AIRFER DIAMOND EVO +AERO 1000 User Manual

DIAMOND EVO
U N P A C K & F IT F R A M E R IN GS
When you receive the parcel with the paratrike you can see that wood panels are screwed by small
screws, remove these screws and all wood panels. Now you can bring the different parts of the
Paratrike out of the box.
Please take every part out carefully for them not to be damaged. The propeller protection rings may
be tangled with each other or by the lines (lines netting) , remove the lines
When you have taken all the parts: rings, wheels, etc. you will see that the central part of the Paratrike
is attached by a line , cut it off to take this central part from the box, you need someone help you to
do it.
ATTENTION: you can see that the fuel pump is under the fuel tank, just behind the axle, when you
are bringing the paratrike out of the box please pay attention that the fuel pump is not knocked
with something anywhere.
Once you have brought all parts out of the box you have to fit the 2 rear wheels. In order to
distinguish the left Wheel from right Wheel you will see that the one of the wheel axles is marked
with 1 point, the other wheel axle is marked with 2 points, you have to match these points with the
trike rear axle points in the trike rear axles, which are marked also.
Now you can fit the front wheel.
Then you can fit the propeller protection rings, please follow this sequence to fit the rings (you can
see the video also):
1. Fit the upper ring part
2. Fit one of the lower ring part. Fit it on its upper part first, and then fit the 2 unions of the
outer ring and fix the velcro. Repeat the same with the opposite lower ring part.
3. Now fit the lower supports near the axle, with the 2 screws; but do not tighthen the nuts too
much, you will do it afterwards at the end
4. Proceed to make ensure the complete ring with the Push Pins
5. Finally tighthen the screws in the lower part of the rings
You can see the described operation in the video, if you follow these steps it will be easy to do it, in
case you try otherwise you may not achieve to fit the ring or find it difficult.
When you have everything fitted you must check and make sure that everything in the paratrike is
correctly fitted: propeller protection rings, rear axles, front wheel, etc... Check that all the screws and
pins are in its place and all them are correctly tighthened.
( USER MANUAL)
+AERO 1000
