Installation and Operating Instruction Manual
For California Customers
WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Model
Voltage
EBS-400
120V~60Hz
EBS-400-I
220V~50Hz
BEFORE OPERATING ANY EQUIPMENT, READ AND FAMILIARIZE YOURSELF WITH THESE USE AND SAFETY INSTRUCTIONS
Congratulations on your purchase of this SPECTRUM commercial Vacuum Sealer. When used as intended, and with
proper care and maintenance, you are sure to experience years of reliable operation from this equipment. To ensure
best results, it is important that you read and follow the instructions in this manual carefully. It is important to
keep these instructions in a safe place for future reference.
MANUAL IMPULSE BAG SEALER
Power
Amperage Plug Type
480W
4 A
NEMA 5-15P
480W
2.2 A
CEE 7/7
ELECTRIC COUNTERTOP
Overall Dimensions
Length
Depth
20-7/8"
3-5/8"
(530mm)
(92mm)
Seal Bar
15-3/4" (400mm)
Product
Height
Height
Weight
Base
Open
3-3/8"
12"
(86mm)
(305mm)
6.8 lbs
3.1 kgs
Seal Wire
1/8" (3mm)
Advertisement
Table of Contents
Summary of Contents for Winco SPECTRUM EBS-400
- Page 1 ELECTRIC COUNTERTOP MANUAL IMPULSE BAG SEALER Installation and Operating Instruction Manual For California Customers WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov Overall Dimensions Product Model Voltage Power Amperage Plug Type Height Height Weight Length Depth Base Open 20-7/8" 3-5/8" 3-3/8" 12"...
- Page 2 L'USINE DEVRA EFFECTUER TOUT L'ENTRETIEN ET LES AND REPAIR. BEFORE DOING ANY MAINTENANCE RÉPARATIONS. AVANT DE FAIRE TOUT ENTRETIEN OU OR REPAIR, FOLLOW SERVICE SET UP ARRANGEMENT RÉPARATION, VEUILLEZ CONTACTER WINCO. ON PAGE 11. Introduction Immediately Inspect for Shipping Damage All containers should be examined for damage before and during Congratulations on the purchase of your SPECTRUM™...
-
Page 3: Table Of Contents
Manual Impulse Bag Sealer Table of Contents Specifications ................1 Warnings ..................2 Introduction ................2 Packaging ..................3 Installation .................. 4 Food Safety ................. 5 Operation ..................6 Cleaning, Care & Maintenance ..........7 Safety ................... 7 Troubleshooting ................. 8 Service &... -
Page 4: Warnings
Important Safeguards To ensure safe installation and operation, please carefully read and understand the following statements. Unless the operator is adequately trained and supervised there is a possibility of serious injury. Owners of this equipment bear the responsibility to make certain that this equipment is used properly and safely, and to strictly follow all of the instructions contained in this manual and the requirements of local, state or federal law. -
Page 5: Installation
This machine is provided with a three-pronged grounding plug. The outlet to which this plug 6. The use of accessory attachments not recommended by WINCO is connected must be properly grounded. If the may cause fire, electric shock or injury. -
Page 6: Operation
• Do not immerse unit in water or use hose to clean. Ne jamais immerger l'appareil dans l'eau ni utilisez un jet d'eau pour le nettoyer. • If the power cord is damaged, it must be replaced by a WINCO® Approved Recommended Qualified Service Technician in order to avoid a hazard. -
Page 7: Troubleshooting
Parts protected by the manufacturer or its agent are not to be adjusted by the installer unless the installer is an authorized service agent. If you have any questions or problems DO NOT send unit to WINCO® without first contacting our customer service department. -
Page 8: Exploded View
Exploded View MODEL: EBS-400M & EBS-400M-I... -
Page 9: Parts List
MODELS: EBS-400M & EBS-400M-I Timing Switch Transformer Heating Element This circuit diagram has been provided to assist qualified electricians; only WINCO service agents or qualified electricians should carry out repairs if required. Do not remove any components or service panels on this product. -
Page 10: Limited Warranty
Limited Warranty WINCO® warrants to the original purchaser of new equipment that said equipment, when installed in accordance with our instructions within North America and subjected to normal use, is free from defects in material or workmanship for a period of 1 year. The labor warranty is one year from original installation or 18 months from actual factory shipment date, whichever date occurs first. - Page 11 Proof of purchase is required to extend warranty more than 1 year from date of shipment from the factory. THE FOREGOING WARRANTY PROVISIONS ARE A COMPLETE AND EXCLUSIVE STATEMENT BETWEEN THE BUYER AND SELLER. WINCO® NEITHER ASSUMES NOR AUTHORIZES ANY PERSONS TO ASSUME FOR IT ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH SAID EQUIPMENT.
- Page 12 Models: EBS-400M | EBS-400M-I www.wincous.com...
