Riviera Duratuf SENTRY SHEDS SG3030 Assembly Instructions Manual

3.020m x 3.020m
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ASSEMBLY INSTRUCTIONS
SG3030
BASE SIZE: 3.020m x 3.020m

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Duratuf SENTRY SHEDS SG3030 and is the answer not in the manual?

Questions and answers

Summary of Contents for Riviera Duratuf SENTRY SHEDS SG3030

  • Page 1 ASSEMBLY INSTRUCTIONS SG3030 BASE SIZE: 3.020m x 3.020m...

  • Page 3: Before You Start

    CONGRATULATIONS ON PURCHASING A DURATUF SENTRY SHED. BEFORE YOU BEGIN THE ASSEMBLY PLEASE NOTE SOME IMPORTANT POINTS BEFORE YOU START:  Read all instructions carefully  Identify all parts and check quantities against parts list  Select a level site ...
  • Page 4 SG3030 PARTS LIST DESCRIPTION DIAGRAM DESCRIPTION DIAGRAM CLADDING FLASHINGS CHECKED CHECKED Front/Back Wall Door Sides 1.850 m 1.810 m Gable Wall Angled Door Jamb 1.880 m (Measurement along 1.850 m centre of sheet) Gable Wall Angled Door Brace 1.940 m (Measurement along 1.160 m centre of sheet)

  • Page 5: Parts Location

    PARTS LOCATION Ridge Flashings—x 2 Roof Sheets Barge Flashing Spouting Back Wall Sheets Ridge Beam Jack Stud Top Plate Back Top Plate Side Top Plate Front Front Wall Sheets Door Brace Door Sheets Door Jambs Bottom Plate Front Side Wall Sheets Padbolt Support Bottom Plate Side Hinge...
  • Page 6 FOUNDATION No doubt by now you will have decided what sort of base you are putting down. Please read the section that applies to your situation. If you choose to pour a concrete base you will need to decide whether you wish to raise the base plate of your shed. This allows the cladding to protrude below the surface of the concrete and ensures a water tight pad.
  • Page 7 ASSEMBLE DOORS SELECT: 3 x 1.810 m Door Sheets (Narrow) 2 x 0.945 m Door Top/Bottom Flashings 2 x 0.495 m Door Top/Bottom Flashings 4 x 1.810 m Door Side Flashings 2 x 1.160 m Door Brace Flashings 2 x 0.915 m Door Brace Flashings 1 x 1.810 m Weatherstrip 6 x Hinges 1 x Padbolt Support Flashing...
  • Page 8 ASSEMBLE SIDE PANELS SELECT: IMPORTANT—IF YOU CHOOSE TO RAISE YOUR TIMBER BASE PLATE –READ THE FOLLOWING; 4 x 1.880 m Gable Wall Sheets (Angled) 4 x 1.940 m Gable Wall Sheets (Angled) For sheds with Raised Base Plate option only (see page 5), deduct 4 x 2.000 m Gable Wall Sheets (Angled) 30mm from measurement shown between Top and Bottom Plates on 2 x 3.020 m Top Plates (Red)
  • Page 9 ASSEMBLE BACK PANEL IMPORTANT—IF YOU CHOOSE TO RAISE YOUR TIMBER SELECT: BASE PLATE –READ THE FOLLOWING; 6 x 1.850m Wall Sheets For sheds with Raised Base Plate option only (see page 5), deduct 1 x 3.020 m Top Plate (Red) 30mm from measurement shown between Top and Bottom Plates on 1 x 3.020 m Bottom Plate (Green) all wall panels, so cladding protrudes 20mm below bottom plate...
  • Page 10 ASSEMBLE FRONT PANEL IMPORTANT—IF YOU CHOOSE TO RAISE YOUR TIMBER SELECT: BASE PLATE –READ THE FOLLOWING; 3 x 1.850 Wall Sheets For sheds with Raised Base Plate option only (see page 5), deduct 1 x 3.020 Top Plate (Red) 30mm from measurement shown between Top and Bottom Plates on 1 x 3.020 Bottom Plate (Green) all wall panels, so cladding protrudes 20mm below bottom plate 2 x 1.850 Door Jamb Flashings...

  • Page 11: Wall Panel Assembly

    WALL PANEL ASSEMBLY SELECT: SIDE 4 x Pre-made Wall Panels OVERLAPS 16 x 40mm Screws BACK 16 x Rivets TOP PLATE BACK WALL STEP 1:  Stand the Back Panel and the Side Panel BOTTOM PLATE up using someone to support the panels SIDE WALL while they are screwed together.

  • Page 12: Roof Assembly

    ROOF ASSEMBLY SELECT: IMPORTANT—FOR SHEDS WITH OPTIONAL CLEAR ROOF PANEL Assemble as below, making sure that the Clear Roof Sheets over- 12 x 1.600 m Roof Sheets lap the standard roof sheets on both sides. 2 x 3.055 m Spouting The Clear Roof Panel must be secured to the Top Plate and the 4 x 1.600 m Barges Ridge Beam.
  • Page 13 ROOF ASSEMBLY CONT... STEP 3:  Position 1 x roof sheet so that the top of the sheet is at the TOP PLATE centre of the Ridge Beam and the side of the sheet over BACK WALL hangs the end of the Ridge Beam and the Top Plate by BOTTOM PLATE 15mm.
  • Page 14 SECURING SHED Secure your shed using Treated Timber Pegs or a Bolt Down Kit TIMBER PEGS—WOODEN FLOOR  The optional Duratuf Timber Peg Down Kit includes six H5 treated timber pegs that can be hammered into the ground and then attached to the Base Plate with stainless steel screws.

  • Page 16: Year Warranty

    20 YEAR WARRANTY Riverlea Group Ltd warrant that the cladding used in the manufacture of the Sentry shed will not rust within 20 years from the date of purchase. Any liability for product failure that may arise will be limited to repair or replacement of the defective product and will only apply for the benefit of the original purchaser.
