- Page 1 INSTALLATION/OPERATING INSTRUCTIONS AQUEFIER POOL HEATERS Model TM121 / WCC115 Trevor-Martin Corp., 4151 112 Terrace North, Clearwater, FL 33762 Bulletin PH-121...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW INSTRUCTIONS SAVE THESE INSTRUCTIONS TO THE HOMEOWNER Congratulations on your decision to purchase an AQUEFIER Pool Heater. The AQUEFIER Pool Heater is designed to heat your swimming pool by taking heat from the air in your backyard and transferring it into your pool.
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using this electrical equipment, basic safety precautions should always be followed, including the following: 1. READ AND FOLLOW ALL INSTRUCTIONS. 2. To reduce the risk of injury: a. The water in a pool or tub should never exceed 104 degrees F. A water temperature in excess of 104 degrees F is considered unsafe for all persons. -
Page 4: Locating The Pool Heater For Installation
LOCATING THE POOL HEATER FOR INSTALLATION The AQUEFIER Pool Heater must be installed outside near the pool pump/filter on a level area. Special care must be taken to ensure that air flow is not restricted on the side air inlets, the heat pump coil, or the top air discharge. -
Page 5: Installing The Pool Heater
INSTALLING THE POOL HEATER Pool Heater installation is divided into two sections: electrical connections, and pool piping connections. The Factory has fully installed the refrigeration loop and preset the controls. There are no job-site installation requirements for the heat pump. Wiring should only be done by licensed electricians. -
Page 6: Pool Piping Connections
1. Wiring must be sized per National Electrical Code requirements based on the pump load and conductor length. 2. Conductors must be installed in approved conduit. 3. The pool heater, the pool pump, and the pump timer must be grounded per National Electrical Code requirements. - Page 7 OPERATING THE POOL HEATER The AQUEFIER Pool Heater is designed to be easy to operate. The front panel contains a digital temperature control readout. The Pool Heater is set to reach and then maintain the selected pool water temperature, as long as the pool pump is running. Once the selected pool temperature has been reached, control of the pool pump is returned to the pool timer.
- Page 8 The control system includes a time delay to accurately check the pool water temperature, and an anti-cycle timer to protect the compressor. The time delay allows the control to get an accurate reading of the pool water temperature. The water in the heater may be hotter or colder than the water in the pool depending on weather conditions.
- Page 9 Water Side Pressure Drop Water Flow Pressure (gal./min.) Drop (psig) 0.23 0.46 0.74 1.06 1.42 1.86 2.32 Temperature Rise Across Heater Water Flow Temperature (gal./min.) Rise (deg. F) 10.0...
- Page 14 Startup Troubleshooting PROBLEM POSSIBLE CAUSE SOLUTION Temperature display not lit Check power supply to unit. Turn on or reset breaker. Unit will not start Check circuit breaker or fuses Check 24 volt transformer Check transformer/replace if required. Temperature display lit Unit will not start.
-
Page 15: Limited Warranty
Warranties, expressed or implied, written or oral. No employee, agent, dealer or other person is authorized to give any other Warranty on behalf of Trevor-Martin Corporation; nor to assume for Trevor-Martin Corporation any other liability in connection with this product; except as may be authorized by an officer of Trevor-Martin Corporation in a signed written document.
