Part identification

Panel outlook picture, just for reference, please take the real until as standard.
Cabinet
Air inlet louver
Front grille
Front intake grille
Air filter
Control panel cover
(behind the front intake grille)
Panel outlook picture, just for reference, please take the real until as standard.
Cabinet
Air inlet louver
Front grille
Front intake grille
main control panel
Air filter
(behind the front intake grille)

Air direction adjustment

Vertical airflow direction vane
(Airfl o w direction adjustment up and down).
The vertical airflow direction vane is controlled by
positioning the vane to discharge the air upwards,
downwards or straight out.
-8-
