- Page 1 R2000 Truck MANURE SPREADER ART'S WAY MANUFACTURING CO., INC. 5556 W. HWY 9 ARMSTRONG, IA. 51239 712-864-3131 WWW.ARTSWAY-MFG.COM...
-
Page 3: Table Of Contents
INTRODUCTION Thank you for purchasing a Roda Spreader. We appreciate your business. Here at Roda, we do our best to provide you with a rugged and durable unit, which is easy to maintain. If you have any suggestions for any of our products, please let us know. -
Page 4: Safety
SAFETY UNDERSTAND SAFETY WORDS AND SYMBOLS THIS SAFETY ALERT SYMBOL is used in this manual whenever personal safety is involved and means ATTENTION! BECOME ALERT! It stresses an attitude of “HEADS UP” for safety. Read and understand all pages in this manual that bear this safety symbol and…TAKE TIME TO BE CAREFUL! The Signal Word or Message areas of all safety decals are color coded to indicate the level of hazard. - Page 5 SAFETY OPERATING SAFETY PRECAUTIONS WHEN THE SPREADER IS IN OPERATION, IT HAS MANY MOVING PARTS, WHICH COULD CAUSE SEVERE INJURY OR DEATH TO PERSONS COMING IN CONTACT WITH THESE PARTS. TO HELP AVOID SERIOUS ACCIDENTS, THE FOLLOWING GUIDELINES MUST BE FOLLOWED. •...
-
Page 6: Safety Decals & Location
• REPLACE ANY DAMAGED OR WORN DECAL. Once any part of a decal becomes non-readable, it should be replaced. Replacement decals may be ordered through your dealer or Roda Manufacturing. • WHEN REPLACING DECALS, be sure the surface area is clean and dry, peel the backing off the decal, and apply to the unit. - Page 7 SAFETY SAFETY DECALS...
- Page 8 SAFETY SAFETY DECAL LOCATION MODEL AND SERIAL NUMBER INFORMATION s located in the upper center area of the front panel. This is the number to give service personnel for parts and service questions.
-
Page 9: Manure Spreader Safety
MANURE SPREADER SAFETY THERE ARE INHERENT HAZARDS ASSOCIATED WITH THE OPERATION OF A MANURE SPREADER. FOR YOUR SAFETY: • ONLY PROPERLY INSTRUCTED PEOPLE SHOULD OPERATE THE SPREADER. Do not allow children or inexperienced persons to operate spreader. • KEEP ALL GUARDS AND SHIELDS IN PLACE. Moving parts can crush and dismember. •... -
Page 10: Pre-Operation
PRE-OPERATION IMPORTANT: READ BEFORE OPERATING SPREADER. IT IS THE RESPONSIBILITY OF THE OWNER TO MAKE SURE THE SPREADER IS SET UP PROPERLY. THE FOLLOWING RECOMMENDATIONS SHOULD BE HELPFUL. • CHECK FOR PROPER ASSEMBLY, adjustment and lubrication. Check to be sure all bolts and setscrews are tight. -
Page 11: Lubrication
CAUTION WHEN WORKING ON THIS MACHINE! It is extremely important to properly lubricate your new RODA machine before it is used for the first time. If the mechanical drive components of your unit are not protected from shock and frictional abrasion, the wear rate of these components will be vastly accelerated and their life span will be drastically reduced. -
Page 12: Inspection & Adjustments
• SHIELDING to be sure all shielding is in place and functioning properly. Replace all damaged or missing shielding immediately-Contact your nearest dealer or the Roda parts/service dept. for more information. Check bolts and Set Screws after a few hours of use and each month thereafter, and tighten if necessary. -
Page 13: Spreader Operation
If apron is loose, remove one link from each side of each apron chain assembly and readjust to tension as shown. CAUTION: Over tightening can cause premature failure of the drive components. SPREADER OPERATION ALWAYS REFER TO THE OPERATING SAFETY PRECAUTIONS AND SAFETY DECAL SECTIONS OF THIS MANUAL BEFORE OPERATING THIS SPREADER LOADING •... - Page 14 OPERATION • BEFORE OPERATING, BE SURE NO ONE IS NEAR THE SPREADER AND THAT THE DISCHARGE AREA IS CLEAR OF ALL OBJECTS OR PERSONS THAT COULD BE HARMED IF MATERIAL WAS DISCHARGED! • WITH THE VEHICLE STOPPED and the engine throttled down, engage the PTO per manufacturers instructions.
