Insignia Tent
Instructions
toll free : 800.227.0337 | phone : 303.371.1717 | fax : 303.371.9149
4690 Joliet Street | Denver, Colorado 80239
www.eps-doublet.com
17'hex
Please read instructions prior to assembling tent.
Proper installation will ensure maximum usage and stability of the structure.
Advertisement
Summary of Contents for EPS 17'hex
- Page 1 Instructions toll free : 800.227.0337 | phone : 303.371.1717 | fax : 303.371.9149 4690 Joliet Street | Denver, Colorado 80239 www.eps-doublet.com 17’hex Please read instructions prior to assembling tent. Proper installation will ensure maximum usage and stability of the structure.
- Page 2 Evacuation of the tent is recommended any time weather is extreme. Proper safety equipment should be used to ensure a safe set up and take down. EPS-Doublet suggest a careful examination be make to determine the safety equipment needed, such as hard hats, steel toe shoes, safety glasses and others materials as required.
- Page 3 (detail) & (detail) Item Part Description Part Number Item Part Description Part Number Canopy & Canopy Bag 10977 Nut - 5/16” Nylok 8369 Cross Cable 112299 Stakes 3/4” x 34” 10666 9’ Legs 10591 Cable Tool Base 10514 Center Pole Lifter Corner 10628 Flag Pole Extension...
- Page 4 Frame Assembly Organize all the parts before assembly. Canopy (1) Cable Tool Corners (6) Center Pole Tool 9’ Legs (6) Bases (6) Center Pole Cross Cables (3) Stakes (12) Eve Tubes (8) Assemble the Bases to the 9’ Legs as shown. Bolt Base 9’...
- Page 5 Frame Assembly Assemble frame as shown. Connect all Corners , Eve Tubes and by inserting one into the other as shown. Corner Eve Tube Attach first Cross Cable diagonally across frame. Hook cable loop over the corner pin on the Corners as shown in detail.
- Page 6 Canopy Installation Install the third Cross Cable . Hook one loop over corner pin as shown in step 5. Lift last corner of the frame upward to shorten the distance and hook the last loop over the pin. Lowering frame will tighten cable. Lift Lift Remove the Canopy...
- Page 7 Canopy Installation Attach the Canopy webbing by pulling down on Handle B until webbing Loop A is around Metal Hook C located on the outside of Corners . Attach webbing to two corners that are adjacent to one another. Center Socket Canopy Canopy Handle B...
- Page 8 Erecting the Tent Install four of the six 9’ Legs on an adjacent side. Lift one side of frame and slide assembled 9’ Leg into the Corner . Align holes and secure with Lock Pin Lock Pin Lock Pin Corner Corner 9’...
- Page 9 Erecting the Tent Insert Center Pole through the opening at the center of the Canopy . Lean the Center Pole against the intersection of the cross cable. Canopy Cross Cables Center Pole Install flag on the Center Pole from the outside of the tent. Be careful when stepping on Canopy fabric.
- Page 10 Erecting the Tent Attach the Cable Tool to the Top Cross Cable . Attach to top of the Come Along Wench to the Cable Tool and the other hook to the handle of the Center Pole Tool . Raise the Center Pole cranking the Come Along Wench until the bottom of the Center Pole is slightly above the cables.
- Page 11 Erecting the Tent Ensure 9’ Legs are aligned and straight. Drive to Ground Stakes through each Base 9’ Leg Ground Stake Base Secure and tension all Toggle Ropes as shown in Step 13. Tie off slack rope tails. NOTE: Toggle Rope should slide outward from the ring as toggle is pulled down as illustrated on Page 8.
- Page 12 Guy Rope Installation Guy Ropes should always be used in cases of high wind or other inclement weather. Good judgment must be used to ascertain the severity of weather conditions in determining when to set up or take down the Insignia Tent. Snap ring onto corner hook.
- Page 13 Wall Installation Before beginning, ensure all Toggle Ropes are evenly tensioned and the Canopy is evenly positioned on the frame. From inside of the tent, install the Sliding Wall Brackets to each post where walls are to be installed. Attach the Sliding Wall Cables by inserting the Turn Buckle hook into the holes of the Sliding Wall Bracket.
- Page 14 Joiner Installation Canopy Joiner Canopy Velcro Strip Canopy Flap Lapels Valance Velcro Velcro Strap Joiner Joiner Flap Flap Front Side Joiner Side Velcro Strips Downspout Unfold the Joiner. Lay Joiner out between the two tents to be joined. Starting at one tent, slip the joiner under the Canopy Flab B and fasten the two Velcro strips together.
- Page 15 Joiner Installation Insert Lapel Strap through adjacent front side Valance Ring. Secure the side release buckle. Pull strap to tighten. Valance Lapel Strap Front Valance Ring From the outside of the tent, fasten both of the front Valances together with the Velcro strips. After the Lapels are in place and secured, fasten the wall straps to the corresponding Posts.
- Page 16 Maintaining Your Tent CLEANING YOUR TENT: To clean, spread out canopy on clean surface. Use mild detergent or industrial cleaner that does not contain bleach. Small rocks and pebbles may create holes in fabric when stepped on. Cleaning the tent while assembled is recommended.
