Thank you for purchasing this Ballatta shelving unit. Please ensure instructions are read in full before attempting to
assemble product.
WARNING:
IN ORDER TO PREVENT OVERTURNING, THIS PRODUCT PRODUCT MUST BE USED WITH THE WALL
ATTACHMENT DEVICE PROVIDED.
Installation should be carried out exactly according to the manufacturers instructions, otherwise a safety risk can
occur if incorrectly installed. Cabinets and shelving over 600mm high can be unstable and should be supported until
fixed to the wall.
This product is heavy, it should be assembled as near as possible to the point of use. Take care when lifting to avoid
personal injury and (or) damage to the product.
The fittings pack contains small items which should be KEPT AWAY FROM YOUNG CHILDREN.
Read this leaflet in full before commencing assembly.
Ref: 2507 / 2203
2203 BALLATTA SHELVING UNIT
1
Advertisement
Summary of Contents for Ercol BALLATTA 2203
- Page 1 2203 BALLATTA SHELVING UNIT Thank you for purchasing this Ballatta shelving unit. Please ensure instructions are read in full before attempting to assemble product. WARNING: IN ORDER TO PREVENT OVERTURNING, THIS PRODUCT PRODUCT MUST BE USED WITH THE WALL ATTACHMENT DEVICE PROVIDED. Installation should be carried out exactly according to the manufacturers instructions, otherwise a safety risk can occur if incorrectly installed.
-
Page 2: Pre-Assembly Preparation
Please check the pack contents before attempting to assemble this product. A full checklist of components is given in this leaflet. If any components are missing, please contact the retailer from whom you bought this product. Pre-assembly preparation Items you will need This is a two person operation Parts checklist 1 x R/H side frame... - Page 3 Step by step assembly instructions 1. Place 2x cam heads (A) into the holes of each back rail (3) and insert the 4x wooden dowels (D) by using soft hammer as shown below. 2. Place 2x cam heads (A) into the holes of each bottom rail (6) and insert the 2x wooden dowels (D) by using soft hammer.
- Page 4 4. Lay down the L/H side frame (1) on a smooth surface. With the aid of an assistant, place 5x back rails (3) and 2x bottom rails (6) on the side frame (1) by aligning the dowels. Tighten 7x grub screws (B) by using a screw 5.
- Page 5 6. With the aid of an assistant, carefuly turn the bookcase on its feet. Slide 2x fixed shelves (5) through the side frames (1 and 2) and secure them with 8x allen head bolts (E) by using the allen key (F) provided. 7.
- Page 6 8. If the bookcase is not level on your floor use the wedge (H) provided, and snap it o so that it does not protrude out from the cabinet’s leg, you can also snap it lengthways if desired. Ref: 2507 / 2203...
- Page 7 Wall Fixing Instructions 1 Place your product in the final position. Loosen the screws on the metal brackets just enough so that the slotted bracket can be extended to meet the wall. 2 Mark the wall through the bracket slot in the short face of the bracket. This is the mark for fitting the bracket to the wall.
- Page 8 A guide to wall mounting and fixings Warning Serious or fatal crushing injuries can occur from furniture tipping over. To prevent this furniture from tipping over it must be permanantly fixed to the wall. Wall fixing screws are not included, since different wall materials require different types of screws / fixings. Please ensure you use the correct screws / fixings for your type of walls and seek professional advice if you are not sure.
-
Page 9: Care And Maintenance
No liability will be accepted for damage or injury caused by incorrectly installed furniture. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE Ref: 2507 / 2203 Ercol Furniture Ltd, Summerleys Road, Princes Risborough, Buckinghamshire. HP27 9PX ercol.com YNG TAL 14 / ERBMT1 D: 11.07.2018 / RN 003...