-
Page 15: Control Box Operation
Control Box Operation: Manure: -PTO on truck (separate from control box) is turned on, hydraulic pump engaged (and vertical beaters if equipped) -Control box power switch is turned on -Beater switch is turned on (if equipped with horizontal beaters) -Slop Gate “Open” switch must be activated before apron will engage -Apron switch moved to “manure”... -
Page 16: Apron Drive Breakdown
APRON DRIVE BREAKDOWN (units with Berma apron drive) - Page 17 APRON DRIVE PARTS LIST (units with Berma drive apron) ITEM NO. PART NUMBER DESCRIPTION Default/QTY. 200013 FLASHING,FRONT 200022 STRAP FOR FRONT FLASHING 200032 SHAFT,APRON CHAIN-FRONT 200033 APRON CHAIN (20') 200033-01 APRON FLIGHT 200069 REAR GANG FLOOR SECTION 200072 FLOOR SECTION 200074 FRONT IDLER SPROCKET 200084...
- Page 18 APRON DRIVE BREAKDOWN (units with Superior drive apron)
- Page 19 APRON DRIVE PARTS LIST (units with Superior drive apron) ITEM NO. PART NUMBER DESCRIPTION QTY. 200100 VB, REAR GANG 200032 SHAFT, APRON CHAIN-FRONT 200074 FRONT IDLER SPROCKET 200069 REAR GANG FLOOR SECTION FAB K5050-2.00 1/2" SQR KEY 2" LONG 200084 OUTSIDE APRON TIGHTENER 200085 INSIDE APRON TIGHTENER...
-
Page 20: Driveline Breakdown
DRIVELINE BREAKDOWN... - Page 21 DRIVELINE PARTS LIST ITEM EXPLODED PART NUMBER DESCRIPTION VIEW/QTY. 200121 DRIVE SHAFT 200170 DRIVE SHAFT EXT. (24' BOX) 200186 PUMP ADAPTER 160047 or 160048 REAR PTO SHAFT FOR 22' BOX OR 20' & 24' BOX BELT DRIVE SYSTEM 5 V-BELT DRIVE (VERSION 1) H75-01-8198 VERTICAL BEATER...
-
Page 22: Belt Drive Breakdown
BELT DRIVE BREAKDOWN... - Page 23 BELT DRIVE PARTS LIST ITEM EXPLODED PART NUMBER DESCRIPTION VIEW/QTY. 200107 BDS TAKE UP BRKT 200108 PULLEY MNT 1 200109 PULLEY MNT 2 200110 SPACER 200111 LOWER BELT DRIVE SHIELD 200112 TOP BELT DRIVE SHIELD 200115 TOP PULLEY SHAFT 200116 BOTTOM PULLEY SHAFT 200117 TAKE UP BOLT...
-
Page 24: Belt Drive Breakdown (37Mm)
BELT DRIVE BREAKDOWN (37MM) - Page 25 BELT DRIVE PARTS LIST (37MM) Explode ITEM NO. PART NUMBER DESCRIPTION View/QTY. 200117 TAKE UP BOLT 200123 FRONT PANEL ASSY (POLY CHAIN) 200124 TAKE UP PLATE (POLY CHAIN) 200125 REAR PANEL ASSY (POLY CHAIN) 200192 BENT SHIELD (POLY CHAIN) 200193 FLAT SHIELD (POLY CHAIN) 200194 SPACER (POLY CHAIN)
- Page 26 WORM GEAR BREAKDOWN (Superior Gear Box)
- Page 27 WORM GEAR BREAKDOWN PARTS LIST (Superior Gear Box) ITEM N O . P ART N UM BER DESC RIPTIO N Q TY. R ETAIN IN G RIN G , EXT 203293 1.00 SH FT P LUG , 1/2-14 N PT 400300 SC H D W /3M EN D C AP,...
- Page 28 HYDRAULIC TANK BREAKDOWN...
- Page 29 HYDRAULIC TANK PARTS LIST Tank ITEM NO. PART NUMBER DESCRIPTION Breakdown/QTY. 200007 SHEET,TANK COVER 200122 VALVE BODY ADAPTER PLATE C34-01-3117 GAUGE, SIGHT/TEMP 5" METRIC THREAD BLACK ANODIZED C28-01-3132 TANK, HYD STRAINER, 4" x 2-1/2" STEEL WITH BYPASS C28-01-3131 TANK, HYD MOUNTED FILTER WITH SYNTHETIC ELEMENT AA# 5931 C28-01-3100 FILTER, HYD BREATHER C28-02-3129...
