MST13006
22 TON AIR/HYDRAULIC
TRUCK JACK
OWNERS MANUAL
Low Height .............................................................................9.06"
Ram Travel .............................................................................4.75"
Screw Adjustment ..................................................................4.13"
Max. Height ..........................................................................17.94"
MST13006
SPECIFICATIONS
Complies with ASME PALD/2009 Safety Standard
Handle Length ...........................................................................48"
Overall Length ......................................................................22.38"
Overall Width .............................................................................11"
Weight .................................................................................... 77 lb
11/07/16
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MONSTER MOBILE MST13006
Summary of Contents for MONSTER MOBILE MST13006
- Page 1 MST13006 22 TON AIR/HYDRAULIC TRUCK JACK OWNERS MANUAL SPECIFICATIONS Low Height ................9.06" Handle Length ................48" Ram Travel ................4.75" Overall Length ..............22.38" Screw Adjustment ..............4.13" Overall Width ................11" Max. Height ................17.94" Weight ..................77 lb Complies with ASME PALD/2009 Safety Standard...
-
Page 2: Warning Information
Failure to read this manual completely and thoroughly, failure to understand its OPERATING INSTRUCTIONS, SAFETY WARNINGS, MAINTENANCE INSTRUCTIONS and comply with them, and failure to comply with the METHODS TO AVOID HAZARDOUS SITUATIONS could cause accidents resulting in serious or fatal personal injury and/or property damage. MST13006 11/07/16... - Page 3 Remove the safety support stands from under the vehicle, being very careful not to move the vehicle. 9. Rotate the air lever to the left to lower the vehicle or load down to the ground. MST13006 11/07/16...
-
Page 4: Preventative Maintenance
PROBLEM: UNIT WILL NOT LIFT TO FULL HEIGHT. ACTION: Purge air from hydraulic system as above or check oil level in reservoir. PROBLEM: UNIT STILL DOES NOT OPERATE. ACTION: Contact your place of purchase for details on handling warranty. MST13006 11/07/16... - Page 5 PROFESSIONAL LIFTING EQUIPMENT. ALL OTHER WARRANTIES, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXCLUDED. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE. MST13006 11/07/16...
- Page 6 MST13006 22 TON AIR/HYDRAULIC TRUCK JACK EXPLODED DRAWING MST13006 11/07/16...
-
Page 7: Parts List
MST13006 22 TON AIR/HYDRAULIC TRUCK JACK PARTS LIST REF. # PART # DESCRIPTION QTY. REF. # PART # DESCRIPTION QTY. Bolt Block Bolt MS1300642 Coupler Bolt MS1300643 Coupler MS1300604 Short Orange Hose MS1300605 Washer MS1300645 Short Black Hose MS1300606 Wheel...
