usi UNIVERSAL 5304CN Instructions Manual

Smoke & fire alarm with silence feature and alarm origination feature

Hide thumbs

Table of Contents

Quick Links

Download this manual

SMOKE & FIRE ALARM WITH SILENCE FEATURE

This smoke alarm uses an extremely small amount of a radioactive

element in the ionization chamber. Do not tamper with radioactive sealed

source or try to repair the smoke alarm yourself.

Smoke Alarm Limitations and Functions ................................. 2

Recommended Location of Alarms.......................................... 3

Avoid These Locations ............................................................ 4

Early Warning .......................................................................... 4

Installation Instructions ............................................................ 4

Electrical Shock Hazard .......................................................... 4

Locking/Tamper Feature .......................................................... 4

Wiring Instructions ................................................................... 5

Operation, Testing & Maintenance .......................................... 6

QUICK FIND

Cautions/Warnings .................................................................. 7

Silence Feature ....................................................................... 7

Backup Battery Replacement .................................................. 8

Develop and Practice a Plan of Escape .................................. 8

Operational Summary.............................................................. 9

Warranty ..................................................................Back Cover

MODEL 5304CN, 5304LCN

MODEL 2995CN, 2995LCN

AND ALARM ORIGINATION FEATURE

READ ALL INSTRUCTIONS

Need help?

Do you have a question about the UNIVERSAL 5304CN and is the answer not in the manual?

Questions and answers

Summary of Contents for usi UNIVERSAL 5304CN

Page 1: Table Of Contents
MODEL 5304CN, 5304LCN MODEL 2995CN, 2995LCN SMOKE & FIRE ALARM WITH SILENCE FEATURE AND ALARM ORIGINATION FEATURE READ ALL INSTRUCTIONS This smoke alarm uses an extremely small amount of a radioactive element in the ionization chamber. Do not tamper with radioactive sealed source or try to repair the smoke alarm yourself.
Page 2: Smoke Alarm Limitations And Functions
SMOKE ALARM LIMITATIONS AND FUNCTIONS There are three basic smoke alarm types: IoPhic ® , Ionization and Photoelectric. IoPhic ® is an ionization alarm containing a patent-pending Universal Smoke Sensing Technology. IoPhic ® alarms are very effective at detecting fast flaming fires and also respond very quickly to slow smoldering fires - up to 87% faster than the maximum allowable alarm limit (UL217 Smoldering Smoke Test on 5/26/2010, Underwriters Laboratories Project #09CA38078).
Page 3: Recommended Location Of Alarms
RECOMMENDED LOCATION OF ALARMS • Locate the first smoke alarm in the immediate area of the bedrooms. Try to protect the escape route as the bedrooms are usually farthest from an exit. If more than one sleeping area exists, locate additional smoke alarms in each sleeping area. If a hall is more than 40 feet (12 meters) long, install a smoke alarm at each end.
Page 4: Avoid These Locations
AVOID THESE LOCATIONS • the garage – products of combustion are produced when you start your vehicle. • near appliances or areas where normal combustion regularly occurs (kitchens, near furnaces, gas hot water heaters). Use smoke alarms with photoelectric sensors or smoke alarms with Silence Feature for these areas.
Page 5: Wiring Instructions
This alarm may be interconnected with a total of not more than 24 interconnected devices, i.e., as many as 11 other USI ELECTRIC or UNIVERSAL model smoke alarms or combination smoke and carbon monoxide (CO) or smoke and carbon monoxide / natural gas alarms;...
Page 6: Operation, Testing & Maintenance
/ event or heat alarm / event initiates the alarm. All CO alarms remain silent. Note that smoke alarms without battery backup will not respond during an AC power failure. NOTE: Relay Modules/USI-960 will not respond if a CO alarm / event initiates the alarm. 120 VAC 60Hz 100mA Max.
Page 7: Quick Find ® Alarm Originating Feature & Reset
NUISANCE ALARMS: The smoke alarm is designed to minimize nuisance alarms. Smoking will not normally set off the alarm unless smoke is blown directly into the smoke alarm. Combustion particles from cooking may set off the alarm if the smoke alarm is located close to the kitchen cooking surface.
Page 8: Backup Battery Replacement
LITHIUM Battery Models only - The LITHIUM battery is warranted to last for 10 years under normal operating conditions. Replace the battery with only LITHIUM type: (ULTRALIFE: U9VL-J or Ultralife U9VL-J-P). OPTIONAL BATTERY DRAWER TAMPER LOCKING PIN: To make your battery drawer tamper resistant, a locking pin has been provided (breakaway part on mounting bracket).
Page 9: Operational Summary
OPERATIONAL SUMMARY HORN RED LED GREEN LED CONDITION / RECOMMENDATION Silent Blinks On once Stays On Condition: AC Power is present. DC Power is present. approx every Recommendation: None, alarm is operating properly. 40-45 seconds Condition: AC Power is not present and alarm is receiving DC Power. Blinks On once Silent Recommendation: Check the breaker or fuse box for power.
Page 10: Warranty
If this product is found to be defective, USI’s only obligation, and your exclusive remedy, is the repair or replacement of the product, at USI’s discretion, provided that the product has not been damaged through misuse, abuse, accident, modifications, alteration, neglect or mishandling.

This manual is also suitable for:

Universal 5304lcn Universal 2995cn Universal 2995lcn
