Summary of Contents for Fair-Play GL-7248
- Page 1 GL-7248, GOAL LIGHT ASSEMBLY INSTALLATION MANUAL REVISION DATE: 04-06-17 PART#: 98-7248-01...
- Page 2 SERVICE & CUSTOMER INFORMATION CUSTOMER MUST HAVE PART NUMBER WHEN ORDERING ITEMS THROUGH THE SERVICE DEPARTMENT. IF FURTHER HELP IS NEEDED CONTACT A TRANS-LUX SERVICE REP IN YOUR TRANS-LUX DEALER ORGANIZATION OR PHONE THE TRANS-LUX SERVICE DEPARTMENT (800) 747-5305 OR (800) 462-2716. TO AID YOU IN YOUR DISCUSSIONS WITH SERVICE REPS, WE SUGGEST THAT YOU RECORD THE FOLLOWING: MODEL NUMBER:_______________________________________________________________________________...
- Page 3 INSTRUCTION DRAWING LIST LED GOAL LIGHTS TABLE OF CONTENTS DESCRIPTION DRAWING NUMBER INTRODUCTION AND INSTRUCTIONS…………………………………………………………………………… 98-7248-01 ASSEMBLY DRAWING……………………………………………………………………………………………… 32-7242-04...
- Page 4 INTRODUCTION This manual is a reference guide for the installation of Trans-Lux LED goal light assembly. It includes information for typical installation. These instructions may need to be altered for your installation. If further help is needed, you may contact your local Trans-Lux representative or the Trans-Lux Customer Service Department at 1-800-747- 5305 or 1-800-462-2716.
- Page 5 Parts List ITEM PART NUMBER DESCRIPTION 30-7242-10 GOAL LIGHT TOP CHANNEL 30-7242-11 FRONT COVER, GOAL LIGHT 30-7242-12 GOAL LIGHT CORNERS 30-7242-13 SIDE CHANNEL,42" GOAL LIGHT 30-7242-14 TOP COVER, 42" GOAL LIGHT 30-7242-15. BOTTOM CHANNEL, 42" GOAL LIGHT 30-7242-19 MOUNTING STRAP, GOAL LIGHTS F0857 6-32 X 3/8"...
