Summary of Contents for Yard force ER U45
- Page 1 Model ER U45 ELECTRIC SHREDDER Original Instructions READ & UNDERSTAND INSTRUCTION MANUAL Save all warnings and instructions for future reference. Hotline: 1300 418 640 Monday/Friday: 9.00am to 4.30pm Saturday: 9.00am to 3.00pm Email: service@actionspares.com.au...
- Page 2 Read this manual carefully prior to assembling and operating the shredder. It is dangerous to operate this product without being familiar with these instructions. Keep this manual in a safe place and have it ready for future reference.
-
Page 3: Table Of Contents
ER U45 Original instructions CONTENT Intended use General safety warning 6~11 Symbols 12~13 Technical specifications Parts description Package content Assembly Operation 16~18 Cleaning, maintenance and storage Troubleshooting Warranty... -
Page 6: Intended Use
INTENDED USE This shredder is designed for shredding garden material such as tree cuttings, hedge cuttings and garden waste. Any other use is deemed to be a case of misuse. This shredder is designed for domestic use only, it is not design for commercial or trade use. GENERAL SAFETY WARNINGS IMPORTANT! Read this instruction manual carefully before operation. - Page 7 GENERAL SAFETY WARNINGS inspect the machine, the supply and extension cord for signs of damage or ageing. 6. If an extension cord is used it shall not be of lighter grade than the supply cord already fitted to the appliance. 7.
- Page 8 GENERAL SAFETY WARNINGS Operation 1. Before starting the machine, look into the feeding hopper to make certain that it is empty. 2. Keep your face and body away from the feeding hopper's opening. 3. Do not allow hands or any other part of the body or clothing inside the feeding hopper, discharge chute, or near any moving part.
- Page 9 GENERAL SAFETY WARNINGS 10. Do not allow processed material to build up in the discharge zone, this may prevent proper discharge and can result in kickback of material through the feed intake opening. 11. If the machine becomes clogged, shut-off the power source and disconnect from supply before clearing debris.
- Page 10 GENERAL SAFETY WARNINGS Maintenance and storage 1. When the machine is stopped for servicing, inspection, or storage, or to change an accessory, shut off the power source, disconnect from supply, make sure that all moving parts have come to a complete stop and, where a key is fitted remove the key.
- Page 11 PRODUCT SAFETY WARNINGS break during use. 4. Damage to eyes and hearing if effective protections are not worn. 5. Injuries caused by prolonged use of a tool. When using any tool for prolonged periods ensure you take regular breaks. 6. Health hazards caused by breathing dust developed when using your machine (example: working with wood, especially oak, beech and MDF.)
-
Page 12: Symbols 12~13
SYMBOLS The following symbols are used in this instruction manual and/or on the shredder to attach your attention to possible risks. These symbols and the explanations that accompany them must be understood. WARNING! OR CAUTION! READ the instruction manual before using this shredder Beware of debris being ejected from the shredder Keep by standers away... - Page 13 SYMBOLS Switch off and remove plug from mains before adjusting, cleaning or if the power cord is entangled or damaged Do not expose to rain Sound power level Dispose of electrical appliances according to the regulation and requirement of your local council.
-
Page 14: Technical Specifications
TECHNICAL DATA Shredder: Model: ER U45 230 - 240V~ 50 Hz Rated voltage: Rated input wattage: 2400 W (P40) No load speed: 42 rpm Collection bin capacity: 60 L Protection class: IPX4 Max. branch cutting diameter: 45 mm Sound power level:... -
Page 15: Package Content
PACKAGE CONTENTS Fig. B A. 1 x Shredder unit B. 1 x Base frame C. 1 x Collection bin D. 2 x Wheels E. 2 x Wheel covers F. 1 x Instruction manual G. 2 x Feet H. 2 x Screw for the foot I. -
Page 16: Assembly
ASSEMBLY Figure B to F Mount the feet (3) on the base frame (16) with the screws provided. Insert the wheel axle (21) through the holes in the base frame (16), then insert the inner washers (18) onto each end of the wheel axle (21). Insert the two wheels (2) onto the wheel axle (21), place the outer washers onto the wheel axle and secure the wheels with the cotter pins (20). - Page 17 OPERATION Press the forward/reverse button to position and press the green ON button (10) continuously for reverse turning direction. The shredder will stop turning reversely when the green ON button (10) is released. Resetting the shredder This shredder is equipped with an overload protection. When the cutting blade is jammed, the motor will switch OFF automatically.
-
Page 18: Cleaning Maintenance And Storage
OPERATION WARNING! Cutting blade are sharp, always wear protective gloves when opening the cutting blade cover. Reset the shredder if it is overloaded and automatically stop. Empty the collection bin if it is full. Change the turning direction to reverse to remove the jammed material. Open the cutting blade cover (23) and remove the jammed material if it cannot be removed from outside. -
Page 19: Troubleshooting
TROUBLESHOOTING Problem Possible cause Possible solution Shredder not running No Power Check power outlet and plug Locking lever (4) is in down Push the locking lever to ON position position Forward/reverse button is in Press the forward/reverse button to middle position forward position Shredder is overloaded Reset the shredder by press the reset... -
Page 20: Warranty
WARRANTY This product is covered by a 1 year parts and labour warrant against manufacturing defects. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
