Summary of Contents for Parallax RX-101
- Page 1 Instruction Booklet RX-101 Please read all instructions carefully before opening box...
- Page 2 PULL YOUR PARALLAX FABRIC OUT OF THE BOX & UNWRAP YOUR EXTRUSION CAREFUL NOT TO CUT INTO THE BAGS OR THE BOX AS YOU COULD DAMAGE THE FABRIC LINE UP THE X2 TOP CORNER LENGTHS NOTE: IF THERE IS NO SCREW...
- Page 3 SCREW INTO PLACE AND REPEAT FOR THE OTHER LENGTHS UNTIL THE ENTIRE FRAME IS FIXED INTO PLACE. NOTE: THE RX-101 IS SPECIALLY DESIGNED TO CATER FOR UNEVEN & UNSQUARE WALLS, IT IS NOT IMPERATIVE THAT THE MITRE LINES UP PERFECTLY ONLY THE TOP FABRIC CHANNEL...
- Page 4 INSERT THE FABRIC INTO THE EXTRUSION STARTING WITH THE CORNERS ENSURE THE SILICON GASKET IS CONCEALED FOLLOW THE DIAGRAM BELOW FOR THE REMAINING SILICON GASKET EDGE. STARTING WITH ALL CORNERS ENSURE SILICON GASKET EDGE ON FABRIC IS PUSHED AS FAR INTO THE CHANNEL AS POSSIBLE, THIS SHOULD SUBSIDE ANY WRINKLES THAT MAY HAVE APPEARED.
- Page 5 CONTINUE WITH THE MIDDLE OF EACH LENGTH, AND THEN THE REMAINDER OF THE FABRIC CONTINUE UNTIL ALL THE FABRIC HAS BEEN FULLY INSERTED...
