LED #2
Wireless Mesh
Activity
Orange
LED #3 Signal Strength
Indicator
Blue
LED #4 Messages to/from
website
Red

Using the Pipeline Watchdog Web Monitor

Once the WatchdogCP system is properly installed in the field, the user's primary contact with the
system will come by using the website. For this reason, Elecsys has put a lot of thought into making
the website simple and intuitive for CP technicians to use.
Key considerations were:
A. No need for laptop reprogramming in the field – just install it and set all
B. Make it easy to automate monthly data reports
C. Make it easy to import data reports into popular CPDM programs
D. Make it easy to set up notifications for various conditions to cell phones or

1.7 Log onto the Elecsys WatchdogCP Web Monitor

It is assumed that you have been set up as a user by your company manager or by Elecsys Support
(913-825-6366) and have had initial WatchdogCP web training.
Log onto the Elecsys WatchdogCP Web Monitor website (http://secure.watchdogcp.com/) using your
assigned Username (your email address) and Password.

1.8 Enter Site Data

When Elecsys ships new RMUs to a customer, a new default Site page is created for each unit.
These can be found under the CP Group: New Units.
Each new unit should be updated with the correct rectifier site data where the RMU will be deployed.
P/N 86-0006-00
Watchdog II Mesh User Manual
2 flashes: Unit is going to sleep
Slow flash: Searching for 'mesh' modules (lasts 15 seconds
per module if all is well; 65 seconds otherwise)
Quick flashes: Indicates signal strength
4 flashes: Excellent signal
3 flashes: Good signal
2 flashes: Fair signal
1 flashes: Poor signal
No flashes during entire test: No signal
2 blinks:
3 blinks:
4 blinks:
5 blinks:
interruption command, or new configuration)
6 blinks:
parameters from the website.
email
Rev E 01-2020
Message written to cellular or satellite modem
Message transmitted from modem to website
Acknowledgement message received from website
Command message received from website (poll,
Unknown or bad message received
