Summary of Contents for Returnstar IQBoard LT Series
- Page 1 IQBoard LT Series User Manual Copyright(C) 2003-2012 Fuzhou Returnstar Technology Co., Ltd. Web: www.recoverystar.com; www.iqboard.net Tel: 0086-591-87274373 Fax: 0086-591-87274383 E-mail: master@iqboard.net...
- Page 2 The product specification may be subject to change without prior notice. The sample pictures in this User Manual may differ from the real product. Returnstar reserves all rights to charge the fee at anytime for product replacement, revision and update. The information in this manual is subject to regular change without prior notice.
-
Page 3: Table Of Contents
Content Chapter 1 Product Introduction .................. 1 Chapter 2 Specifications .................... 2 2.1 Performance....................2 2.2 System Requirement ..................2 Chapter 3 Model Introduction ..................3 Chapter 4 How to Install Hardware................3 4.1 How to Install Electronic Wand ..............3 4.2 How to Install Light Pen ................ -
Page 4: Chapter 1 Product Introduction
IQBoard LT Series is provided with powerful IQBoard Software, which makes your operation on interactive whiteboard more convenient. Through IQBoard Software, various interactive teaching and demonstrating functions can be achieved, such as... -
Page 5: Chapter 2 Specifications
Chapter 2 Specifications 2.1 Performance Signal Receiver Digitalizing Technology Optical imaging and infrared capture Active Area (projection size) 60″~ 150″diagonal (with aspect ratio of 4:3 or 16:9) Resolution 9600×9600 Refresh Rate 80 fps Signal Tracking Rate 8m/s Signal Processing Rate 480 dots/s PC Connection Connect PC to IQBoard with 5m USB cable... -
Page 6: Chapter 3 Model Introduction
Chapter 3 Model Introduction IQBoard LT M1: Single Mode, only allow one user to operate with one Light Pen. IQBoard LT M2:Support Dual Mode, two users (two light pens) can operate simultaneously on the interactive screen. Chapter 4 How to Install Hardware 4.1 How to Install Electronic Wand Step 1. -
Page 7: Signal Receiver
USB charging port: Re-charge battery in Light Pen by connecting pen with computer through USB cable. Note: 1. Please do re-charge Light Pen with a battery which is re-chargeable in, or it may cause explosion of battery if you re-charge Light Pen with a disposable battery in. 2. -
Page 8: How To Install Projector
V8.0”, then press the “Remove” button to remove the drivers. Chapter 6 Mount Signal Receiver 6.1 Desktop Mounting For mobile use of IQBoard LT Series, you can simply mount Signal Receiver on the desktop. 1). Fix Signal Receiver with stand by clamp on it. -
Page 9: Ceiling Mounting
check Recommended Signal Receiver distance about distance between receiver and projection area. 3). Connect one end of Mini USB cable to Mini USB Port on Signal Receiver, the other flat end to PC. 4). Adjust the position of receiver and the angle of Receiving Front to assure it can receive signal from the whole projection area. -
Page 10: Recommended Distance Between Receiver And Screen
Note: If the projector you use isn’t a short-throw one, desktop mounting is recommended. 6.3 Recommended Distance between Receiver and Screen Recommended Distance Screen Size Distance between Receiver and Screen ″ (4:3) 84cm~116cm ″ (4:3) 105cm~145cm ″ (16:9) 128cm~180cm ″ (16:9) 138cm~190cm ″... -
Page 11: Chapter 7 How To Start And Orient Iqboard Lt
“Image Upside Down” Button to flip the image. 3). Fix Signal Receiver, then you can start orientation next. 7.2 Orientation In order to make IQBoard LT Series work normally, you need to orient at the first time... - Page 12 So the moving track of Electronic Wand and Light Pen can match the cursor, and you don’t need to re-orient under the same environment. 1) Select “Start > Programs > IQBoard LT Series Universal Drivers > Orient”, the Orient Window appears.
- Page 13 If you use Light Pen, follow the on-screen instructions, press the center of each dot accurately with Pen Tip. If you use Electronic Wand, follow the on-screen instructions, press the center of each dot accurately with the wand tip and press the button on the wand holder. 6) After orientation, interface of orientation will close automatically, and IQBoard LT is ready to use.
-
Page 14: Chapter 8 How To Use Light Pen And Electronic Wand
8.2 How to Use Buttons on Light Pen The Light Pen of IQBoard LT Series has 2 multi-functional interactive buttons. You can achieve dozens of functions by simply pressing the interactive buttons. Following are the operations of these interactive buttons. When using these buttons, please touch... - Page 15 Pen Tip. Do not press the surface tightly. Front Button Back Button 1) Select “Start > Programs > IQBoard LT Series Universal Drivers > Light Pen Buttons Setting” to set button functions. (See figure as follow) 2) Default Options...
- Page 16 If the “Select” function is activated, press the button once to execute left-click function of Mouse, press twice to execute double-click and press to drag. Back Button: If no Freehand Drawing Tool is selected, press the button once to select a Freehand Drawing Tool;...
-
Page 17: How To Use Soft Hotkeys
8.3 How to Use Soft Hotkeys Following is the introduction of frequently used soft hotkeys: Add Page : In Windows Mode, press this key to clear all annotations on screen. In Board Mode, press this key to add a new page in current .cdf file. Save File : In Windows Mode, press this key to save all annotations on screen to a page in current file. - Page 18 frequently used tools in IQBoard Software. You can add up to 8 shortcut icons in this bar. Applications : Press this key to popup a quick access bar including shortcut icons for frequently used applications. You can add up to 8 shortcut icons in this bar. Start : Press this key to start the IQBoard Software.
-
Page 19: Chapter 9 Faq
1) IQBoard LT Series Universal Drivers has not been correctly installed. Please uninstall the driver and re-install. 2) IQBoard LT Series Universal Drivers has not been started, or IQBoard LT has not been orientated. Please start the drivers and orient IQBoard LT. - Page 20 6. When orientating, some orientating points do not respond. 1) The distance between Receiver and screen is not appropriate, please readjust as per the recommended distance mentioned as above Chapter 6. 2) The receiver and computer are not well connected. Please check and re-connect. For other questions, please consult our service center or local dealer.
-
Page 21: Chapter 10 Cautions And Maintenance
Chapter 10 Cautions and Maintenance 10.1 Signal Receiver 1) Please do not use sharp or pointed objects to touch the signal receiving area in front of the receiver. 2) Please do not use wet cloth to clean the receiver or controller to avoid short circuit and other problems. - Page 22 authorized technician. Make sure that you use our designated part or the one with same specification when replacing.
