Summary of Contents for Nave TPMS TP001
- Page 1 TPMS TP001 Tire pressure monitoring system Manual...
- Page 2 Index: 1.Notice of usage 2.Specification 3.Installation of battery 4.QR code sticker 5.App installation & device installation 6.Error code & status 7.Program pause 8.Notice 9.Warranty Package includes : 1.TPMS set (including sensor/ CR2032 battery/ bolt) - 4 sensors for car version - 2 sensors for motorcycle version CR2032 - single sensor package...
- Page 3 1.Notice of usage Reminder: 1.Using chemical sealing system inside the tire could lead to TPMS malfunction. 2.Regularly check tire valve & external treads to make sure they work properly, as TPMS is only an optional safety equipment. 3.TPMS wireless signals could be lost by interference,wrongly operation and installation could also lead to signal loss.
-
Page 4: Specification
2.Specification Dimension: Width:24.4mm* Height:22.68mm Weight: 7.5g±0.2g(per sensor) Transmission distance: 10~30m line of sight Operation temp: -20℃~85℃ Tir pressure range: 0 KPa~800KPa Battery: CR-2032 (3.0V) Max power consumption: 107μA Transmission interface: Bluetooth BT 4.0 (BLE) 2.4-GHz/Bluetooth/Low Energy Compliant Output Power：0dBm... -
Page 5: Installation Of Battery
3.Installation of battery 1.Open the lid counter-clockwise. 2.Insert CR2032 battery with “+” facing up. 4.Finish 3.lose the lid clock-wise Notice: Please only use CR2032 battery for battery swap. Wrong battery could lead to malfunction and damage. - Page 6 4.QR code sticker QR code sticker is included inside the package, please do not lost it. QR code sticker number should match with TPMS sensor number , please pair the sensors by order on your phone app. QR Code 編碼貼紙僅此一份，請妥善保管，如遺失，恕不補發。...
- Page 7 5.App & TPMS installation & usage 5-1.APP download A.Please search “nAve TPMS”, and installation for free. B.Open the app, the app ca be used with your phone eit- her vertically or horizontally. nAve TPMS nAve TPMS 版本15.0.1...
- Page 8 5-2.App setup Click “ ” for setting A.Choose your language: Japanese, English,Chinese (sim- plified), Chinese (traditional) B.B.Choose “always-on” mode, then the app will always on. C.Turn on alarm overwrite mode, system alarm sound will function even in phone silent mode. Adjust the vol- ume to 50%~100%.
- Page 9 5-3.Build up new vehicle info Press “ ” enter vehicle info A.Press picture area to choose picture from database or to take a photo. B.Name your vehicle by pressing name area C.Choose vehicle spec, then press finish. D.To redo or edit, press the picture 3 secs. Back 車輛選擇...
- Page 10 5-4.Pairing the sensor Pairing the sensor on your App, please follow serial number and pair in order. A.Press 3 sec for pairing mode. B.Scan QR code with your phone for pairing, or enter the serial number below QR code for pairing. Back Back Back...
- Page 11 5-5.Installation of sensors 1.Lock the bolt onto the valve clock-wise. 2.Lock the sensor (with battery ) onto the valve clock-wise. 3.Use wrench to fasten the bot counter clock-wise , so the sensor & bolt will lock tightly. 4.Finish, then apply soap water on the sensor to see if leaking.
- Page 12 5-6.Tire pressure setup Press setup button to setup tire pressure. Follow the suggested tire pressure range form tire com- pany, tire pressure range can be set up automaticallyor manually. Back My Car Monitoring... Stop Back Pressure Unit (L)Front Tire1 (R)Front Tire2 Standard pressure Pressure Max Pressure Min...
-
Page 13: Error Code
6.Error code A.Wrong tire pressure Too low or too high, the background color will turn red + alarm sound B. Wrong tire temperature Too low or too high, the background color will turn red + alarm sound C. Sensor malfunction: 1.Please check if the sensor is missing 2.Please re-pair, choose then... -
Page 14: Program Pause
7.Program pause 1.Press “ ”button on right top of your app screen pause to pause. 2.Press “ ” button again on right top to resume. connect Back Stop Stop Connect My Car Monitoring... Back My Car Monitoring... (L)Front Tire1 (R)Front Tire2 (L)Front Tire1 (R)Front Tire2 setting... - Page 15 8.Notice 1.TPMS cannot guarantee the safety of your trip, please check your tire regularly. 2.Please pull over whenever you sees/hears alarm. 3.TPMS cannot detect any instant tire damage from outside environm- ent. 4. Do not operate TPMS and drive at the same time. 5.Sensor battery life varies by battery quality and usage.
-
Page 16: Warranty
9.Warranty Thank you for purchasing this device, we provide limited one year wa- rranty upon your purchase date, please do not lost your QR coe sticker , warranty card. Below conditions are not within our warranty: 1.Product damaged by nature cause 2.Product damaged by miss-use 3.Product damaged by not following the manual instruction 4.Product failure not caused by product... - Page 17 NCC警語 NCC 警語 低功率電波輻射性電機管理辦法 第十二條 型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均 不得擅自變更頻率、加大功率或變更原設計之特性及功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有 干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。 前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機 須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 警告 任何的自行修改或變更系統本體，將無法保證使用者的權益繼續 受到保護。 符合歐盟法規(European Union Regulatory Conformance) 本設備的CE標誌，符合歐盟 R&TTE Directive 1999/5/EC 的基本要求及 其他相關規定。 本設備符合下列標準： EN 300 328，EN62479，EN 301 489-1&17，EN 60950-1 符合歐盟法 規的聲明(EUDeclaration of Conformity ) Salutica Allied Solutions Sdn. Bhd. 在此鄭重聲明此藍芽設備符合 1999/5/EC 的基本要...
- Page 18 FCC 聲明 FCC Compliance and Advisory Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
