boAt AAVANTE BAR 4000DA User Manual

2.1.2 channel home theatre soundbar with dolby atmos
Hide thumbs
Table of Contents

Advertisement

Quick Links

2.1.2 CHANNEL HOME THEATRE SOUNDBAR
Discover a new era of immersive, cinematic audio experience at home with boAt AAVANTE BAR 4000DA, 2.1.2 Channel Home
Theatre Soundbar that comes with Dolby Atmos technology. With a powerful 200W total audio output, the sleek and slim
sound bar along with the versatile subwoofer brings every aspect of your entertainment be it music, shows or movies to a new
life in the volume and true surround sound clarity it deserves. The thumping drivers deliver clarity on mid and high ranges, and
the 60W subwoofer lls in the rumbling lows. The 2.1.2 channel surround sound system provides a balanced sound and deep
bass for your movies, music and even video games, so that you can experience cinematic sound that revolves around you. Stay
plugged into Nirvana with an array of connectivity options, including the Bluetooth V5.0 wireless technology.
Dolby Atmos : Dolby Atmos is a surround sound technology that expands on existing surround sound systems by adding height
channels, allowing sounds to be interpreted as three-dimensional objects. Get ready to delve deeper into Nirvana with Dolby Atmos
that delivers captivating sound by o ering a three-dimensional e ect. Bring your home to life with boAt AAVANTE BAR 4000DA.
Note: as Dolby ATMOS code stream bandwidth is large, in order to play kindly please wait for about 10 seconds till "ARC" gets
displayed after powering on the device .
WITH DOLBY ATMOS
AAVANTE BAR 4000DA
Aavante Bar 4000DA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AAVANTE BAR 4000DA and is the answer not in the manual?

Questions and answers

Related Manuals for boAt AAVANTE BAR 4000DA

Summary of Contents for boAt AAVANTE BAR 4000DA

  • Page 1 Get ready to delve deeper into Nirvana with Dolby Atmos that delivers captivating sound by o ering a three-dimensional e ect. Bring your home to life with boAt AAVANTE BAR 4000DA.

  • Page 3: Specifications

    USB PORT: Audio input from a USB storage device. 10 11 12 Upgrade software of this product. WOOFER PORT: Connect to the wired subwoofer. SPECIFICATIONS Model boAt AAVANTE BAR 4000DA Technology USB/BT/AUX/Optical/2x HDMI In /HDMI (ARC) Out 3D Audio Technology Dolby Atmos Drivers 2.25"x4 +2"×2+6.5"×1 SW...
  • Page 4 1. : Standby mode for power on/o / Multifunction Button. 2. PAIR: Connect or disconnect to the pairing device. (Press the button more than 2 seconds). 3. Volume+: Master volume up : Pre button: Previous program (Only work under USB & BT Mode). 5.

  • Page 5: Positioning The Sound Bar

    Positioning the Sound Bar Place on a flat Surface Place the sound bar horizontally on a flat surface such as a TV unit or shelves and align it centrally with the TV screen. Allow some space between the speaker and the wall. Don’t place inside a cabinet or an a walled shelf.
  • Page 6 TV's sound settings / computer's audio control panel to select the audio system. Also, the TV should be compatible with the Dolby Atmos technology to play the Dolby Atmos content via the soundbar. Enjoy the Dolby Atmos 3D audio technology on Aavante Bar 4000DA.

  • Page 7: Power On And Off

    Power ON and OFF 1. Plug in the power cord with one side to AC IN on sound bar and the other side to an AC wall outlet (see the following diagram). When you connect the soundbar to the main socket, the unit will be in STANDBY mode, firstly it will display -- 2.
  • Page 8 ” on the sound bar will flicker in the Bluetooth pairing mode. 2. Activate the pairing function on your phone or other compatible device & select “Aavante Bar 4000DA” by BT connection. 3. When successfully paired, you will hear a tone and LED display “...

  • Page 9: Aux Mode

    AUX mode Connect the sound bar to your PC, tablet, smartphone, TV, or other device using the included audio cable.  Short-press the Input button to switch to AUX input mode with the LED Display lit up ( In this mode, playback can only be controlled on your connected device ...
  • Page 10 4000DA This symbol alerts you about the presence of uninsutated dangerous & Smart 4000DA...
  • Page 12 doesn’t respond...
  • Page 13 place Manufactured under license from Dolby Laboratories. D olby, Dolby Audio, Dolby Atmos and the double -D symbol are trademarks of Dolby Laboratories.
