Stakon COMFORT CRIMP ERG4007 Instructions For Use

ERG4007 COMFORT CRIMP
COMPRESSION TOOL WITH SHURE STAKE
For Installing 8 and 6 AWG RD, RDV, RE, and REV
IMPORTANT:
information in this manual before operating or servicing this tool.
WARNING
KEEP ALL BODY PARTS AWAY FROM DIE NEST
DURING GAGING OR CRIMPING PROCEDURE.
6
In the event the SHURE STAKE
1.0
1.1
For Use With Insulated
Terminals 8, 6 AWG
1. Open handles fully.
2. Insure lower die is in the
proper position for the
terminal being installed.
3. Position terminal in the
rear nest. Tongue markings
should be facing up.
4. Close the handles slightly to
secure the terminal. Do not
deform the terminal.
5. Insert stripped wire.
6. Close handles until SHURE
STAKE mechanism cycle
®
has been completed.
TA04532 A Page 1 of 2
TM
Insulated Terminals (Tubular Style Only)
Read and understand all of the instructions and safety
8
Model No.
MECHANISM must be released, please see Figure 5.
®
INSTRUCTIONS FOR USE
Figure 2
WARNING
HANDLES ARE NON-INSULATING.
DO NOT CRIMP ON HOT ENERGIZED WIRES.
1.2
To Rotate Lower Die
TO REMOVE:
1. Open handles fully.
2. Use your thumb, push lower
die up and out of jaw.
TO INSTALL:
1. Place die in lower jaw.
2.
Using finger pressure,
snap, lower die down
into position.
NOTE: Do not close handles of the
tool to insert lower die. Use finger
pressure only.
®
MECHANISM
®
Figure 1
Figure 3
