MF1017 - 02
CMOS 4 - BIT SINGLE CHIP MICROCOMPUTER
S5U1C63002P
Manual
(Peripheral Circuit Board for S1C63158/63358)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S5U1C63002P and is the answer not in the manual?

Questions and answers

Summary of Contents for Epson/Seiko S5U1C63002P

  • Page 1 MF1017 - 02 CMOS 4 - BIT SINGLE CHIP MICROCOMPUTER S5U1C63002P Manual (Peripheral Circuit Board for S1C63158/63358)
  • Page 2 NOTICE No part of this material may be reproduced or duplicated in any form or by any means without the written permission of Seiko Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any liability of any kind arising out of any inaccuracies contained in this material or due to its application or use in any product or circuit and, further, there is no representation that this material is applicable to products requiring high level reliability, such as medical products.
  • Page 3 Development tools for the S1C63/88 Family Previous No. New No. Previous No. New No. ADP63366 S5U1C63366X ADS00002 S5U1C88000X1 ADP63466 S5U1C63466X GWH00002 S5U1C88000W2 ASM63 S5U1C63000A URM00002 S5U1C88000W1 GAM63001 S5U1C63000G ICE63 S5U1C63000H1 PRC63001 S5U1C63001P PRC63002 S5U1C63002P PRC63004 S5U1C63004P PRC63005 S5U1C63005P PRC63006 S5U1C63006P PRC63007 S5U1C63007P URS63366 S5U1C63366Y...

  • Page 5: Table Of Contents

    CONTENTS S5U1C63002P Manual (Peripheral Circuit Board for S1C63158/63358) This manual describes how to use the S1C63 Family Peripheral Circuit Board (S5U1C63002P). This circuit board is used to provide emulation functions when it is installed in the ICE (S5U1C63000H1), a debug- ging tool for the 4-bit Single Chip Microcomputer S1C63 Family.

  • Page 7: Chapter 1 Introduction

    "FOG63XXX" software tool) into the ICE using the debugger command. 1.2 Components of S5U1C63002P After unpacking your S5U1C63002P package, check to see that all of the following components are included. (1) S5U1C63002P main unit (S5U1C63002P board, S5U1C63003P board) ....1 pair (2) I/O cable (80-pin+40-pin/40-pin ×...

  • Page 8: Chapter 2 Installing S5U1C63002P

    (2) Insert the S5U1C63002P board into the ICE along the 2nd guide rails (lower slot) until the tip of the board touches the back of the ICE. If some other board is mounted on the guide rails, remove that board by using the jig supplied with the ICE before you insert the S5U1C63002P board (see Figure 2.1.3).

  • Page 9: Chapter 3 Precautions On Using The S5U1C63002P Peripheral Circuit Board

    S5U1C63002P board for open-drain output and interface them with a voltage level exceeding V <Pull-up resistance> The pull-up resistors on the S5U1C63002P board are fixed to a resistance value of about 220 kΩ which is different from that of an actual IC. Consult the technical hardware manual to check the pull-up resistance of the actual IC.
  • Page 10 - There is a delay between the time the power to the SVD circuit is turned on and the time the SVD data is detected. This delay on the S5U1C63002P board is set to between 61 and 92 µsec. For the delay on an actual IC, consult the technical hardware manual to ensure that there is a sufficient delay before the output voltage is detected.
  • Page 11 IC. - The S5U1C63002P board contains oscillators for the OSC1 and OSC3. If the OSC3 oscillator is not used on an actual IC, care should be exercised because operations are performed on the emulation board by using its OSC3 circuit.

  • Page 12: Chapter 4 Name And Function Of Each Part

    RESET Fig. 4.1 Top view of the S5U1C63002P board (1) RESET switch This switch resets the internal circuits of the S5U1C63002P board, and supplies a reset signal to the ICE. (2) Register monitor LED The LED lights up when the corresponding register contains logic 1 and goes out when the register contains logic 0.
  • Page 13 (7) CR oscillation frequency adjusting control When you choose a CR oscillator on the S5U1C63002P board, you can use this control to adjust the CR oscillation frequency by using a screwdriver, etc. The adjustment range is approx. 30 kHz to 190 kHz for the OSC1, and approx.

  • Page 14: Chapter 5 Connecting The S5U1C63002P To The Target System

    This chapter describes how to connect the S5U1C63002P board to the target system. To connect the S5U1C63002P board to the target system, use the I/O connection cable (80-pin+40-pin/40- pin × 2, flat type) included with this package. Handle with this connector carefully as the power (V ) is supplied through this connector.
  • Page 15 CHAPTER 5: CONNECTING THE S5U1C63002P TO THE TARGET SYSTEM Table 5.1 I/O connector pin assignment 40-pin CN1-1 connector 40-pin CN1-2 connector Pin name Pin function Pin name Pin function Power supply (+) Power supply (+) Power supply (+) Power supply (+)

  • Page 16: Chapter 6 Product Specifications

    CHAPTER 6: PRODUCT SPECIFICATIONS CHAPTER RODUCT PECIFICATIONS The components specifications of the S5U1C63002P are listed below. S5U1C63002P 254 mm (wide) × 144.8 mm (depth) × 13 mm (height) Dimension: (including screws) Weight: Approx. 180 g Power supply: DC 5 V ± 5%, less than 1 A (supplied from ICE main unit) S5U1C63003P 254 mm (wide) ×...
  • Page 17 International Sales Operations AMERICA ASIA EPSON ELECTRONICS AMERICA, INC. EPSON (CHINA) CO., LTD. 28F, Beijing Silver Tower 2# North RD DongSanHuan - HEADQUARTERS - ChaoYang District, Beijing, CHINA 1960 E. Grand Avenue Phone: 64106655 Fax: 64107319 EI Segundo, CA 90245, U.S.A. Phone: +1-310-955-5300 Fax: +1-310-955-5400 SHANGHAI BRANCH...
  • Page 18 S5U1C63002P Manual (Peripheral Circuit Board for S1C63158/63358) ELECTRONIC DEVICES MARKETING DIVISION EPSON Electronic Devices Website http://www.epson.co.jp/device/ First issue October, 1997 Printed February, 2001 in Japan...
