- Page 1 Version 1.2 September 20, 2021 PRODIGY MICROFOCUSER PRODUCT MANUAL BY PEGASUS ASTRO...
-
Page 2: Controller Care
Its sturdy mechanical design ensures that Prodigy Microfocuser can lift up to 10Kg of equipment, dead accurate and flexure free. Focuser has a 25mm of draw tube travel and a clear aperture of 76mm / 3-inch. -
Page 3: Design Overview
DESIGN OVERVIEW The images below show side views of the Prodigy Microfocuser. 9/20/2021 PRODIGY MICROFOCUSER... - Page 4 What is in the box Prodigy Microfocuser 1 x DC Cable (2.1mm) to Cigarette Lighter (10A fused) 2 x Power Cables (0.5 meter) 1 x USB 2.0 Type-A male > USB 2.0 1 x Temperature Sensor with stereo jack Type-B male (1.8m)
- Page 5 Drawtube has a clear aperture of 3 inches or 76mm. It can travel up to 25mm. Prodigy Microfocuser isn’t a Crayford neither a Rack & Pinion type. Its innovative mechanical focus design provides very high load support and accuracy with zero maintenance.
- Page 6 TELESCOPE ADAPTERS Prodigy Microfocuser can accept different types of telescope adapters. The adapter can be securely mounted and aligned on user's preference. • Celestron SCT Edge C11, C14 (SKU: PEG-PRDG-C11) • GSO, Astrotech, Omegon, Altair, TS or similar RC 10'', 12'' , 14'', 16'' (SKU: PEG-PRDG-GSO117) •...
-
Page 7: Camera Adapter
CAMERA ADAPTER Camera adapter (stock) is a M54 adapter. It can be easily replaced with a larger aperture adapter. 9/20/2021 PRODIGY MICROFOCUSER... -
Page 8: Power Input
POWER INPUT Controller accepts a voltage range from DC 11.0V – 15.0V * We strongly recommend you use our certified “Pegasus Astro 12V/10A power supply” • A 13.8V lead (or calcium/lead) battery is also recommended. • Please use a power supply that can provide at least 2 Amps of current. If you utilize the USB and Power ports on the side of the focuser you might need up to 8 Amps of current. -
Page 9: Temperature Sensor
12V POWER OUTPUTS On the right side of the Prodigy Microfocuser there are two (2) 12V DC unregulated outputs. These power outputs are driven by a dual channel smart mosfet, capable to deliver up to 8 Amps of current (in total). -
Page 10: Motor Operation
DUAL PORT USB2 HUB Prodigy Microfocuser includes an industrial grade USB hub IC capable to deliver 2 x USB2 High Speed ports. These dual stacked ports exist on the side of the Prodigy. Both USB ports are controllable and can be switched ON/OFF via supplied software. -
Page 11: Warranty
2 x USB2 Type B Outputs / 1Amps each / Switchable ON or OFF Thermal Sensor Resolution 9-bit Celsius temperature measurements – External Sensor with stereo plug Power Input Connector 2.1mm Centre Positive Socket / 10 Amps maximum current Dimensions 115 mm x 176 mm x 80mm Weight 1470 grams 9/20/2021 PRODIGY MICROFOCUSER... -
Page 12: Maintenance
The color anodizing of the focuser is as resistant to aging as possible using state-of-the-art methods of electro-plating. The color, nevertheless, may change slightly if it is exposed to UV-radiation for years. 9/20/2021 PRODIGY MICROFOCUSER... -
Page 13: Dimensions Drawing
DIMENSIONS DRAWING Please note that backfocus is 80mm (when drawtube is fully inside) without any telescope adapters. When you place a telescope adapter the total backfocus increases. 9/20/2021 PRODIGY MICROFOCUSER... - Page 14 Designed and Assembled in Greece 9/20/2021 PRODIGY MICROFOCUSER...
