Ozito PXBP-40B Instruction Manual

4.0Ah BATTERY
INSTRUCTION MANUAL
SPECIFICATIONS
Input: 18V
Battery Capacity: 4.0Ah Li-ion
Power Consumption: 72Wh
Weight: 0.65kg
ozito.com.au
1. Battery
2. Battery Release Button
3. Charge Indicator Button
DESCRIPTION OF SYMBOLS
V Volts
ac/~ Alternating Current
dc
Direct Current
mA Milliamperes
Lithium Ion Battery
Recycle Battery
Do not incinerate
Regulatory Compliance
Mark (RCM)
Read Instruction Manual
CARING FOR THE ENVIRONMENT
Power tools that are no longer usable should not be disposed of with
household waste but in an environmentally friendly way. Please recycle
where facilities exist. Check with your local council authority for
recycling advice.
Recycling packaging reduces the need for landfill and raw materials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your local
council authority for recycling advice.
1 2 3
PXBP-40B
Hz Hertz
W Watts
Ah Amp Hour
Warning
Do not store or use battery in
temperatures exceeding 50°C
Do not put in the rubbish
Do not get battery wet
Do not store battery when the charge
0%
is low; store between 40-60%.
40-60%
Do not expose to rain.
BATTERY SAFETY WARNINGS
THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS FOR
YOUR BATTERY.
1. Before charging the Power X Change battery, read all instructions and cautionary markings on the
charger, battery pack and the product using the battery pack.
2. DO NOT store or use the tool and battery pack in locations where the temperature may reach or
exceed 50°C (such as inside sheds or metal buildings in summer).
3. The battery pack is not fully charged out of the carton. First read the safety instructions and then
follow the charging notes and procedures.
4. The longest life and best performance can be obtained if the battery pack is charged when the air
temperature is between 18-24°C. Do not charge the battery pack in air temperatures below 0°C
or above 50°C. This is important and will prevent damage to the battery pack.
5. Do not incinerate the battery pack even if it is seriously damaged or is completely worn out. The
battery can explode in a fire.
6. Never attempt to open or dismantle the battery pack for any reason. If the plastic housing of the
battery pack breaks or cracks immediately discontinue use and do not recharge.
7. During charging, the battery must be placed in a well-ventilated area.
8. Keep battery pack out of reach of children.
9. Do not expose battery pack to heat or fire. Avoid storage in direct sunlight.
10. Do not short-circuit the battery pack. Do not store battery pack haphazardly in a box or drawer
where they may short circuit each other or be short-circuited by other metal objects.
11. Do not subject the battery pack to mechanical shock (sudden impacts).
12. In the event of a cell leaking, do not allow the liquid to contact the skin or eyes. If contact has
been made, wash the affected area with copious amounts of water and seek medical advice.
13. Do not use any charger other than that specifically provided for use with the battery pack.
14. Do not use battery pack with equipment it is not designed for.
15. Always keep battery pack clean and dry.
16. Do not use or charge the battery in wet weather conditions. Do not submerge the battery in
water.
17. Wipe the battery terminals with a clean dry cloth if they become dirty.
18. Do not leave a battery on prolonged charge when not in use.
19. After an extended period of storage it may be necessary to charge and discharge the battery pack
several times to obtain maximum performance.
20. Retain the manuals for future reference.
21. When possible, remove the battery pack from the equipment when not in use.
22. Do not store battery near flammable substances.
ELECTRICAL SAFETY
WARNING!
When using mains-powered tools, basic safety precautions,
including the following, should always be followed to reduce risk of fire, electric
shock, personal injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an
emergency, before operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and
New Zealand.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid hazard.
Note: Double insulation does not take the place of normal safety precautions when
operating this tool. The insulation system is for added protection against injury resulting
from a possible electrical insulation failure within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before
use, inspect the extension lead for signs of damage, wear and ageing. Replace the
extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an
extension lead not suitable for the power input of the tool or which is damaged or defective
may result in a risk of fire and electric shock.
To reduce the risk of electric shock, we recommend the use of a residual current device
(rated 30mA or less).
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the appliance.