-
Page 30: Upper Valve Hydraulic Breakdown
UPPER VALVE HYDRAULIC BREAKDOWN ITEM UPPER PART NUMBER DESCRIPTION VALVE/QTY. C67-08-3114 VALVE, HYD 3 BANK 40/21/7 ADD-A-FOLD T53-42-2020 TEE, HYD, #20 MALE JIC X #20 MALE JIC #20 MALE ORING T54-44-2020 ADAPTER, HYD, #20 FEMALE SWIVEL FLARE X 1-1/4" FEMALE PIPE T81-03-2020 NIPPLE, PLATED, KING, 1-1/4"... -
Page 31: Lower Valve Hydraulic Breakdown
LOWER VALVE HYDRAULIC BREAKDOWN ITEM LOWER PART NUMBER DESCRIPTION VALVE/QTY. C67-08-3114 VALVE, HYD 3 BANK 40/21/7 ADD-A-FOLD T60-47-0810 COUPLER, #10 MALE ORB X #8 FEMALE STC T60-47-1212 COUPLER, #12 MALE ORB X #12 FEMALE STC T60-47-1616 COUPLER, #16 MALE ORB X #16 FEMALE STC T55-47-1012 REDUCER, HYD, #10 MALE ORING X #12 FEMALE O-RING T55-47-1612... - Page 32 20’ BOX APRON HYDRAULICS BREAKDOWN...
- Page 33 20’ BOX APRON HYDRAULICS PARTS LIST ITEM PART NUMBER DESCRIPTION QTY. C47-00-3122 MOTOR, HYD EATON 2000 SERIES 9.65 CIR 2-BOLT 1" KEYED, SIDE PORTS O74-01-5069 GEARBOX, BERMA, RIGHT ANGLE T53-46-1010 CONNECTOR, HYD, #10 MALE JIC X #10 MALE ORING, STR THREAD T53-20-1010 90 ELBOW, 7/8-14, M-FLARE x M-"O"...
- Page 34 22’ BOX APRON HYDRAULICS BREAKDOWN...
- Page 35 22’ BOX APRON HYDRAULICS PARTS LIST ITEM PART NUMBER DESCRIPTION QTY. C47-00-3122 MOTOR, HYD EATON 2000 SERIES 9.65 CIR 2-BOLT 1" KEYED, SIDE PORTS O74-01-5069 GEARBOX, BERMA, RIGHT ANGLE T53-46-1010 CONNECTOR, HYD, #10 MALE JIC X #10 MALE ORING, STR THREAD T53-20-1010 90 ELBOW, 7/8-14, M-FLARE x M-"O"...
- Page 36 24’ BOX APRON HYDRAULICS BREAKDOWN...
- Page 37 24’ BOX APRON HYDRAULICS PARTS LIST ITEM PART NUMBER DESCRIPTION QTY. C47-00-3122 MOTOR, HYD EATON 2000 SERIES 9.65 CIR 2-BOLT 1" KEYED, SIDE PORTS O74-01-5069 GEARBOX, BERMA, RIGHT ANGLE T53-46-1010 CONNECTOR, HYD, #10 MALE JIC X #10 MALE ORING, STR THREAD T53-20-1010 90 ELBOW, 7/8-14, M-FLARE x M-"O"...
- Page 38 20’-22’ SLOP GATE HYDRAULICS BREAKDOWN...
- Page 39 20’-22’ SLOP GATE HYDRAULICS PARTS LIST ITEM PART NUMBER DESCRIPTION QTY. C21-01-3116 CYLINDER, HYD 2" X 24" STROKE T52-36-0606 TEE, HYD, #6 MALE JIC T52-77-0606 BULKHEAD, 90 DEGREE 9/16"-18 X 9/16"-18 T52-90-0606 BULKHEAD, ADAPTER NUT 9/16"-18 200206 HOSE, BULKHEAD TO TEE 200207 HOSE, BULKHEAD TO VALVE 200218...
-
Page 40: 24' Slop Gate Hydraulic Breakdown
24’ SLOP GATE HYDRAULICS BREAKDOWN... - Page 41 24’ SLOP GATE HYDRAULICS PARTS LIST ITEM PART NUMBER DESCRIPTION QTY. C21-01-3116 CYLINDER, HYD 2" X 24" STROKE T52-36-0606 TEE, HYD, #6 MALE JIC T52-77-0606 BULKHEAD, 90 DEGREE 9/16"-18 X 9/16"-18 T52-90-0606 BULKHEAD, ADAPTER NUT 9/16"-18 200206 HOSE, BULKHEAD TO TEE 200207 HOSE, BULKHEAD TO VALVE 200230...
