Page 4: Introduction
With its rugged design and high rate of data collection, you can analyze material as it passes through key areas of your process. Using the data acquired by Vertex, you have the ability to warn operators of incoming oversize material or contamination, or automate a response such as closing a crusher gap or triggering a flop gate. -
Page 5: Product Specifications
PRODUCT SPECIFICATIONS Physical Specifications Material Aluminum Alloy (6061) Finish Hard Anodize Weight 2.5 kg / 5.5 lbs Length 170 mm / 6.7” Width 160 mm / 6.3” Height 200 mm / 7.9” Electrical Specifications Input 5V DC @ 4A Consumption 20 W typical / 30 W max Certification Environmental Specifications... -
Page 6: Installation Guide
INSTALLATION GUIDE Vertex Diagram The diagram below displays the features of the Vertex. 1 Status indicator LED light 2 Power receptacle (5VDC) Ethernet receptacle (M12 connector) 4 Mounting points 5 LIDAR distance sensor 6 Removable lens cover Adjustable zoom/focus/ aperture camera lens... - Page 7 The Vertex should be located on a conveyor belt in an area where 5VDC power and a network connection can be provided. You should locate the Vertex at a point in the process you would like to receive data from, either to control quality or collect historical data, or to directly control another piece of equipment, another process, or a group of other processes.
- Page 8 The Vertex is powered with 5V DC power. A field-wired, ingress-protected connector is provided with the system to attach an available 5V DC power source to the power receptable on the Vertex. When measured at the camera end of the cable, the voltage provided must be at least 5V DC, and must not exceed 5.125V DC.
- Page 9 Lighting will need to be provided at the installation point for accurate and consistent results from the Vertex system. The method and angle of lighting depends on the application. Flood lighting should be used in all cases to provide an even spread of light and avoid creating lighting “hot spots”.
-
Page 10: Technical Setup Manual
3. Ensure the Vertex is powered and connected to the proper network before trying to connect to Connecting to the System 1. While connected to the same local area network that the Vertex is on, launch WipFrag on your preferred device. It is recommended to use a Windows PC for first time setup. - Page 11 Setup Wizard feature to see streaming images from the camera and determine the image quality. The lens settings should be set once the Vertex is installed in the actual analysis location. Either perform this procedure in close proximity to the Vertex so that you can view the image while manipulating the lens settings, or coordinate with another person to adjust the lens settings while you monitor the image quality.
- Page 12 3. Set Zoom: Zoom the camera lens in so that the image is filled with target material (or so the image covers the width of the material on the conveyor belt). Do not include anything in the image that you do not need to analyze, such as edges of the conveyor belt which are always empty of material.
- Page 13 The details of using WipFrag 3 as an HMI can be found in the WipFrag 3 manual under Sections 6 through 8, pages 22 – 32. A copy of the WipFrag 3 manual is provided with your Vertex. The latest edition of the manual is always available through the Help feature of WipFrag 3 software.
- Page 14 Accessing Data Note: For automated communications via Modbus TCP, OPC UA or other methods, please consult your WipFrag 3 manual. To access the daily and yearly logfiles from the system, simply use any Windows PC connected to the same network as the system and follow the steps below: Open the file browser.
- Page 15 Further Support Those with questions concerning WipWare sales, user training, and other specific applications should contact their closest representative. For a list of representatives in your area please visit www.wipware.com/contact-us or contact us directly at: WipWare Customer Support 685 Bloem Street North Bay, Ontario Canada P1B 4Z5 Phone: (705) 472-2664 (Monday to Friday 09:00-17:00 Eastern Time)
-
Page 16: Quality Care Instructions
QUALITY CARE INSTRUCTIONS Maintenance Schedule General System Check Up – Every 30 days • Verify lenses are clear and free of dust or debris • Verify cameras are online when material is present, and not triggering when material is not present Notify WipWare Support if components become •...
