- Page 1 MONACO STORAGE BOX DARK GREY Assembly Instructions Actual product size L166 X W77 X H96cm Dark Grey Need Help? 315870 With:Assembly instructions Missing or damaged parts IMPORTANT-RETAIN FOR FUTURE REFERENCE CALL:0333 777 8999 Produced in China for Next Retail Ltd. Version 1...
- Page 2 Next Retail Ltd, Do not use silicone based furniture polish. Silicone in furniture Desford Road, polishes can break down the finish Leicester, LE19 4AT To view our full furniture range please visit www.next.co.uk Produced in China for Next Retail Ltd. 315870 2020...
- Page 3 （The upper ends without Screw hole） （Non woven vine） Components supplied. Please use this guide if you require replacement parts. Dimensions V isual Dimensions V isual 165.5X77X3cm 70X90X3cm 161X93X3cm 155.5X70X3cm 161X93X3cm 156X69X88cm 70X90X3cm Produced in China for Next Retail Ltd. 315870 2020...
- Page 4 MONACO STORAGE BOX DARK GREY Assembly Instructions Fixtures and fittings supplied(actual size) Dimensions ø13x5.0mm M6x25mm ø16x1.0mm M6x40mm ø16x6.0mm ø4x66mm Produced in China for Next Retail Ltd. 315870 2020...
- Page 5 MONACO STORAGE BOX DARK GREY Assembly Instructions ø13 5.0mm ø16 1.0mm 40mm ø4 x ø13 5.0mm ø16 1.0mm 40mm ø4 x Produced in China for Next Retail Ltd. 315870 2020...
- Page 6 40mm ø4 x - Remember to fully tighten all bolts before turning over. ø13 5.0mm 25mm ø16 1.0mm ø16 6.0mm ø4x - Remember to fully tighten all bolts before turning over. Produced in China for Next Retail Ltd. 315870 2020...
- Page 7 MONACO STORAGE BOX DARK GREY Assembly Instructions 77CM 166CM 96CM Produced in China for Next Retail Ltd. 315870 2020...
