GIpro Mount
Instructions manual
Fully adjustable handlebar mount for GIpro
Choose the proper shim
Thick
Disassemble the clamp. Separate the plastic shims
and unroll the thin shim. Depending on the target tube
diameter, select the corresponding shim and place on
the handlebar.
21-23mm (7/8") : Thick Shim
24-26mm (1")
27-29mm (9/8") : Without Shim
Insert the pin
Slide the pin into place, making sure the threaded hole
is aligned with the bolt hole.
Thin
: Thin Shim
Place the clamp on the bar
Wind the arm around the handlebar then close.
If a plastic shim is used, rotate it to the correct
position.
Fasten the clamp
Tighten the bolt with an
M5 hex (Allen) wrench
to secure the clamp on
the bar in the desired
position.