-
Page 42: Frame And Shield Breakdown
FRAME AND SHIELD BREAKDOWN... - Page 43 FRAME & SHIELD PARTS LIST ITEM Frame & PART NUMBER DESCRIPTION Shield/QTY. 200001 WMT,MAIN FRAME 200005 SHEET,ACCESS PANEL 200008 SIDE ACCESS PANEL 200009 WMT,BEARING GUIDE 200010 WMT,BEARING GUIDE 200015 SHEET,ACCES COVER 200088 LEFT ACCESS PANEL 200095 LEFT HEADBOARD GUSSET 200096 RIGHT HEADBOARD GUSSET 200097 HEADBOARD ASSEMBLY...
-
Page 44: 20' Manure-Forage Option Breakdown
20’ MANURE-FORAGE OPTION BREAKDOWN... - Page 45 20’ MANURE-FORAGE OPTION PARTS LIST 20' Manure- ITEM PART DESCRIPTION Forage NUMBER Option/QTY. 200057 EXTENSION PANEL 200058 FRONT EXTENSION PANEL 200059 LEFT REAR EXT PANEL 20' 200060 RIGHT REAR EXT PANEL 20' 200062 EXTENSION BRACE 200063 RUBBER SEAL 200064 LEFT GATE EXTENSION PANEL 200065 RIGHT GATE EXTENSION PANEL 200066...
-
Page 46: 22' Manure-Forage Option Breakdown
22’ MANURE-FORAGE OPTION BREAKDOWN... - Page 47 22’ MANURE-FORAGE OPTION PARTS LIST 22' Manure- ITEM PART DESCRIPTION Forage NUMBER Option/QTY. 200057 EXTENSION PANEL 200058 FRONT EXTENSION PANEL 200062 EXTENSION BRACE 200063 RUBBER SEAL 200064 LEFT GATE EXTENSION PANEL 200065 RIGHT GATE EXTENSION PANEL 200066 RIGHT REAR GATE EXT. PANEL 200067 LEFT REAR GATE EXT.
-
Page 48: 24' Manure-Forage Option Breakdown
24’ MANURE-FORAGE OPTION BREAKDOWN... - Page 49 24’ MANURE-FORAGE OPTION PARTS LIST 24' Manure- ITEM PART DESCRIPTION Forage NUMBER Option/QTY. 200057 EXTENSION PANEL 200058 FRONT EXTENSION PANEL 200062 EXTENSION BRACE 200063 RUBBER SEAL 200064 LEFT GATE EXTENSION PANEL 200065 RIGHT GATE EXTENSION PANEL 200066 RIGHT REAR GATE EXT. PANEL 200067 LEFT REAR GATE EXT.
-
Page 50: Slop Gate Breakdown
SLOP GATE BREAKDOWN (OPTIONAL EXT. KIT) - Page 51 SLOP GATE PARTS LIST PART Slop Gate ITEM NO. DESCRIPTION NUMBER Breakdown/QTY. 200042 SLOP GATE 200043 FLASHING,SLOP GATE 200044 FLASHING,SLOPGATE 200045 FLASHING,SLOPGATE 200047 WMT,SLOP GATE PIVOT 200048 WMT,FLAG PIN 200049 FLASHING,SLOP GATE-BOTTOM 200064 LEFT GATE EXTENSION PANEL 200065 RIGHT GATE EXTENSION PANEL 200066 RIGHT REAR GATE EXT.
- Page 52 Roda Manufacturing Incorporation warrants, in accordance with the provisions below, to the original purchaser for the period of (12) months from the date of delivery of a Roda machine that the machine is free from defects in material or workmanship. Roda’s obligation under this warranty is to repair or replace, at Roda’s election, without charge and at the place of business of a dealer authorized to handle Roda machinery,...
- Page 53 Roda Manufacturing Incorporation warrants, in accordance with the provisions below, to the original purchaser for the period of (12) months from the date of delivery of a Roda machine that the machine is free from defects in material or workmanship. Roda’s obligation under this warranty is to repair or replace, at Roda’s election, without charge and at the place of business of a dealer authorized to handle Roda machinery, any part or parts of the machine which, in the judgment of Roda, prove to be defective.
