave oven has been used for a long time, there may be some strange odors exist in oven, Following 3 methods can get rid of them: a. Place several lemon slices in a cup, then heat with high Micro Power for 2-3 min.

  • Page 10: Product Instruction

    Turntable/ Rotation ring/ Rotation axis: Wash with mild soap water Rinse with clean water and allow drying thoroughly .PRODUCT INSTRUCTION …………………………......BAKED POTATO POPCORN PIZZA BEVERAGE FROZEN DINNER REHEAT POWER DEFRO BY T KITC DEFRO TIMER BY WE EXPRESS COOK CLOCK HOLD OP /...

  • Page 11: Operation Of Control Panel

    5) Turntable The food sits on the turntable, its rotation during operation helps to cook food evenly - Place the rotating ring first - Fit the turntable onto the rotating axis and make sure that it is geared in properly 6) Control panel See below in details (the control panel is subject to change without prior notice)
  • Page 12 2. START/PAUSE Touch to start or stop cooking. 3. NUMBER PADS (0-9) Touch to set the cooking time. 4. SETTING THE CLOCK 1) Touch CLOCK once (for 12 hour clock) or twice (for 24 hour). 2) Use the number pads to enter correct time. 3) Touch CLOCK again.
  • Page 13 6. EXPRESS Program will start immediately after touching the number pad (1-6). Suppose you want to set the quick cooking in 6 minutes. 1) Touch number pad 6. 2) 6:00 can be seen on display. 3) The program starts automatically. Touch number pad Time minutes 1 minute...
  • Page 14 4) Use the number pads to enter the power level as shown in the table below. NUMBER Display POWER 100P 100% 5) Touch START/PAUSE pad. 9. SETTING “TIME DEFROST” 1) Touch TIME DEFROST pad. 2) Enter desired defrosting time by touching correct number pads.
  • Page 15 10. SETTING “WEIGHT DEFROST” 1) Touch WEIGHT DEFROST pad. 2) Use the number pad to enter food weight “LB”. 3) When icon of “OZ” flashes, use the number pad to enter food weight in “OZ”. 4) Touch START/PAUSE pad. Note: The maximum weight is 5 LB.
  • Page 16 1) Baked Potato Each potato about 3.5-5.3oz 1. Touch BAKED POTATO once for each potato to be cooked. 1 potato 6 min 2 potatoes 8 min 3 potatoes 10 min 4 potatoes 12 min 2. Touch START/PAUSE pad 2) Popcorn For microwave popcorn: 1.
  • Page 17 3) Pizza Reheating pizza: 1. Touch PIZZA pad. 2. Touch PIZZA once for one slice and touch the pad twice for two slices. 3. Touch START/PAUSE pad 4) Beverage Each cup about 250ml: 1. Touch BEVERAGE once for each cup to be heated. 1 cup.
  • Page 18 12. TWO-STAGE COOKING Use for multi-stage cooking. It enable cooking at multiple power and time settings automatically. SET STAGE1: 1) Place food into oven and close it. Touch TIME COOK pad. 2) Use the number pads to set a cooking time. 3) Touch POWER LEVEL pad.

  • Page 19: Utensils Guideline

    .UTENSILS GUIDELINE …………………。。…………………………….. It is strongly recommended to use the containers which are suitable and safe for microwave cooking. Generally speaking, the containers which are made of heat-resistant ceramic, glass or plastic are suitable for microwave cooking. Never use the metal containers for microwave cooking and combination cooking as spark is likely to occur.

  • Page 20: Cooking Tips

    .COOKING TIPS …………………………………………。 ……………..……….. The following factors may affect the cooking result: Food arrangement Place thicker areas towards outside of dish, the thinner part towards the centre and spread it evenly. Do not overlap if possible. Cooking time length Start cooking with a short time setting, evaluate it after it times out and extend it according to the actual need.

  • Page 21: Maintenance

    Microwave safe plastic cookware Some microwave safe plastic cookware might not be suitable for cooking foods with high fat and sugar content. Also, the preheating time specified in the dish instruction manual must not be exceeded .MAINTENANCE …………。。 SERVICING Please check the following before calling for services. 1.
  • Page 22 2. During servicing below listed parts are liable to be removed and give access to potentials above 250V to earth. ● Magnetron ● High voltage transformer ● High voltage capacitor ● High voltage diode ● High voltage fuse 3. The following conditions may cause undue microwave exposure during servicing.
