Defender COMPACT User Manual page 7

ENGINEERING DRAWING
A
B
C
A
A 810 mm / 31.9"
B 25 mm / 1.0"
C 830 mm / 32.7"
D 37 mm / 1.5"
Accessories:
85103
DEFENDER
E 23 mm / 0.9"
F 27 mm / 1.1"
G 29 mm / 1.1"
H 30 mm / 1.1"
® COMPACT BASE
D E F G H G
I
J
K
L
I 28 mm / 1.1"
J 410 mm / 16.1"
K 235 mm / 9.3"
L 21 mm / 0.9"
COMPACT
F E
M
M 22 mm / 0.9"
7
