This instruction manual has been prepared especially for the operator of this equipment. Your new lift is the product of over
15 years of continuous research, testing and development, it is the most technically advanced lift on the market today.
YL-250
READ THIS ENTIRE MANUAL BEFORE INSTALLATION &
5000KG 5 TON BASE PLATE CAR HOIST
Installation and operation manual
RECEIVING
Ensure shipment is thoroughly inspected as soon as received.
The signed Bill of Lading is acknowledgement by the shipping
carrier as receipt that this product as listed on invoice is in good
condition for shipment. For your protection: If any goods listed on
this Bill of Lading are missing or damaged, do not accept goods
until the shipping carrier makes a notation on the freight bill of
the missing or damaged goods.
KEEP THIS OPERATION MANUAL NEAR THE MACHINE AT ALL TIMES. ENSURE ALL USERS READ THIS MANUAL.
KEEP THESE INSTRUCTIONS ON HAND. PLEASE READ THE ENTIRE CONTENTS OF THIS MANUAL PRIOR TO INSTALLATION AND
OPERATION. BY PROCEEDING WITH LIFT INSTALLATION AND OPERATION YOU AGREE THAT YOU FULLY UNDERSTAND THE FULL
CONTENT OF THIS MANUAL. FORWARD THIS MANUAL TO ALL OPERATORS. FAILURE TO OPERATE THIS EQUIPMENT AS DIRECTED
OPERATION COMMENCES
IMPORTANT SAFETY INSTRUCTIONS
MAY CAUSE INJURY OR DEATH.
BE SAFE
Your hoist was designed and built with safety in mind. To
increase your overall safety operate with proper training
and thoughtful operation. DO NOT operate or repair this
equipment without reading this manual and the important
safety instructions included throughout. Ensure ALL USERS
read and understand this manual.
READ FIRST
Do not operate this machine
until you have read and
understood all dangers, warnings
and cautions in this manual
YOUR
SAFETY
OUR
STANDARDS
